AB22 - Fuse 22x65 1000VDC aBat 80A
AB22 - Fuse 22x65 1000VDC aBat 80A

AB22 - Fuse 22x65 1000VDC aBat 80A

Reference: 993.797.75.0.0  -  Manufacturer: FAULTRAP
Product available on request
Ask for more information

Product Details

Class
aBat
Rated current In (A)
80
Applicable standards
IEC
Power loss (W)
13.5
Rated Voltage Un DC (V)
1000
Time costant L/R (ms)
1-3
Series name
AB22
Rated breaking capacity I1 DC (kA)
10
Fuse Dimension (mm)
22x65
Melting I²t value (A²s)
3030
Minimum breaking current (A)
640
Fuse Connection/Terminal type
Cylindrical
Total clearing I²t @Un DC (A²s)
16600
