PV22 - Fuse 22x65mm 1500VDC gPV UL 25A
PV22 - Fuse 22x65mm 1500VDC gPV UL 25A

PV22 - Fuse 22x65mm 1500VDC gPV UL 25A

Reference: 568.895.42.0.0  -  Manufacturer: FAULTRAP
Product available on request
Ask for more information

Product Details

Class
gPV
Rated current In (A)
25
Applicable standards
UL
Power loss (W)
6,5
Rated Voltage Un DC (V)
1500
Time costant L/R (ms)
3
Series name
PV22
Rated breaking capacity I1 DC (kA)
10000
Fuse Dimension (mm)
22x65
Melting I²t value (A²s)
130
Fuse Connection/Terminal type
Cylindrical
Voltage of total clearing I2t test
1500
Total clearing I²t @Un AC (A²s)
1400
