SPK-385-12,5-1(S) - SPD 385V T1+2 2+0 with microswitch
SPK-385-12,5-1(S) - SPD 385V T1+2 2+0 with microswitch

SPK-385-12,5-1(S) - SPD 385V T1+2 2+0 with microswitch

Reference: U64.255.90.0.0  -  Manufacturer: TechnoTeam
€299.94 /pc VAT excl.

Product Details

Rated Voltage Un AC (V)
230
Applicable standards
IEC
Type
1+2
Protection level Up (kV)
1,8
Remote contact
YES
Housing
Plug-in modules
Short circuit current rating Isccr kA
25
Impulse Discharge Current kA (Iimp 10/350us)
12,5
Nominal Dischiarge current kA (In 8/20us)
20
Maximum Discharge Current kA (Imax 8/20μs)
50
Maximum Continuous Operating Voltage AC Uc (V)
385
