List of products by manufacturer SIBA

Fuse 12kV full range 85x292 with striker 80A 80N

Fuse 12kV full range 85x292 with striker 80A 80N

Reference 3002003.80.0 - Manufacturer SIBA
Class HHD full
Rated current In (A) 80
Rated Voltage Un AC (V) 12000
Applicable standards IEC
Power loss (W) 68
Resistance (ohm) 7,7
Fuse Dimension (mm) 85x292
Melting I²t value (A²s) 145
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 10500
Total clearing I²t @Un AC (A²s) 31000
Rated breaking capacity I1 AC (kA) 80000
Weight (gr) 3898
Price List €363.23/pc
Quantity
lock Datasheet
Fuse 12kV 85x292 back-up with striker 160ARC125 80N

Fuse 12kV 85x292 back-up with striker 160ARC125 80N

Reference 3002013.160.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 160
Rated Voltage Un AC (V) 6000
Applicable standards IEC
Power loss (W) 90
Resistance (ohm) 0,004
Fuse Dimension (mm) 85x292
Melting I²t value (A²s) 78500
Minimum breaking current (A) 600
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 5220
Total clearing I²t @Un AC (A²s) 650000
Rated breaking capacity I1 AC (kA) 80000
Weight (gr) 3930
Price List €280.33/pc
Quantity
lock Datasheet
Fuse 12kV 87x292 back-up striker no temp.lim200ARC125

Fuse 12kV 87x292 back-up striker no temp.lim200ARC125

Reference 3002014.200LM.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 200
Rated Voltage Un AC (V) 6000
Applicable standards IEC
Power loss (W) 71
Resistance (ohm) 0,0032
Fuse Dimension (mm) 85x292
Melting I²t value (A²s) 227000
Minimum breaking current (A) 870
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 5220
Total clearing I²t @Un AC (A²s) 1300000
Rated breaking capacity I1 AC (kA) 80000
Price List €508.18/pc
Quantity
lock Datasheet
Fuse 12kV 87x292 back-up striker no temp.lim250ARC140

Fuse 12kV 87x292 back-up striker no temp.lim250ARC140

Reference 3002014.250LM.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 250
Rated Voltage Un AC (V) 6000
Applicable standards IEC
Power loss (W) 81
Resistance (ohm) 0,003
Fuse Dimension (mm) 85x292
Melting I²t value (A²s) 265000
Minimum breaking current (A) 1000
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 5220
Total clearing I²t @Un AC (A²s) 1800000
Rated breaking capacity I1 AC (kA) 80000
Price List €441.36/pc
Quantity
lock Datasheet
Fuse 12kV 85x292 SSK with striker 125A 80N

Fuse 12kV 85x292 SSK with striker 125A 80N

Reference 3002043.125.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 125
Rated Voltage Un AC (V) 12000
Applicable standards IEC
Power loss (W) 135
Resistance (ohm) 4,8
Fuse Dimension (mm) 85x292
Melting I²t value (A²s) 39000
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 12000
Total clearing I²t @Un AC (A²s) 323000
Rated breaking capacity I1 AC (kA) 63000
Weight (gr) 3900
Price List €263.26/pc
Quantity
Fuse 24kV 53x442 back-up with striker 40A 80N

Fuse 24kV 53x442 back-up with striker 40A 80N

Reference 3000613.40.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 40
Rated Voltage Un AC (V) 10000
Applicable standards IEC
Power loss (W) 109
Resistance (ohm) 0,043
Fuse Dimension (mm) 53x442
Melting I²t value (A²s) 2200
Minimum breaking current (A) 140
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 8700
Total clearing I²t @Un AC (A²s) 25000
Rated breaking capacity I1 AC (kA) 63000
Weight (gr) 2290
Price List €105.39/pc
Quantity
lock Datasheet
Fuse 24kV 53x442 TV with striker 4A 80N

Fuse 24kV 53x442 TV with striker 4A 80N

Reference 3000613.4.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 4
Rated Voltage Un AC (V) 10000
Applicable standards IEC
Power loss (W) 22
Resistance (ohm) 0,95
Fuse Dimension (mm) 53x442
Melting I²t value (A²s) 31
Minimum breaking current (A) 32
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 8700
Total clearing I²t @Un AC (A²s) 90
Rated breaking capacity I1 AC (kA) 63000
Weight (gr) 2280
Price List €73.93/pc
Quantity
lock Datasheet
Fuse 24kV 53x442 back-up with striker 31,5A 80N

Fuse 24kV 53x442 back-up with striker 31,5A 80N

Reference 3000613.31,5.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 31,5
Rated Voltage Un AC (V) 10000
Applicable standards IEC
Power loss (W) 73
Resistance (ohm) 0,054
Fuse Dimension (mm) 53x442
Melting I²t value (A²s) 1400
Minimum breaking current (A) 110
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 8700
Total clearing I²t @Un AC (A²s) 16000
Rated breaking capacity I1 AC (kA) 63000
Weight (gr) 2400
Price List €99.62/pc
Quantity
lock Datasheet
Fuse 24kV 53x442 TV with striker 3A 80N

Fuse 24kV 53x442 TV with striker 3A 80N

Reference 3000613.3.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 3
Rated Voltage Un AC (V) 24000
Applicable standards IEC
Fuse Dimension (mm) 53x442
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 20880
Rated breaking capacity I1 AC (kA) 630000
Weight (gr) 2280
Price List €65.88/pc
Quantity
lock Datasheet
Fuse 24kV 53x442 TV with striker 3,15A 80N

Fuse 24kV 53x442 TV with striker 3,15A 80N

Reference 3000613.3,15.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 3,15
Rated Voltage Un AC (V) 10000
Applicable standards IEC
Power loss (W) 18
Resistance (ohm) 1,3
Fuse Dimension (mm) 53x442
Melting I²t value (A²s) 17
Minimum breaking current (A) 24
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 8700
Total clearing I²t @Un AC (A²s) 48
Rated breaking capacity I1 AC (kA) 63000
Weight (gr) 2283
Price List €65.88/pc
Quantity
lock Datasheet
Fuse 24kV 53x442 back-up with striker 25A 80N

Fuse 24kV 53x442 back-up with striker 25A 80N

Reference 3000613.25.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 25
Rated Voltage Un AC (V) 10000
Applicable standards IEC
Power loss (W) 56
Resistance (ohm) 0,066
Fuse Dimension (mm) 53x442
Melting I²t value (A²s) 920
Minimum breaking current (A) 90
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 8700
Total clearing I²t @Un AC (A²s) 11000
Rated breaking capacity I1 AC (kA) 63000
Weight (gr) 2325
Price List €89.59/pc
Quantity
lock Datasheet
Fuse 24kV 53x442 back-up with striker 20A 80N

Fuse 24kV 53x442 back-up with striker 20A 80N

Reference 3000613.20.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 20
Rated Voltage Un AC (V) 10000
Applicable standards IEC
Power loss (W) 46
Resistance (ohm) 0,086
Fuse Dimension (mm) 53x442
Melting I²t value (A²s) 545
Minimum breaking current (A) 70
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 8700
Total clearing I²t @Un AC (A²s) 7000
Rated breaking capacity I1 AC (kA) 63000
Weight (gr) 2260
Price List €76.67/pc
Quantity
lock Datasheet
Fuse 24kV 53x442 TV with striker 2A 80N

Fuse 24kV 53x442 TV with striker 2A 80N

Reference 3000613.2.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 2
Rated Voltage Un AC (V) 10000
Applicable standards IEC
Power loss (W) 15
Resistance (ohm) 2,85
Fuse Dimension (mm) 53x442
Melting I²t value (A²s) 3,2
Minimum breaking current (A) 16
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 8700
Total clearing I²t @Un AC (A²s) 9,8
Rated breaking capacity I1 AC (kA) 63000
Weight (gr) 2280
Price List €73.01/pc
Quantity
lock Datasheet
Fuse 24kV 53x442 TV with striker 2,5A 80N

Fuse 24kV 53x442 TV with striker 2,5A 80N

Reference 3000613.2,5.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 2,5
Rated Voltage Un AC (V) 10000
Applicable standards IEC
Power loss (W) 16
Resistance (ohm) 1,92
Fuse Dimension (mm) 53x442
Melting I²t value (A²s) 7,2
Minimum breaking current (A) 20
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 8700
Total clearing I²t @Un AC (A²s) 26
Rated breaking capacity I1 AC (kA) 63000
Weight (gr) 2300
Price List €65.88/pc
Quantity
lock Datasheet
Fuse 24kV 53x442 back-up with striker 16A 80N

Fuse 24kV 53x442 back-up with striker 16A 80N

Reference 3000613.16.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 16
Rated Voltage Un AC (V) 10000
Applicable standards IEC
Power loss (W) 57
Resistance (ohm) 0,169
Fuse Dimension (mm) 53x442
Melting I²t value (A²s) 140
Minimum breaking current (A) 56
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 8700
Total clearing I²t @Un AC (A²s) 3200
Rated breaking capacity I1 AC (kA) 63000
Weight (gr) 2320
Price List €74.70/pc
Quantity
lock Datasheet
Fuse 24kV 53x442 back-up with striker 10A 80N

Fuse 24kV 53x442 back-up with striker 10A 80N

Reference 3000613.10.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 10
Rated Voltage Un AC (V) 10000
Applicable standards IEC
Power loss (W) 44
Resistance (ohm) 0,352
Fuse Dimension (mm) 53x442
Melting I²t value (A²s) 68
Minimum breaking current (A) 34
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 8700
Total clearing I²t @Un AC (A²s) 880
Rated breaking capacity I1 AC (kA) 63000
Weight (gr) 2283
Price List €73.95/pc
Quantity
lock Datasheet
Fuse 24kV 53x442 TV without striker 2A

Fuse 24kV 53x442 TV without striker 2A

Reference 3000611.2.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 2
Rated Voltage Un AC (V) 24000
Applicable standards IEC
Fuse Dimension (mm) 53x442
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 20880
Rated breaking capacity I1 AC (kA) 63000
Weight (gr) 2270
Price List €73.04/pc
Quantity
lock Datasheet
Fuse 24kV 53x442 TV no striker 1A

Fuse 24kV 53x442 TV no striker 1A

Reference 3000611.1.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 1
Rated Voltage Un AC (V) 10000
Applicable standards IEC
Power loss (W) 8,6
Resistance (ohm) 6,45
Fuse Dimension (mm) 53x442
Melting I²t value (A²s) 0,63
Minimum breaking current (A) 8
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 8700
Total clearing I²t @Un AC (A²s) 1,8
Rated breaking capacity I1 AC (kA) 63000
Weight (gr) 2270
Price List €88.38/pc
Quantity
lock Datasheet
Fuse 24kV 53x442 TV without striker 0,8A

Fuse 24kV 53x442 TV without striker 0,8A

Reference 3000611.0,8.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 0,8
Rated Voltage Un AC (V) 24000
Applicable standards IEC
Fuse Dimension (mm) 53x442
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 20880
Rated breaking capacity I1 AC (kA) 63000
Weight (gr) 2422
Price List €514.68/pc
Quantity
lock Datasheet
Fuse 24kV 53x442 TV no striker 0,5A

Fuse 24kV 53x442 TV no striker 0,5A

Reference 3000611.0,5.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 0,5
Rated Voltage Un AC (V) 10000
Applicable standards IEC
Power loss (W) 11,2
Resistance (ohm) 40,55
Fuse Dimension (mm) 53x442
Melting I²t value (A²s) 1,6
Minimum breaking current (A) 5
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 8700
Total clearing I²t @Un AC (A²s) 5,9
Rated breaking capacity I1 AC (kA) 63000
Weight (gr) 2270
Price List €72.09/pc
Quantity
lock Datasheet
Fuse 24kV 53x442 back-up with striker 20A 80N

Fuse 24kV 53x442 back-up with striker 20A 80N

Reference 3000513.20.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 20
Rated Voltage Un AC (V) 24000
Applicable standards IEC
Power loss (W) 46
Resistance (ohm) 83
Fuse Dimension (mm) 53x442
Melting I²t value (A²s) 640
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 20880
Total clearing I²t @Un AC (A²s) 4800
Rated breaking capacity I1 AC (kA) 63000
Price List €519.96/pc
Quantity
lock Datasheet
Fuse 12kV 53x292 general purpose with striker 6,3A 80N

Fuse 12kV 53x292 general purpose with striker 6,3A 80N

Reference 3000493.6,3.0 - Manufacturer SIBA
Class HH G P
Rated current In (A) 6,3
Rated Voltage Un AC (V) 12000
Applicable standards IEC
Power loss (W) 7
Resistance (ohm) 150
Fuse Dimension (mm) 53x292
Melting I²t value (A²s) 110
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 12000
Total clearing I²t @Un AC (A²s) 900
Rated breaking capacity I1 AC (kA) 63000
Weight (gr) 1620
Price List €355.58/pc
Quantity
lock Datasheet
Fuse 12kV 53x292 back-up +striker no temp-limiting 40A 120N

Fuse 12kV 53x292 back-up +striker no temp-limiting 40A 120N

Reference 3000414.40.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 40
Rated Voltage Un AC (V) 12000
Applicable standards IEC
Power loss (W) 50
Resistance (ohm) 22
Fuse Dimension (mm) 53x292
Melting I²t value (A²s) 2900
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 12000
Total clearing I²t @Un AC (A²s) 19000
Rated breaking capacity I1 AC (kA) 63000
Weight (gr) 1640
Price List €109.29/pc
Quantity
lock Datasheet
Fuse 24kV 53x442 back-up with striker 25A 80N

Fuse 24kV 53x442 back-up with striker 25A 80N

Reference 3000513.25.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 25
Rated Voltage Un AC (V) 24000
Applicable standards IEC
Power loss (W) 56
Resistance (ohm) 62
Fuse Dimension (mm) 53x442
Melting I²t value (A²s) 1050
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 20880
Total clearing I²t @Un AC (A²s) 7500
Rated breaking capacity I1 AC (kA) 63000
Product available on request Ask for more information
Product added to compare.
Product added to wishlist
