All Products

Fuse SQB0 aR 1800V/2400VDC with switch adapter 6A

Fuse SQB0 aR 1800V/2400VDC with switch adapter 6A

Reference 9022126.6.0 - Manufacturer SIBA
Class aR
Rated current In (A) 6
Voltage of total I2t test 2400
Weight (g) 1780
Format Screw fixing
Dimension SQB0
Homologations IEC
Rated Voltage Un DC (V) 1800
Rated break.capacity I1 DC (A) 30000
Price List €240.40/pc
Quantity
lock Datasheet
Fuse SQB-DC92 gR 900VDC screw M10 250A

Fuse SQB-DC92 gR 900VDC screw M10 250A

Reference 9037020.250.0 - Manufacturer SIBA
Class gR
Rated current In (A) 250
Voltage of total I2t test 750
Weight (g) 1250
Format Screw fixing
Dimension DC92
Pre-arcing I2t value (A2s) 21500
Total I2t value (A2s) 141000
Homologations IEC
Power loss (W) 48
Rated Voltage Un DC (V) 900
Rated break.capacity I1 DC (A) 100000
Time costant L/R (ms) 100
Price List €489.23/pc
Quantity
lock Datasheet
Fuse SQB-DC92 aR 750VDC screw M10 with switch adapt 350A

Fuse SQB-DC92 aR 750VDC screw M10 with switch adapt 350A

Reference 9037026.350.0 - Manufacturer SIBA
Class aR
Rated current In (A) 350
Voltage of total I2t test 900
Weight (g) 1280
Format Screw fixing
Dimension DC92
Pre-arcing I2t value (A2s) 57100
Total I2t value (A2s) 751000
Homologations IEC
Power loss (W) 61
Rated Voltage Un DC (V) 750
Rated break.capacity I1 DC (A) 30000
Time costant L/R (ms) 40
Product available on request Ask for more information
Fuse NH3L 1500V DC aBat 500A

Fuse NH3L 1500V DC aBat 500A

Reference 9044325.500.0 - Manufacturer SIBA
Voltage of total I2t test 1500
Weight (g) 2000
Format NH knife contact
Dimension NH3L
Rated Voltage Un DC (V) 1500
Rated break.capacity I1 DC (A) 260000
Time costant L/R (ms) 3
Price List €2,013.15/pc
Quantity
lock Datasheet
Fuse SQB0 aR 1700V/2000VDC without indicator 80A

Fuse SQB0 aR 1700V/2000VDC without indicator 80A

Reference 9022225.80.0 - Manufacturer SIBA
Class aR
Rated current In (A) 80
Voltage of total I2t test 2000
Weight (g) 920
Format Screw fixing
Dimension SQB0
Pre-arcing I2t value (A2s) 328
Total I2t value (A2s) 2700
Power loss (W) 73
Rated Voltage Un DC (V) 1700
Rated break.capacity I1 DC (A) 30000
Time costant L/R (ms) 15
Price List €278.10/pc
Quantity
lock Datasheet
Fuse SQB0 aR 1000V/1200VDC without indicator 63A

Fuse SQB0 aR 1000V/1200VDC without indicator 63A

Reference 9022325.63.0 - Manufacturer SIBA
Class aR
Rated current In (A) 63
Voltage of total I2t test 1200
Weight (g) 621
Format Screw fixing
Dimension SQB0
Pre-arcing I2t value (A2s) 250
Total I2t value (A2s) 2250
Homologations IEC
Power loss (W) 34
Rated Voltage Un DC (V) 900
Rated break.capacity I1 DC (A) 300000
Time costant L/R (ms) 15
Price List €2,170.88/pc
Quantity
lock Datasheet
Fuse SQB-DC91 gR 900VDC knife contacts 166mm 160A

Fuse SQB-DC91 gR 900VDC knife contacts 166mm 160A

Reference 9031020.160.0 - Manufacturer SIBA
Class gR
Rated current In (A) 160
Voltage of total I2t test 750
Weight (g) 1000
Format Screw fixing
Dimension DC91
Pre-arcing I2t value (A2s) 9500
Total I2t value (A2s) 51000
Homologations IEC
Power loss (W) 28
Rated Voltage Un DC (V) 900
Rated break.capacity I1 DC (A) 100000
Time costant L/R (ms) 100
Price List €2,882.61/pc
Quantity
lock Datasheet
Fuse SQB-DC92 gR 900VDC knife contacts 171mm 315A

Fuse SQB-DC92 gR 900VDC knife contacts 171mm 315A

Reference 9032020.315.0 - Manufacturer SIBA
Class gR
Rated current In (A) 315
Voltage of total I2t test 900
Weight (g) 1340
Format Screw fixing
Dimension DC92
Pre-arcing I2t value (A2s) 38000
Total I2t value (A2s) 349000
Homologations IEC
Power loss (W) 57
Rated Voltage Un DC (V) 900
Rated break.capacity I1 DC (A) 100000
Time costant L/R (ms) 40
Price List €496.90/pc
Quantity
lock Datasheet
Fuse 1500VDC SQB-DC154 aR 4xM10 1250A

Fuse 1500VDC SQB-DC154 aR 4xM10 1250A

Reference 9039325.1250.0 - Manufacturer SIBA
Class aR
Rated current In (A) 1250
Rated break.capacity I1 AC (A) 100000
Voltage of total I2t test 1600
Format Screw fixing
Dimension SQB-DC154
Pre-arcing I2t value (A2s) 720000
Total I2t value (A2s) 3750000
Power loss (W) 160
Rated Voltage Un DC (V) 1600
Rated break.capacity I1 DC (A) 260000
Time costant L/R (ms) 3
Price List €516.28/pc
Quantity
lock Datasheet
Fuse holder 39,6x254mm

Fuse holder 39,6x254mm

Reference 9110001.X.0 - Manufacturer SIBA
Rated Voltage Un AC (V) 3000
Weight (g) 1320
Fuses format Cylindrical
Fuses dimension 39.6x254mm
Number of phase 1
Price List €178.02/pc
Quantity
Fuse SQB1 110mm aR 690V top indicator 630A

Fuse SQB1 110mm aR 690V top indicator 630A

Reference 2061332.630.0 - Manufacturer SIBA
Class aR
Rated current In (A) 630
Rated Voltage Un AC (V) 690
Rated break.capacity I1 AC (A) 200000
Voltage of total I2t test 660
Weight (g) 450
Format Screw fixing
Dimension SQB1-110mm
Pre-arcing I2t value (A2s) 61000
Total I2t value (A2s) 370000
Power loss (W) 80
Price List €146.96/pc
Quantity
lock Datasheet
Fuse SQB1 110mm aR 690V lateral switch adapter 315A

Fuse SQB1 110mm aR 690V lateral switch adapter 315A

Reference 2061532.315.0 - Manufacturer SIBA
Class aR
Rated current In (A) 315
Rated Voltage Un AC (V) 690
Rated break.capacity I1 AC (A) 200000
Voltage of total I2t test 660
Weight (g) 480
Format Screw fixing
Dimension SQB1-110mm
Pre-arcing I2t value (A2s) 6600
Total I2t value (A2s) 39000
Power loss (W) 59
Price List €148.51/pc
Quantity
lock Datasheet
Fuse SQB2 110mm aR 690V top switch adapter 700A

Fuse SQB2 110mm aR 690V top switch adapter 700A

Reference 2062432.700.0 - Manufacturer SIBA
Class aR
Rated current In (A) 700
Rated Voltage Un AC (V) 690
Rated break.capacity I1 AC (A) 200000
Voltage of total I2t test 660
Weight (g) 610
Format Screw fixing
Dimension SQB2-110mm
Pre-arcing I2t value (A2s) 74000
Total I2t value (A2s) 410000
Power loss (W) 99
Price List €251.59/pc
Quantity
lock Datasheet
Fuse SQB2 US-Short aR 690V top indicator 900A

Fuse SQB2 US-Short aR 690V top indicator 900A

Reference 2062732.900.0 - Manufacturer SIBA
Class aR
Rated current In (A) 900
Rated Voltage Un AC (V) 690
Rated break.capacity I1 AC (A) 200000
Voltage of total I2t test 660
Weight (g) 600
Format Screw fixing
Dimension SQB2 US-Short
Pre-arcing I2t value (A2s) 170000
Total I2t value (A2s) 950000
Power loss (W) 111
Price List €115.81/pc
Quantity
lock Datasheet
Fuse SQB2 US-Long aR 690V without indicator 800A

Fuse SQB2 US-Long aR 690V without indicator 800A

Reference 2062931.800.0 - Manufacturer SIBA
Class aR
Rated current In (A) 800
Rated Voltage Un AC (V) 690
Rated break.capacity I1 AC (A) 200000
Voltage of total I2t test 660
Weight (g) 2000
Format Screw fixing
Dimension SQB2 US-Long
Pre-arcing I2t value (A2s) 100000
Total I2t value (A2s) 580000
Power loss (W) 108
Price List €226.67/pc
Quantity
lock Datasheet
Fuse SQB1 screw M8 aR 690V lateral switch adapter 450A

Fuse SQB1 screw M8 aR 690V lateral switch adapter 450A

Reference 2066132.450.0 - Manufacturer SIBA
Class aR
Rated current In (A) 450
Rated Voltage Un AC (V) 690
Rated break.capacity I1 AC (A) 200000
Voltage of total I2t test 660
Weight (g) 420
Format Screw fixing
Dimension SQB1 screw M8
Pre-arcing I2t value (A2s) 22000
Total I2t value (A2s) 130000
Power loss (W) 70
Price List €207.70/pc
Quantity
lock Datasheet
Fuse SQB2 screw M10 aR 690V top indicator 900A

Fuse SQB2 screw M10 aR 690V top indicator 900A

Reference 2067032.900.0 - Manufacturer SIBA
Class aR
Rated current In (A) 900
Rated Voltage Un AC (V) 690
Rated break.capacity I1 AC (A) 200000
Voltage of total I2t test 660
Weight (g) 510
Format Screw fixing
Dimension SQB2 screw M10
Pre-arcing I2t value (A2s) 170000
Total I2t value (A2s) 950000
Power loss (W) 111
Price List €283.64/pc
Quantity
lock Datasheet
Fuse SQB2 US-UNC 3/8 690V without indicator 315A

Fuse SQB2 US-UNC 3/8 690V without indicator 315A

Reference 2067331.315.0 - Manufacturer SIBA
Class aR
Rated current In (A) 315
Rated Voltage Un AC (V) 690
Rated break.capacity I1 AC (A) 200000
Voltage of total I2t test 660
Weight (g) 600
Format Screw fixing
Dimension SQB2 US-UNC 3/8
Pre-arcing I2t value (A2s) 7800
Total I2t value (A2s) 45000
Homologations IEC
Power loss (W) 56
Product available on request Ask for more information
Fuse SQB3 body59mm M12 550V lateral switch adapter 2000A

Fuse SQB3 body59mm M12 550V lateral switch adapter 2000A

Reference 2068152.2000.0 - Manufacturer SIBA
Class aR
Rated current In (A) 2000
Rated Voltage Un AC (V) 550
Rated break.capacity I1 AC (A) 200000
Voltage of total I2t test 550
Weight (g) 930
Format Screw fixing
Dimension SQB3 screw M12
Pre-arcing I2t value (A2s) 1000000
Total I2t value (A2s) 4950000
Homologations IEC
Power loss (W) 250
Price List €439.48/pc
Quantity
lock Datasheet
Fuse SQB3 US-UNC 1/2 690V without indicator 700A

Fuse SQB3 US-UNC 1/2 690V without indicator 700A

Reference 2068331.700.0 - Manufacturer SIBA
Class aR
Rated current In (A) 700
Rated Voltage Un AC (V) 690
Rated break.capacity I1 AC (A) 200000
Voltage of total I2t test 660
Weight (g) 2000
Format Screw fixing
Dimension SQB3 US-UNC 1/2
Pre-arcing I2t value (A2s) 50000
Total I2t value (A2s) 300000
Power loss (W) 113
Price List €1,178.96/pc
Quantity
lock Datasheet
Fuse SQB3 US-UNC 1/2 690V lateral switch adapter 630A

Fuse SQB3 US-UNC 1/2 690V lateral switch adapter 630A

Reference 2068432.630.0 - Manufacturer SIBA
Class aR
Rated current In (A) 630
Rated Voltage Un AC (V) 690
Rated break.capacity I1 AC (A) 200000
Voltage of total I2t test 660
Weight (g) 853
Format Screw fixing
Dimension SQB3 US-UNC 1/2
Pre-arcing I2t value (A2s) 32000
Total I2t value (A2s) 190000
Power loss (W) 108
Price List €236.62/pc
Quantity
lock Datasheet
Fuse 2x SQB3 M12 aR 690V lateral switch adapter 1800A

Fuse 2x SQB3 M12 aR 690V lateral switch adapter 1800A

Reference 2068832.1800.0 - Manufacturer SIBA
Class aR
Rated current In (A) 1800
Rated Voltage Un AC (V) 690
Rated break.capacity I1 AC (A) 200000
Voltage of total I2t test 660
Weight (g) 2000
Format Screw fixing
Dimension 2x SQB3 screw M12
Pre-arcing I2t value (A2s) 460000
Total I2t value (A2s) 2640000
Homologations IEC
Power loss (W) 252
Price List €808.03/pc
Quantity
lock Datasheet
Fuse SQB4 4screws aR 690V lateral switch adapter 2000A

Fuse SQB4 4screws aR 690V lateral switch adapter 2000A

Reference 2069532.2000.0 - Manufacturer SIBA
Class aR
Rated current In (A) 2000
Rated Voltage Un AC (V) 690
Rated break.capacity I1 AC (A) 120000
Voltage of total I2t test 690
Weight (g) 2000
Format Screw fixing
Dimension SQB4 screw M10
Pre-arcing I2t value (A2s) 596000
Total I2t value (A2s) 3600000
Homologations IEC
Power loss (W) 166
Price List €858.00/pc
Quantity
lock Datasheet
Fuse SQB2 US-Long aR 1250V lateral switch adapter 250A

Fuse SQB2 US-Long aR 1250V lateral switch adapter 250A

Reference 2072832.250.0 - Manufacturer SIBA
Class aR
Rated current In (A) 250
Rated Voltage Un AC (V) 1250
Rated break.capacity I1 AC (A) 100000
Voltage of total I2t test 1000
Weight (g) 2000
Format Screw fixing
Dimension SQB2 US-Long
Pre-arcing I2t value (A2s) 8200
Total I2t value (A2s) 45000
Power loss (W) 55
Price List €1,211.53/pc
Quantity
lock Datasheet
Filter by
Manufacturer
Class
Rated Voltage Un AC (V)
Series name
more... less
Rated Voltage Un DC (V)
Rated insultaion voltage AC (V)
Rated insulated voltage DC (V)
Fuses format
Fuses dimension
Inside diameter (mm)
Distance (mm)
Homologations
Product added to compare.
Product added to wishlist
