SPH-150-40-4(S) - SPD 150V T2 4+0 with microswitch
SPH-150-40-4(S) - SPD 150V T2 4+0 with microswitch

SPH-150-40-4(S) - SPD 150V T2 4+0 with microswitch

Reference: X79.657.66.0.0  -  Manufacturer: TechnoTeam
€547.72 /pc VAT excl.

Product Details

Rated Voltage Un AC (V)
120
Applicable standards
IEC
Type
2
Protection level Up (kV)
1
Remote contact
YES
Housing
Plug-in modules
Series name
SPH-150-40
Short circuit current rating Isccr kA
25
Nominal Dischiarge current kA (In 8/20us)
20
Maximum Discharge Current kA (Imax 8/20μs)
40
Maximum Continuous Operating Voltage AC Uc (V)
150
