10TD - Fuse 10x38 400VAC aM/aR 20A
10TD - Fuse 10x38 400VAC aM/aR 20A

10TD - Fuse 10x38 400VAC aM/aR 20A

Reference: 651.340.87.0.0  -  Manufacturer: FAULTRAP
Product available on request
Ask for more information

Product Details

Class
aM, aR
Rated current In (A)
20
Rated Voltage Un AC (V)
400
Applicable standards
IEC, UL
Series name
10TD
Fuse Dimension (mm)
10x38
Melting I²t value (A²s)
960
Fuse Connection/Terminal type
Cylindrical
Voltage of total clearing I2t test
400
Total clearing I²t @Un AC (A²s)
2460
Rated breaking capacity I1 AC (kA)
50000

Accessories
