10TD - Fuse 10x38 500VAC aM/aR 4A
10TD - Fuse 10x38 500VAC aM/aR 4A

10TD - Fuse 10x38 500VAC aM/aR 4A

Reference: 598.660.25.0.0  -  Manufacturer: FAULTRAP
Product available on request
Ask for more information

Product Details

Class
aM, aR
Rated current In (A)
4
Rated Voltage Un AC (V)
500
Applicable standards
IEC, UL
Series name
10TD
Fuse Dimension (mm)
10x38
Melting I²t value (A²s)
92
Fuse Connection/Terminal type
Cylindrical
Voltage of total clearing I2t test
500
Total clearing I²t @Un AC (A²s)
211
Rated breaking capacity I1 AC (kA)
50000
