List of products by manufacturer FAULTRAP

10TD - Fuse 10x38 500VAC aM/aR 16A

10TD - Fuse 10x38 500VAC aM/aR 16A

Reference 863.903.84.0.0 - Manufacturer FAULTRAP
Rated current In (A) 16
Rated Voltage Un AC (V) 500
Rated break.capacity I1 AC (A) 50000
Voltage of total I2t test 500
Format Cylindrical
Dimension 10x38mm
Pre-arcing I2t value (A2s) 560
Total I2t value (A2s) 2060
Power loss (W) 0
Series name 10TD
Product available on request Ask for more information
AB22 - Fuse 22x65 1000VDC aBat 40A

AB22 - Fuse 22x65 1000VDC aBat 40A

Reference 873.361.63.0.0 - Manufacturer FAULTRAP
Class aBat
Rated current In (A) 40
Rated Voltage Un AC (V) 1000
Format Cylindrical
Dimension 22x65mm
Pre-arcing I2t value (A2s) 415
Total I2t value (A2s) 2300
Homologations IEC
Power loss (W) 8,5
Rated Voltage Un DC (V) 1000
Rated break.capacity I1 DC (A) 10000
Series name AB22
Product available on request Ask for more information
EV65.1000 - Fuse 1000VDC 22x65 cylindrical 40A

EV65.1000 - Fuse 1000VDC 22x65 cylindrical 40A

Reference 893.574.49.0.0 - Manufacturer FAULTRAP
Class EV full
Rated current In (A) 40
Voltage of total I2t test 1000
Format Cylindrical
Dimension 22x65mm
Pre-arcing I2t value (A2s) 425
Total I2t value (A2s) 1750
Homologations UL
Power loss (W) 9
Rated Voltage Un DC (V) 1000
Rated break.capacity I1 DC (A) 25000
Time costant L/R (ms) 2,5
Series name EV65
Product available on request Ask for more information
BPF3 - Fuse 1500VDC aBat M12 1000A

BPF3 - Fuse 1500VDC aBat M12 1000A

Reference 900.131.26.0.0 - Manufacturer FAULTRAP
Class aBat
Rated current In (A) 1000
Voltage of total I2t test 1500
Format Screw fixing
Dimension 76x140mm
Pre-arcing I2t value (A2s) 342200
Total I2t value (A2s) 1197700
Homologations IEC
Power loss (W) 260
Rated Voltage Un DC (V) 1500
Rated break.capacity I1 DC (A) 100000
Time costant L/R (ms) 3
Series name BPF3
Min breaking current (A) 10000
Product available on request Ask for more information
DC22 - Fuse 1000VDC aBat 22x65mm 20A

DC22 - Fuse 1000VDC aBat 22x65mm 20A

Reference 903.248.36.0.0 - Manufacturer FAULTRAP
Class aBat
Rated current In (A) 20
Format Cylindrical
Dimension 22x65mm
Pre-arcing I2t value (A2s) 48
Total I2t value (A2s) 220
Power loss (W) 4.4
Rated Voltage Un DC (V) 1000
Rated break.capacity I1 DC (A) 100000
Series name DC22
Product available on request Ask for more information
B500 - Fuse 1500VDC aBat 4xM10 with micro adapter 750A

B500 - Fuse 1500VDC aBat 4xM10 with micro adapter 750A

Reference 909.634.43.0.0 - Manufacturer FAULTRAP
Class aBat
Rated current In (A) 750
Voltage of total I2t test 1500
Format Screw fixing
Dimension 89x144mm
Pre-arcing I2t value (A2s) 228000
Total I2t value (A2s) 1264000
Homologations IEC
Power loss (W) 205
Rated Voltage Un DC (V) 1500
Rated break.capacity I1 DC (A) 100000
Time costant L/R (ms) 3
Min breaking current (A) 8700
Series name B500
Product available on request Ask for more information
10TD - Fuse 10x38 500VAC aM/aR 10A

10TD - Fuse 10x38 500VAC aM/aR 10A

Reference 922.606.35.0.0 - Manufacturer FAULTRAP
Rated current In (A) 10
Rated Voltage Un AC (V) 500
Rated break.capacity I1 AC (A) 50000
Voltage of total I2t test 500
Format Cylindrical
Dimension 10x38mm
Pre-arcing I2t value (A2s) 305
Total I2t value (A2s) 900
Power loss (W) 0
Series name 10TD
Product available on request Ask for more information
B500 - Fuse 1500VDC aBat 4xM10 with micro adapter 700A

B500 - Fuse 1500VDC aBat 4xM10 with micro adapter 700A

Reference 929.737.75.0.0 - Manufacturer FAULTRAP
Class aBat
Rated current In (A) 700
Voltage of total I2t test 1500
Format Screw fixing
Dimension 89x144mm
Pre-arcing I2t value (A2s) 208000
Total I2t value (A2s) 1169000
Homologations IEC
Power loss (W) 185
Rated Voltage Un DC (V) 1500
Rated break.capacity I1 DC (A) 100000
Time costant L/R (ms) 3
Min breaking current (A) 8000
Series name B500
Product available on request Ask for more information
EV65.1000 - Fuse 1000VDC 22x65 cylindrical 75A

EV65.1000 - Fuse 1000VDC 22x65 cylindrical 75A

Reference 938.403.22.0.0 - Manufacturer FAULTRAP
Class EV full
Rated current In (A) 75
Voltage of total I2t test 1000
Format Cylindrical
Dimension 22x65mm
Pre-arcing I2t value (A2s) 2480
Total I2t value (A2s) 7300
Homologations UL
Power loss (W) 13,5
Rated Voltage Un DC (V) 1000
Rated break.capacity I1 DC (A) 25000
Time costant L/R (ms) 2,5
Series name EV65
Product available on request Ask for more information
B300 - Fuse 1000V DC aBat DC 2xM12 1100A

B300 - Fuse 1000V DC aBat DC 2xM12 1100A

Reference 942.974.93.0.0 - Manufacturer FAULTRAP
Class aBat
Rated current In (A) 1100
Voltage of total I2t test 1000
Format Screw fixing
Dimension 89x106,5mm
Pre-arcing I2t value (A2s) 373200
Total I2t value (A2s) 1120000
Power loss (W) 210
Rated Voltage Un DC (V) 1000
Rated break.capacity I1 DC (A) 100000
Time costant L/R (ms) 2
Series name B300
Product available on request Ask for more information
B500 - Fuse 1500VDC aBat 2xM12 with micro adapter 700A

B500 - Fuse 1500VDC aBat 2xM12 with micro adapter 700A

Reference 946.887.63.0.0 - Manufacturer FAULTRAP
Class aBat
Rated current In (A) 700
Voltage of total I2t test 1500
Format Screw fixing
Dimension 89x144mm
Pre-arcing I2t value (A2s) 208000
Total I2t value (A2s) 1169000
Homologations IEC
Power loss (W) 185
Rated Voltage Un DC (V) 1500
Rated break.capacity I1 DC (A) 100000
Time costant L/R (ms) 3
Min breaking current (A) 8000
Series name B100
Product available on request Ask for more information
EV65.1000 - Fuse 1000VDC 22x65 cylindrical 50A

EV65.1000 - Fuse 1000VDC 22x65 cylindrical 50A

Reference 968.836.79.0.0 - Manufacturer FAULTRAP
Class EV full
Rated current In (A) 50
Voltage of total I2t test 1000
Format Cylindrical
Dimension 22x65mm
Pre-arcing I2t value (A2s) 685
Total I2t value (A2s) 2800
Homologations UL
Power loss (W) 11
Rated Voltage Un DC (V) 1000
Rated break.capacity I1 DC (A) 25000
Time costant L/R (ms) 2,5
Series name EV65
Product available on request Ask for more information
AB22 - Fuse 22x65 1000VDC aBat 40A

AB22 - Fuse 22x65 1000VDC aBat 40A

Reference 972.091.49.0.0 - Manufacturer FAULTRAP
Class aBat
Rated current In (A) 60
Rated Voltage Un AC (V) 1000
Format Cylindrical
Dimension 22x65mm
Pre-arcing I2t value (A2s) 1270
Total I2t value (A2s) 7000
Homologations IEC
Power loss (W) 0
Rated Voltage Un DC (V) 1000
Rated break.capacity I1 DC (A) 10000
Series name AB22
Product available on request Ask for more information
NRAB - Fuse 690V AC aR NH00 with indicator 63A

NRAB - Fuse 690V AC aR NH00 with indicator 63A

Reference 444.949.61.0.0 - Manufacturer FAULTRAP
Class aR
Rated current In (A) 63
Rated Voltage Un AC (V) 690
Rated break.capacity I1 AC (A) 200000
Voltage of total I2t test 770
Format NH knife contact
Dimension NH00
Pre-arcing I2t value (A2s) 520
Total I2t value (A2s) 2500
Homologations IEC
Power loss (W) 9,5
Rated Voltage Un DC (V) 700
Rated break.capacity I1 DC (A) 30000
Time costant L/R (ms) 2
Series name NRAB
Product available on request Ask for more information
B100 - Fuse 1000VDC aBat 750A - 152,7mm - Silver Plated

B100 - Fuse 1000VDC aBat 750A - 152,7mm - Silver Plated

Reference 456.954.32.0.0 - Manufacturer FAULTRAP
Class aBat
Rated current In (A) 750
Voltage of total I2t test 1000
Format Screw fixing
Dimension 63,5x130,5mm
Pre-arcing I2t value (A2s) 166000
Total I2t value (A2s) 500000
Power loss (W) 140
Rated Voltage Un DC (V) 1000
Rated break.capacity I1 DC (A) 100000
Time costant L/R (ms) 2
Series name B100
Min breaking current (A) 7500
Product available on request Ask for more information
B100 - Fuse 1000VDC aBat 900A - 152,7mm - Silver Plated

B100 - Fuse 1000VDC aBat 900A - 152,7mm - Silver Plated

Reference 456.383.65.0.0 - Manufacturer FAULTRAP
Class aBat
Rated current In (A) 900
Voltage of total I2t test 1000
Format Screw fixing
Dimension 63,5x203,2mm
Pre-arcing I2t value (A2s) 267000
Total I2t value (A2s) 813000
Power loss (W) 170
Rated Voltage Un DC (V) 1000
Rated break.capacity I1 DC (A) 100000
Time costant L/R (ms) 2
Series name B100
Min breaking current (A) 9000
Product available on request Ask for more information
T500 - Fuse 500VDC aBat d:38mm axial 80mm 80A

T500 - Fuse 500VDC aBat d:38mm axial 80mm 80A

Reference 449.701.36.0.0 - Manufacturer FAULTRAP
Class aBat
Rated current In (A) 80
Voltage of total I2t test 500
Format Screw fixing
Dimension 38x80mm
Pre-arcing I2t value (A2s) 1300
Total I2t value (A2s) 2000
Power loss (W) 7,5
Rated Voltage Un DC (V) 500
Rated break.capacity I1 DC (A) 100000
Time costant L/R (ms) 2
Series name T500
Product available on request Ask for more information
B100 - Fuse 1000VDC aBat double body 1600A - Silver Plated

B100 - Fuse 1000VDC aBat double body 1600A - Silver Plated

Reference 407.568.47.0.0 - Manufacturer FAULTRAP
Class aBat
Rated current In (A) 1600
Voltage of total I2t test 1000
Format Screw fixing
Pre-arcing I2t value (A2s) 740000
Total I2t value (A2s) 2200000
Power loss (W) 315
Fuses dimension 63,5x130,5
Rated Voltage Un DC (V) 1000
Rated break.capacity I1 DC (A) 100000
Time costant L/R (ms) 2
Series name B100
Min breaking current (A) 16000
Product available on request Ask for more information
B100 - Fuse 1000VDC aBat 900A - 132,7mm - Silver Plated

B100 - Fuse 1000VDC aBat 900A - 132,7mm - Silver Plated

Reference 374.004.92.0.0 - Manufacturer FAULTRAP
Class aBat
Rated current In (A) 900
Voltage of total I2t test 1000
Format Screw fixing
Pre-arcing I2t value (A2s) 267000
Total I2t value (A2s) 813000
Power loss (W) 170
Fuses dimension 63,5x167
Rated Voltage Un DC (V) 1000
Rated break.capacity I1 DC (A) 100000
Time costant L/R (ms) 2
Series name B100
Min breaking current (A) 9000
Product available on request Ask for more information
NRAB - Fuse 690V AC aR NH00 with indicator 40A

NRAB - Fuse 690V AC aR NH00 with indicator 40A

Reference 383.177.16.0.0 - Manufacturer FAULTRAP
Class aR
Rated current In (A) 40
Rated Voltage Un AC (V) 690
Rated break.capacity I1 AC (A) 200000
Voltage of total I2t test 770
Format NH knife contact
Dimension NH00
Pre-arcing I2t value (A2s) 230
Total I2t value (A2s) 1100
Homologations IEC
Power loss (W) 7,2
Rated Voltage Un DC (V) 700
Rated break.capacity I1 DC (A) 30000
Time costant L/R (ms) 2
Series name NRAB
Product available on request Ask for more information
