Fuse DIN000 80mm aR 690V UL with indicator, w/o lug 100A
Fuse DIN000 80mm aR 690V UL with indicator, w/o lug 100A

Fuse DIN000 80mm aR 690V UL with indicator, w/o lug 100A

Reference: 2028220.100.0  -  Manufacturer: SIBA
€53.75 /pc VAT excl.

This product is only sold in boxes of 6 pcs

Product Details

Class
aR
Rated current In (A)
100
Rated Voltage Un AC (V)
690
Dimension
000
Applicable standards
IEC, UL
Power loss (W)
22
Melting I²t value (A²s)
730
Fuse Connection/Terminal type
Screw fixing
Fixing connection centres (mm)
80
Voltage of total clearing I2t test
660
Total clearing I²t @Un AC (A²s)
4000
Rated breaking capacity I1 AC (kA)
200000
Weight (gr)
126
