20PV10 - Fuse 2000VDC gPV 10x85 8A
20PV10 - Fuse 2000VDC gPV 10x85 8A

20PV10 - Fuse 2000VDC gPV 10x85 8A

Reference: 797.476.09.0.0  -  Manufacturer: FAULTRAP
Product available on request
Ask for more information

Product Details

Class
gPV
Rated current In (A)
8
Applicable standards
IEC
Power loss (W)
2,4
Rated Voltage Un DC (V)
2000
Time costant L/R (ms)
1-3
Series name
20PV10
Rated breaking capacity I1 DC (kA)
50
Fuse Dimension (mm)
10x85
Melting I²t value (A²s)
193
Fuse Connection/Terminal type
Cylindrical
