Fuses

B050 - Fuse 1000VDC aBat 350A - 118,85mm - Tin Plated

B050 - Fuse 1000VDC aBat 350A - 118,85mm - Tin Plated

Reference 768.151.83.0.0 - Manufacturer FAULTRAP
Class aBat, aR
Rated current In (A) 350
Applicable standards IEC, UL
Power loss (W) 48
Rated Voltage Un DC (V) 1000
Time costant L/R (ms) 2
Series name B050
Rated breaking capacity I1 DC (kA) 100
Fuse Dimension (mm) 50x141
Melting I²t value (A²s) 33600
Minimum breaking current (A) 3500
Fuse Connection/Terminal type Screw fixing
Fixing connection centres (mm) 118
Total clearing I²t @Un DC (A²s) 88000
Price List €101.28/pc
Quantity
lock Datasheet
NR2A - Fuse DIN000 80mm aR 500VAC ind. micro 350A

NR2A - Fuse DIN000 80mm aR 500VAC ind. micro 350A

Reference 768.569.77.0.0 - Manufacturer FAULTRAP
Class aR
Rated current In (A) 350
Rated Voltage Un AC (V) 500
Dimension 000
Applicable standards IEC
Power loss (W) 80
Time costant L/R (ms) 2
Series name NR2A
Melting I²t value (A²s) 21500
Fuse Connection/Terminal type Screw fixing
Fixing connection centres (mm) 80
Voltage of total clearing I2t test 500
Total clearing I²t @Un AC (A²s) 92500
Rated breaking capacity I1 AC (kA) 200000
Product available on request Ask for more information
RL12 - Fuse 25x60mm 125VDC 70A

RL12 - Fuse 25x60mm 125VDC 70A

Reference 768.964.48.0.0 - Manufacturer FAULTRAP
Rated current In (A) 70
Power loss (W) 6,8
Rated Voltage Un DC (V) 125
Time costant L/R (ms) 3
Series name RL12
Rated breaking capacity I1 DC (kA) 10000
Melting I²t value (A²s) 500
Total clearing I²t @Un AC (A²s) 4000
Price List €3.74/pc
Quantity
V108 - Fuse 10x85 1500VDC gPV In-line 4A

V108 - Fuse 10x85 1500VDC gPV In-line 4A

Reference 770.725.83.0.0 - Manufacturer FAULTRAP
Class gPV
Rated current In (A) 4
Applicable standards IEC, UL
Power loss (W) 2,16
Rated Voltage Un DC (V) 1500
Series name V108
Rated breaking capacity I1 DC (kA) 20000
Fuse Dimension (mm) 10x85
Melting I²t value (A²s) 6,48
Fuse Connection/Terminal type Cylindrical In-line
Voltage of total clearing I2t test 1500
Total clearing I²t @Un AC (A²s) 23
Product available on request Ask for more information
X800 - Fuse 22x65mm 800VAC gG 63A

X800 - Fuse 22x65mm 800VAC gG 63A

Reference 771.575.29.0.0 - Manufacturer FAULTRAP
Class gG
Rated current In (A) 63
Rated Voltage Un AC (V) 800
Applicable standards IEC
Power loss (W) 6,5
Series name X800
Fuse Dimension (mm) 22x65
Melting I²t value (A²s) 4050
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 800
Total clearing I²t @Un AC (A²s) 34300
Rated breaking capacity I1 AC (kA) 80000
Price List €41.82/pc
Quantity
lock Datasheet
B500 - Fuse 1500VDC aBat 2xM12 with micro adapter 1000A

B500 - Fuse 1500VDC aBat 2xM12 with micro adapter 1000A

Reference 771.687.08.0.0 - Manufacturer FAULTRAP
Class aBat
Rated current In (A) 1000
Applicable standards IEC
Power loss (W) 260
Rated Voltage Un DC (V) 1500
Time costant L/R (ms) 3
Series name B500
Rated breaking capacity I1 DC (kA) 250000
Fuse Dimension (mm) 103x144
Fixing dimensions M12
Melting I²t value (A²s) 404000
Minimum breaking current (A) 11000
Fuse Connection/Terminal type Screw fixing
Voltage of total clearing I2t test 1500
Total clearing I²t @Un AC (A²s) 2210000
Product available on request Ask for more information
C100 - Fuse 690V aR size 1 M8 200A

C100 - Fuse 690V aR size 1 M8 200A

Reference 772.168.00.0.0 - Manufacturer FAULTRAP
Class aR
Rated current In (A) 200
Rated Voltage Un AC (V) 690
Dimension SQB2
Applicable standards IEC
Power loss (W) 30
Fixing dimensions M8
Melting I²t value (A²s) 2300
Fuse Connection/Terminal type Screw fixing
Voltage of total clearing I2t test 690
Total clearing I²t @Un AC (A²s) 15500
Rated breaking capacity I1 AC (kA) 100000
Product available on request Ask for more information
NR2A-Fuse 000/80 aR 700VDC/690VAC with ind. w/o lug 100A

NR2A-Fuse 000/80 aR 700VDC/690VAC with ind. w/o lug 100A

Reference 773.800.56.0.0 - Manufacturer FAULTRAP
Class aR
Rated current In (A) 100
Rated Voltage Un AC (V) 690
Dimension 000
Applicable standards IEC
Power loss (W) 19
Rated Voltage Un DC (V) 700
Time costant L/R (ms) 2
Series name NR2A
Rated breaking capacity I1 DC (kA) 30000
Melting I²t value (A²s) 1340
Fuse Connection/Terminal type Screw fixing
Fixing connection centres (mm) 80
Voltage of total clearing I2t test 700
Total clearing I²t @Un AC (A²s) 5000
Rated breaking capacity I1 AC (kA) 200000
Product available on request Ask for more information
20PV22 - Fuse 2000VDC gPV 22x85mm inline copper 10/12AWG 12A

20PV22 - Fuse 2000VDC gPV 22x85mm inline copper 10/12AWG 12A

Reference 773.810.27.0.0 - Manufacturer FAULTRAP
Class gPV
Rated current In (A) 12
Applicable standards IEC
Power loss (W) 4
Rated Voltage Un DC (V) 2000
Time costant L/R (ms) 1-3
Series name 20PV22
Rated breaking capacity I1 DC (kA) 50
Fuse Dimension (mm) 22x85
Melting I²t value (A²s) 23
Fuse Connection/Terminal type Cylindrical
Product available on request Ask for more information
C200 - Fuse 690VAC aR 700A size 2 61x52,4mm M10 flush end terminals

C200 - Fuse 690VAC aR 700A size 2 61x52,4mm M10 flush end terminals

Reference 740.683.38.0.0 - Manufacturer FAULTRAP
Class aR
Rated current In (A) 700
Rated Voltage Un AC (V) 690
Dimension SQB2
Applicable standards IEC
Power loss (W) 92
Series name C200
Fixing dimensions M10
Melting I²t value (A²s) 74000
Fuse Connection/Terminal type Screw fixing
Total clearing I²t @Un AC (A²s) 510600
Rated breaking capacity I1 AC (kA) 200
Product available on request Ask for more information
C200 - Fuse 690VAC aR 800A size 2 61x52,4mm M10 flush end terminals

C200 - Fuse 690VAC aR 800A size 2 61x52,4mm M10 flush end terminals

Reference 745.259.17.0.0 - Manufacturer FAULTRAP
Class aR
Rated current In (A) 800
Rated Voltage Un AC (V) 690
Dimension SQB2
Applicable standards IEC
Power loss (W) 98
Series name C200
Fixing dimensions M10
Melting I²t value (A²s) 115200
Fuse Connection/Terminal type Screw fixing
Total clearing I²t @Un AC (A²s) 795000
Rated breaking capacity I1 AC (kA) 200
Product available on request Ask for more information
20PV22 - Fuse 2000VDC gPV 22x85 inline 40A 6/8 AWG

20PV22 - Fuse 2000VDC gPV 22x85 inline 40A 6/8 AWG

Reference 730.712.59.0.0 - Manufacturer FAULTRAP
Class gPV
Rated current In (A) 40
Applicable standards IEC
Power loss (W) 11.3
Rated Voltage Un DC (V) 2000
Time costant L/R (ms) 1-3
Series name 20PV22
Rated breaking capacity I1 DC (kA) 50
Fuse Dimension (mm) 22x85
Melting I²t value (A²s) 415
Fuse Connection/Terminal type In-line for copper cable
Product available on request Ask for more information
20PV22 - Fuse 2000VDC gPV 22x85 inline 35A 6/8 AWG

20PV22 - Fuse 2000VDC gPV 22x85 inline 35A 6/8 AWG

Reference 732.907.12.0.0 - Manufacturer FAULTRAP
Class gPV
Rated current In (A) 35
Applicable standards IEC
Power loss (W) 10.7
Rated Voltage Un DC (V) 2000
Time costant L/R (ms) 1-3
Series name 20PV22
Rated breaking capacity I1 DC (kA) 50
Fuse Dimension (mm) 22x85
Melting I²t value (A²s) 265
Fuse Connection/Terminal type In-line for copper cable
Product available on request Ask for more information
C200 - Fuse 690VAC aR 1100A size 2 61x50mm M10 flush end...

C200 - Fuse 690VAC aR 1100A size 2 61x50mm M10 flush end terminals, with microswitch adapter

Reference 763.377.28.0.0 - Manufacturer FAULTRAP
Class aR
Rated current In (A) 1100
Rated Voltage Un AC (V) 600
Dimension SQB2
Applicable standards IEC
Power loss (W) 121
Series name C200
Fuse Dimension (mm) 61x50
Fixing dimensions M10
Melting I²t value (A²s) 290000
Fuse Connection/Terminal type Screw fixing
Total clearing I²t @Un AC (A²s) 2001000
Rated breaking capacity I1 AC (kA) 200
Product available on request Ask for more information
C200 - Fuse 690VAC aR 1000A size 2 61x52,4mm M10 flush...

C200 - Fuse 690VAC aR 1000A size 2 61x52,4mm M10 flush end terminals

Reference 765.955.74.0.0 - Manufacturer FAULTRAP
Class aR
Rated current In (A) 1100
Rated Voltage Un AC (V) 600
Dimension SQB2
Applicable standards IEC
Power loss (W) 121
Series name C200
Fuse Dimension (mm) 61x50
Fixing dimensions M10
Melting I²t value (A²s) 290000
Fuse Connection/Terminal type Screw fixing
Total clearing I²t @Un AC (A²s) 2001000
Rated breaking capacity I1 AC (kA) 200
Product available on request Ask for more information
NR2B - Fuse DIN00 80mm aR 700VDC/690VAC with ind. lug 315A

NR2B - Fuse DIN00 80mm aR 700VDC/690VAC with ind. lug 315A

Reference 712.042.86.0.0 - Manufacturer FAULTRAP
Class aR
Rated current In (A) 315
Rated Voltage Un AC (V) 690
Dimension 000
Applicable standards IEC, UL
Power loss (W) 70
Rated Voltage Un DC (V) 700
Time costant L/R (ms) 2
Series name NR2B
Rated breaking capacity I1 DC (kA) 30000
Melting I²t value (A²s) 16450
Fuse Connection/Terminal type Screw fixing
Fixing connection centres (mm) 80
Voltage of total clearing I2t test 700
Total clearing I²t @Un AC (A²s) 60000
Rated breaking capacity I1 AC (kA) 200000
Price List €62.83/pc
Quantity
lock Datasheet
20PV27 - Fuse 2000VDC gPV 27x85mm inline copper 4AWG 100A

20PV27 - Fuse 2000VDC gPV 27x85mm inline copper 4AWG 100A

Reference 713.261.87.0.0 - Manufacturer FAULTRAP
Class gPV
Rated current In (A) 100
Applicable standards IEC
Power loss (W) 21.1
Rated Voltage Un DC (V) 2000
Time costant L/R (ms) 1-3
Series name 20PV27
Rated breaking capacity I1 DC (kA) 50
Fuse Dimension (mm) 27x85
Melting I²t value (A²s) 5600
Fuse Connection/Terminal type In-line for copper cable
Product available on request Ask for more information
20PV10 - Fuse 2000VDC gPV 10x85 inline 3A

20PV10 - Fuse 2000VDC gPV 10x85 inline 3A

Reference 714.152.74.0.0 - Manufacturer FAULTRAP
Class gPV
Rated current In (A) 3
Applicable standards IEC
Power loss (W) 1,8
Rated Voltage Un DC (V) 2000
Time costant L/R (ms) 1-3
Series name 20PV10
Rated breaking capacity I1 DC (kA) 50
Fuse Dimension (mm) 10x85
Melting I²t value (A²s) 5
Fuse Connection/Terminal type In-line for copper cable
Product available on request Ask for more information
20PV22 - Fuse 2000VDC gPV 22x85mm inline aluminum 4AWG 40A

20PV22 - Fuse 2000VDC gPV 22x85mm inline aluminum 4AWG 40A

Reference 715.106.10.0.0 - Manufacturer FAULTRAP
Class gPV
Rated current In (A) 40
Applicable standards IEC
Power loss (W) 11.3
Rated Voltage Un DC (V) 2000
Time costant L/R (ms) 1-3
Series name 20PV22
Rated breaking capacity I1 DC (kA) 50
Fuse Dimension (mm) 22x85
Melting I²t value (A²s) 415
Fuse Connection/Terminal type In-line for aluminum cable
Product available on request Ask for more information
20PV22 - Fuse 2000VDC gPV 22x85 15A

20PV22 - Fuse 2000VDC gPV 22x85 15A

Reference 717.383.24.0.0 - Manufacturer FAULTRAP
Class gPV
Rated current In (A) 15
Applicable standards IEC
Power loss (W) 4.8
Rated Voltage Un DC (V) 2000
Time costant L/R (ms) 1-3
Series name 20PV22
Rated breaking capacity I1 DC (kA) 50
Fuse Dimension (mm) 22x85
Melting I²t value (A²s) 38
Fuse Connection/Terminal type Cylindrical
Product available on request Ask for more information
UR22 - Fuse 500V AC 22x58 cylindrical 135A

UR22 - Fuse 500V AC 22x58 cylindrical 135A

Reference 719.479.82.0.0 - Manufacturer FAULTRAP
Class aR
Rated current In (A) 135
Rated Voltage Un AC (V) 550
Applicable standards IEC, UL
Power loss (W) 28,6
Series name UR22
Melting I²t value (A²s) 3640
Fuse Connection/Terminal type Cylindrical
Total clearing I²t @Un AC (A²s) 17800
Rated breaking capacity I1 AC (kA) 200
Product available on request Ask for more information
BP22 -Fuse 22x65mm cylindrical 50A

BP22 -Fuse 22x65mm cylindrical 50A

Reference 719.648.37.0.0 - Manufacturer FAULTRAP
Class gBat, gR
Rated current In (A) 50
Applicable standards IEC, UL
Power loss (W) 7,9
Rated Voltage Un DC (V) 1000
Series name BP22
Rated breaking capacity I1 DC (kA) 100000
Fuse Dimension (mm) 22x65
Fuse Connection/Terminal type Cylindrical
Total clearing I²t @Un AC (A²s) 737
Product available on request Ask for more information
Filter by
Manufacturer
Series name
Fuse size
Class
Fuse Connection/Terminal type
Rated current In (A)
Rated Voltage Un AC (V)
Rated Voltage Un DC (V)
Applicable standards
Product added to compare.
Product added to wishlist
