10TD - Fuse 10x38 500VAC aM/aR 12A
10TD - Fuse 10x38 500VAC aM/aR 12A

10TD - Fuse 10x38 500VAC aM/aR 12A

Reference: 445.872.40.0.0  -  Manufacturer: FAULTRAP
Product available on request
Ask for more information

Product Details

Class
aM, aR
Rated current In (A)
12
Rated Voltage Un AC (V)
500
Applicable standards
IEC, UL
Series name
10TD
Fuse Dimension (mm)
10x38
Melting I²t value (A²s)
385
Fuse Connection/Terminal type
Cylindrical
Voltage of total clearing I2t test
500
Total clearing I²t @Un AC (A²s)
1160
Rated breaking capacity I1 AC (kA)
50000

Accessories
