Fuse SMD 2,6x6,1 F 125V UL 2A 7016974.2

Fuse SMD 2,6x6,1 F 125V UL 2A 7016974.2

Reference 157000.2.0 - Manufacturer SIBA
Class F
Rated current In (A) 2
Rated Voltage Un AC (V) 125
Applicable standards UL
Voltage drop (mV) 100
Rated Voltage Un DC (V) 125
Fuse Dimension (mm) 2,6x6,1
Melting I²t value (A²s) 0,57
Fuse Connection/Terminal type SMD
Voltage of total clearing I2t test 125
Rated breaking capacity I1 AC (kA) 50
Weight (gr) 1
Price List €0.67/pc
Quantity
lock Datasheet
Fuse SMD 2,6x6,1 F 125V UL 3,5A 7016974.3,5

Fuse SMD 2,6x6,1 F 125V UL 3,5A 7016974.3,5

Reference 157000.3,5.0 - Manufacturer SIBA
Class F
Rated current In (A) 3,5
Rated Voltage Un AC (V) 125
Applicable standards UL
Voltage drop (mV) 100
Rated Voltage Un DC (V) 125
Fuse Dimension (mm) 2,6x6,1
Melting I²t value (A²s) 2,5
Fuse Connection/Terminal type SMD
Voltage of total clearing I2t test 125
Rated breaking capacity I1 AC (kA) 50
Weight (gr) 1
Price List €0.67/pc
Quantity
lock Datasheet
Fuse SMD 2,6x6,1 F 125V UL 3A 7016974.3

Fuse SMD 2,6x6,1 F 125V UL 3A 7016974.3

Reference 157000.3.0 - Manufacturer SIBA
Class F
Rated current In (A) 3
Rated Voltage Un AC (V) 125
Applicable standards UL
Voltage drop (mV) 100
Rated Voltage Un DC (V) 125
Fuse Dimension (mm) 2,6x6,1
Melting I²t value (A²s) 1,5
Fuse Connection/Terminal type SMD
Voltage of total clearing I2t test 125
Rated breaking capacity I1 AC (kA) 50
Weight (gr) 1
Price List €0.67/pc
Quantity
lock Datasheet
Fuse SMD 2,6x6,1 F 125V UL 4A 7016974.4

Fuse SMD 2,6x6,1 F 125V UL 4A 7016974.4

Reference 157000.4.0 - Manufacturer SIBA
Class F
Rated current In (A) 4
Rated Voltage Un AC (V) 125
Applicable standards UL
Voltage drop (mV) 100
Rated Voltage Un DC (V) 125
Fuse Dimension (mm) 2,6x6,1
Melting I²t value (A²s) 3,3
Fuse Connection/Terminal type SMD
Voltage of total clearing I2t test 125
Rated breaking capacity I1 AC (kA) 50
Weight (gr) 1
Price List €0.67/pc
Quantity
lock Datasheet
Fuse SMD 2,6x6,1 F 125V UL 5A 7016974.5

Fuse SMD 2,6x6,1 F 125V UL 5A 7016974.5

Reference 157000.5.0 - Manufacturer SIBA
Class F
Rated current In (A) 5
Rated Voltage Un AC (V) 125
Applicable standards UL
Voltage drop (mV) 90
Rated Voltage Un DC (V) 125
Fuse Dimension (mm) 2,6x6,1
Melting I²t value (A²s) 6,2
Fuse Connection/Terminal type SMD
Voltage of total clearing I2t test 125
Rated breaking capacity I1 AC (kA) 50
Weight (gr) 1
Price List €0.67/pc
Quantity
lock Datasheet
Fuse SMD 4,6x6,1 F 145V UL 6,3A 7016974.6,3

Fuse SMD 4,6x6,1 F 145V UL 6,3A 7016974.6,3

Reference 157000.6,3.0 - Manufacturer SIBA
Class F
Rated current In (A) 6,3
Rated Voltage Un AC (V) 125
Applicable standards UL
Voltage drop (mV) 90
Fuse Dimension (mm) 2,6x6,1
Melting I²t value (A²s) 9,1
Fuse Connection/Terminal type SMD
Voltage of total clearing I2t test 125
Rated breaking capacity I1 AC (kA) 50
Weight (gr) 1
Price List €2.12/pc
Quantity
lock Datasheet
Fuse SMD 2,6x6,1 F 125V UL 7A 7016974.7

Fuse SMD 2,6x6,1 F 125V UL 7A 7016974.7

Reference 157000.7.0 - Manufacturer SIBA
Class F
Rated current In (A) 7
Rated Voltage Un AC (V) 125
Applicable standards UL
Voltage drop (mV) 90
Rated Voltage Un DC (V) 125
Fuse Dimension (mm) 2,6x6,1
Melting I²t value (A²s) 11
Fuse Connection/Terminal type SMD
Voltage of total clearing I2t test 125
Rated breaking capacity I1 AC (kA) 50
Weight (gr) 1
Price List €0.67/pc
Quantity
lock Datasheet
Fuse SMD 2,6x6,1 125VAC/DC T UL 0,25A 7016975.0,25

Fuse SMD 2,6x6,1 125VAC/DC T UL 0,25A 7016975.0,25

Reference 158000.0,25.0 - Manufacturer SIBA
Class T
Rated current In (A) 0,25
Rated Voltage Un AC (V) 125
Applicable standards UL
Voltage drop (mV) 280
Fuse Dimension (mm) 2,6x6,1
Melting I²t value (A²s) 0,08
Fuse Connection/Terminal type SMD
Voltage of total clearing I2t test 125
Rated breaking capacity I1 AC (kA) 50
Price List €3.03/pc
Quantity
lock Datasheet
Fuse SMD 2,6x6,1 125VAC/DC T UL 0,315A 7016975.0,315

Fuse SMD 2,6x6,1 125VAC/DC T UL 0,315A 7016975.0,315

Reference 158000.0,315.0 - Manufacturer SIBA
Class T
Rated current In (A) 0,315
Rated Voltage Un AC (V) 125
Applicable standards UL
Voltage drop (mV) 260
Rated Voltage Un DC (V) 125
Rated breaking capacity I1 DC (kA) 50
Fuse Dimension (mm) 2,6x6,1
Melting I²t value (A²s) 0,16
Fuse Connection/Terminal type SMD
Voltage of total clearing I2t test 125
Rated breaking capacity I1 AC (kA) 50
Weight (gr) 1
Price List €3.03/pc
Quantity
lock Datasheet
Fuse SMD 2,6x6,1 125VAC/DC T UL 0,375A 7016975.0,375

Fuse SMD 2,6x6,1 125VAC/DC T UL 0,375A 7016975.0,375

Reference 158000.0,375.0 - Manufacturer SIBA
Class T
Rated current In (A) 0,375
Rated Voltage Un AC (V) 125
Applicable standards UL
Voltage drop (mV) 230
Rated Voltage Un DC (V) 125
Rated breaking capacity I1 DC (kA) 50
Fuse Dimension (mm) 2,6x6,1
Melting I²t value (A²s) 0,35
Fuse Connection/Terminal type SMD
Voltage of total clearing I2t test 125
Rated breaking capacity I1 AC (kA) 50
Weight (gr) 1
Price List €0.68/pc
Quantity
lock Datasheet
Fuse SMD 2,6x6,1 125VAC/DC T UL 0,4A 7016975.0,4

Fuse SMD 2,6x6,1 125VAC/DC T UL 0,4A 7016975.0,4

Reference 158000.0,4.0 - Manufacturer SIBA
Class T
Rated current In (A) 0,4
Rated Voltage Un AC (V) 125
Applicable standards UL
Voltage drop (mV) 220
Fuse Dimension (mm) 2,6x6,1
Melting I²t value (A²s) 0,35
Fuse Connection/Terminal type SMD
Voltage of total clearing I2t test 125
Rated breaking capacity I1 AC (kA) 50
Price List €0.68/pc
Quantity
lock Datasheet
Fuse SMD 2,6x6,1 125VAC/DC T UL 0,5A 7016975.0,5

Fuse SMD 2,6x6,1 125VAC/DC T UL 0,5A 7016975.0,5

Reference 158000.0,5.0 - Manufacturer SIBA
Class T
Rated current In (A) 0,5
Rated Voltage Un AC (V) 125
Applicable standards UL
Voltage drop (mV) 200
Fuse Dimension (mm) 2,6x6,1
Melting I²t value (A²s) 1
Fuse Connection/Terminal type SMD
Voltage of total clearing I2t test 125
Rated breaking capacity I1 AC (kA) 50
Price List €0.68/pc
Quantity
lock Datasheet
Fuse SMD 2,6x6,1 125VAC/DC T UL 0,63A 7016975.0,63

Fuse SMD 2,6x6,1 125VAC/DC T UL 0,63A 7016975.0,63

Reference 158000.0,63.0 - Manufacturer SIBA
Class T
Rated current In (A) 0,63
Rated Voltage Un AC (V) 125
Applicable standards UL
Voltage drop (mV) 200
Fuse Dimension (mm) 2,6x6,1
Melting I²t value (A²s) 1,4
Fuse Connection/Terminal type SMD
Voltage of total clearing I2t test 125
Rated breaking capacity I1 AC (kA) 50
Price List €0.68/pc
Quantity
lock Datasheet
Fuse SMD 2,6x6,1 125VAC/DC T UL 0,75A 7016975.0,75

Fuse SMD 2,6x6,1 125VAC/DC T UL 0,75A 7016975.0,75

Reference 158000.0,75.0 - Manufacturer SIBA
Class T
Rated current In (A) 0,75
Rated Voltage Un AC (V) 125
Applicable standards UL
Voltage drop (mV) 190
Fuse Dimension (mm) 2,6x6,1
Melting I²t value (A²s) 1,5
Fuse Connection/Terminal type SMD
Voltage of total clearing I2t test 125
Rated breaking capacity I1 AC (kA) 50
Price List €0.68/pc
Quantity
lock Datasheet
Fuse SMD 2,6x6,1 125VAC/DC T UL 0,8A 7016975.0,8

Fuse SMD 2,6x6,1 125VAC/DC T UL 0,8A 7016975.0,8

Reference 158000.0,8.0 - Manufacturer SIBA
Class T
Rated current In (A) 0,8
Rated Voltage Un AC (V) 125
Applicable standards UL
Voltage drop (mV) 170
Fuse Dimension (mm) 2,6x6,1
Melting I²t value (A²s) 1,5
Fuse Connection/Terminal type SMD
Voltage of total clearing I2t test 125
Rated breaking capacity I1 AC (kA) 50
Price List €0.68/pc
Quantity
lock Datasheet
Fuse SMD 2,6x6,1 125VAC/DC T UL 1,25A 7016975.1,25

Fuse SMD 2,6x6,1 125VAC/DC T UL 1,25A 7016975.1,25

Reference 158000.1,25.0 - Manufacturer SIBA
Class T
Rated current In (A) 1,25
Rated Voltage Un AC (V) 125
Applicable standards UL
Voltage drop (mV) 150
Rated Voltage Un DC (V) 125
Rated breaking capacity I1 DC (kA) 50
Fuse Dimension (mm) 2,6x6,1
Melting I²t value (A²s) 4,6
Fuse Connection/Terminal type SMD
Voltage of total clearing I2t test 125
Rated breaking capacity I1 AC (kA) 50
Weight (gr) 1
Price List €0.68/pc
Quantity
lock Datasheet
Fuse SMD 2,6x6,1 125VAC/DC T UL 1,5A 7016975.1,5

Fuse SMD 2,6x6,1 125VAC/DC T UL 1,5A 7016975.1,5

Reference 158000.1,5.0 - Manufacturer SIBA
Class T
Rated current In (A) 1,5
Rated Voltage Un AC (V) 125
Applicable standards UL
Voltage drop (mV) 130
Rated Voltage Un DC (V) 125
Rated breaking capacity I1 DC (kA) 50
Fuse Dimension (mm) 2,6x6,1
Melting I²t value (A²s) 4,8
Fuse Connection/Terminal type SMD
Voltage of total clearing I2t test 125
Rated breaking capacity I1 AC (kA) 50
Weight (gr) 1
Price List €0.68/pc
Quantity
lock Datasheet
Fuse SMD 2,6x6,1 125VAC/DC T UL 1,6A 7016975.1,6

Fuse SMD 2,6x6,1 125VAC/DC T UL 1,6A 7016975.1,6

Reference 158000.1,6.0 - Manufacturer SIBA
Class T
Rated current In (A) 1,6
Rated Voltage Un AC (V) 125
Applicable standards UL
Voltage drop (mV) 130
Rated Voltage Un DC (V) 125
Rated breaking capacity I1 DC (kA) 50
Fuse Dimension (mm) 2,6x6,1
Melting I²t value (A²s) 4,8
Fuse Connection/Terminal type SMD
Voltage of total clearing I2t test 125
Rated breaking capacity I1 AC (kA) 50
Weight (gr) 1
Price List €0.68/pc
Quantity
lock Datasheet
Fuse SMD 2,6x6,1 125VAC/DC T UL 1A 7016975.1

Fuse SMD 2,6x6,1 125VAC/DC T UL 1A 7016975.1

Reference 158000.1.0 - Manufacturer SIBA
Class T
Rated current In (A) 1
Rated Voltage Un AC (V) 125
Applicable standards UL
Voltage drop (mV) 150
Rated Voltage Un DC (V) 125
Rated breaking capacity I1 DC (kA) 50
Fuse Dimension (mm) 2,6x6,1
Melting I²t value (A²s) 4
Fuse Connection/Terminal type SMD
Voltage of total clearing I2t test 125
Rated breaking capacity I1 AC (kA) 50
Weight (gr) 1
Price List €0.68/pc
Quantity
lock Datasheet
Fuse SMD 2,6x6,1 125VAC/DC T UL 2,5A 7016975.2,5

Fuse SMD 2,6x6,1 125VAC/DC T UL 2,5A 7016975.2,5

Reference 158000.2,5.0 - Manufacturer SIBA
Class T
Rated current In (A) 2,5
Rated Voltage Un AC (V) 125
Applicable standards UL
Voltage drop (mV) 120
Rated Voltage Un DC (V) 125
Rated breaking capacity I1 DC (kA) 50
Fuse Dimension (mm) 2,6x6,1
Melting I²t value (A²s) 16
Fuse Connection/Terminal type SMD
Voltage of total clearing I2t test 125
Rated breaking capacity I1 AC (kA) 50
Weight (gr) 1
Price List €0.68/pc
Quantity
lock Datasheet
Fuse SMD 2,6x6,1 125VAC/DC T UL 2A 7016975.2

Fuse SMD 2,6x6,1 125VAC/DC T UL 2A 7016975.2

Reference 158000.2.0 - Manufacturer SIBA
Class T
Rated current In (A) 2
Rated Voltage Un AC (V) 125
Applicable standards UL
Voltage drop (mV) 120
Rated Voltage Un DC (V) 125
Rated breaking capacity I1 DC (kA) 50
Fuse Dimension (mm) 2,6x6,1
Melting I²t value (A²s) 8,6
Fuse Connection/Terminal type SMD
Voltage of total clearing I2t test 125
Rated breaking capacity I1 AC (kA) 50
Weight (gr) 1
Price List €0.68/pc
Quantity
lock Datasheet
Fuse SMD 2,6x6,1 125VAC/DC T UL 3,15A 7016975.3,15

Fuse SMD 2,6x6,1 125VAC/DC T UL 3,15A 7016975.3,15

Reference 158000.3,15.0 - Manufacturer SIBA
Class T
Rated current In (A) 3,15
Rated Voltage Un AC (V) 125
Applicable standards UL
Voltage drop (mV) 100
Rated Voltage Un DC (V) 125
Rated breaking capacity I1 DC (kA) 50
Fuse Dimension (mm) 2,6x6,1
Melting I²t value (A²s) 24
Fuse Connection/Terminal type SMD
Voltage of total clearing I2t test 125
Rated breaking capacity I1 AC (kA) 50
Weight (gr) 1
Price List €0.68/pc
Quantity
lock Datasheet
Fuse SMD 2,6x6,1 125VAC/DC T UL 3,5A 7016975.3,5

Fuse SMD 2,6x6,1 125VAC/DC T UL 3,5A 7016975.3,5

Reference 158000.3,5.0 - Manufacturer SIBA
Class T
Rated current In (A) 3,5
Rated Voltage Un AC (V) 125
Applicable standards UL
Voltage drop (mV) 100
Fuse Dimension (mm) 2,6x6,1
Melting I²t value (A²s) 38
Fuse Connection/Terminal type SMD
Voltage of total clearing I2t test 125
Rated breaking capacity I1 AC (kA) 50
Weight (gr) 1
Price List €0.68/pc
Quantity
lock Datasheet
Fuse SMD 2,6x6,1 125VAC/DC T UL 3A 7016975.3

Fuse SMD 2,6x6,1 125VAC/DC T UL 3A 7016975.3

Reference 158000.3.0 - Manufacturer SIBA
Class T
Rated current In (A) 3
Rated Voltage Un AC (V) 125
Applicable standards UL
Voltage drop (mV) 110
Rated Voltage Un DC (V) 125
Rated breaking capacity I1 DC (kA) 50
Fuse Dimension (mm) 2,6x6,1
Melting I²t value (A²s) 24
Fuse Connection/Terminal type SMD
Voltage of total clearing I2t test 125
Rated breaking capacity I1 AC (kA) 50
Weight (gr) 1
Price List €0.68/pc
Quantity
lock Datasheet
Filter by
Manufacturer
Series name
Class
Rated Voltage Un AC (V)
Rated Voltage Un DC (V)
Rated insultaion voltage AC (V)
Rated insulated voltage DC (V)
Applicable standards
Product added to compare.
Product added to wishlist
