PV22 - Fuse 22x65mm 1500VDC gPV UL 30A
PV22 - Fuse 22x65mm 1500VDC gPV UL 30A

PV22 - Fuse 22x65mm 1500VDC gPV UL 30A

Reference: 693.945.08.0.0  -  Manufacturer: FAULTRAP
Product available on request
Ask for more information

Product Details

Class
gPV
Rated current In (A)
30
Applicable standards
UL
Power loss (W)
7
Rated Voltage Un DC (V)
1500
Time costant L/R (ms)
3
Series name
PV22
Rated breaking capacity I1 DC (kA)
10000
Fuse Dimension (mm)
22x65
Melting I²t value (A²s)
230
Fuse Connection/Terminal type
Cylindrical
Voltage of total clearing I2t test
1500
Total clearing I²t @Un AC (A²s)
1800
