Fuses

UR22 - Fuse 690V AC 22x58 fixing on pcb 80A

UR22 - Fuse 690V AC 22x58 fixing on pcb 80A

Reference 265.359.20.0.0 - Manufacturer FAULTRAP
Class aR
Rated current In (A) 80
Rated Voltage Un AC (V) 690
Applicable standards IEC
Power loss (W) 16,3
Series name UR22
Melting I²t value (A²s) 1055
Fuse Connection/Terminal type PCB Mount Terminals
Total clearing I²t @Un AC (A²s) 4620
Rated breaking capacity I1 AC (kA) 200
Product available on request Ask for more information
B050 - Fuse 1000VDC aBat 450A - 97,6mm - Tin Plated

B050 - Fuse 1000VDC aBat 450A - 97,6mm - Tin Plated

Reference 265.639.01.0.0 - Manufacturer FAULTRAP
Class aBat, aR
Rated current In (A) 450
Applicable standards IEC, UL
Power loss (W) 60
Rated Voltage Un DC (V) 1000
Time costant L/R (ms) 2
Series name B050
Rated breaking capacity I1 DC (kA) 100
Fuse Dimension (mm) 50x129
Melting I²t value (A²s) 62000
Minimum breaking current (A) 4500
Fuse Connection/Terminal type Screw fixing
Fixing connection centres (mm) 97
Total clearing I²t @Un DC (A²s) 162000
Price List €136.92/pc
Quantity
lock Datasheet
B050 - Fuse 1000VDC aBat 250A - 118,85mm - Tin Plated

B050 - Fuse 1000VDC aBat 250A - 118,85mm - Tin Plated

Reference 267.812.88.0.0 - Manufacturer FAULTRAP
Class aBat, aR
Rated current In (A) 250
Applicable standards IEC, UL
Power loss (W) 36
Rated Voltage Un DC (V) 1000
Time costant L/R (ms) 2
Series name B050
Rated breaking capacity I1 DC (kA) 100
Fuse Dimension (mm) 50x141
Melting I²t value (A²s) 15000
Minimum breaking current (A) 2500
Fuse Connection/Terminal type Screw fixing
Fixing connection centres (mm) 118
Total clearing I²t @Un DC (A²s) 40000
Product available on request Ask for more information
M050 - Fuse 500V DC 10x38 40A

M050 - Fuse 500V DC 10x38 40A

Reference 269.721.81.0.0 - Manufacturer FAULTRAP
Class EV full
Rated current In (A) 40
Power loss (W) 5,6
Rated Voltage Un DC (V) 500
Series name M050
Fuse Dimension (mm) 10x38
Fuse Connection/Terminal type Cylindrical
Product available on request Ask for more information
BPF3 - Fuse 1500VDC aBat d:76mm axial 171mm 1100A

BPF3 - Fuse 1500VDC aBat d:76mm axial 171mm 1100A

Reference 270.898.07.0.0 - Manufacturer FAULTRAP
Class aBat
Rated current In (A) 1100
Applicable standards IEC
Power loss (W) 245
Rated Voltage Un DC (V) 1500
Time costant L/R (ms) 3
Series name BPF3
Rated breaking capacity I1 DC (kA) 100000
Fuse Dimension (mm) 76x171
Melting I²t value (A²s) 790000
Fuse Connection/Terminal type Screw fixing
Voltage of total clearing I2t test 1500
Total clearing I²t @Un AC (A²s) 4505000
Product available on request Ask for more information
E103 - Fuse 10x38 1000VDC aBAT 8A

E103 - Fuse 10x38 1000VDC aBAT 8A

Reference 279.440.74.0.0 - Manufacturer FAULTRAP
Class aBat
Rated current In (A) 8
Applicable standards IEC
Power loss (W) 2,1
Rated Voltage Un DC (V) 1000
Series name E103
Rated breaking capacity I1 DC (kA) 20000
Fuse Dimension (mm) 10x38
Fuse Connection/Terminal type Cylindrical
Product available on request Ask for more information
C100 - Fuse 690V aR size 1 M8 315A

C100 - Fuse 690V aR size 1 M8 315A

Reference 285.250.19.0.0 - Manufacturer FAULTRAP
Class aR
Rated current In (A) 315
Rated Voltage Un AC (V) 690
Dimension SQB2
Applicable standards IEC
Power loss (W) 48
Fixing dimensions M8
Melting I²t value (A²s) 6800
Fuse Connection/Terminal type Screw fixing
Voltage of total clearing I2t test 690
Total clearing I²t @Un AC (A²s) 46000
Rated breaking capacity I1 AC (kA) 100000
Product available on request Ask for more information
B200 - Fuse 38x73mm 1000VDC aBat Axial 200A

B200 - Fuse 38x73mm 1000VDC aBat Axial 200A

Reference 289.725.19.0.0 - Manufacturer FAULTRAP
Class aBat
Rated current In (A) 200
Applicable standards IEC
Power loss (W) 32
Rated Voltage Un DC (V) 1000
Time costant L/R (ms) 2
Series name B200
Rated breaking capacity I1 DC (kA) 50000
Fuse Dimension (mm) 38x73
Melting I²t value (A²s) 11400
Fuse Connection/Terminal type Screw fixing
Voltage of total clearing I2t test 1000
Total clearing I²t @Un AC (A²s) 43500
Product available on request Ask for more information
C200 - Fuse 690VAC aR 700A size 2 61x50mm M10 flush end terminals, with microswitch adapter

C200 - Fuse 690VAC aR 700A size 2 61x50mm M10 flush end terminals, with microswitch adapter

Reference 288.019.04.0.0 - Manufacturer FAULTRAP
Class aR
Rated current In (A) 700
Rated Voltage Un AC (V) 690
Dimension SQB2
Applicable standards IEC
Power loss (W) 92
Series name C200
Fixing dimensions M10
Melting I²t value (A²s) 74000
Fuse Connection/Terminal type Screw fixing
Total clearing I²t @Un AC (A²s) 510600
Rated breaking capacity I1 AC (kA) 200
Product available on request Ask for more information
20PV22 - Fuse 2000VDC gPV 22x85 55A

20PV22 - Fuse 2000VDC gPV 22x85 55A

Reference 276.236.15.0.0 - Manufacturer FAULTRAP
Class gPV
Rated current In (A) 55
Applicable standards IEC
Power loss (W) 13.5
Rated Voltage Un DC (V) 2000
Time costant L/R (ms) 1-3
Series name 20PV22
Rated breaking capacity I1 DC (kA) 50
Fuse Dimension (mm) 22x85
Melting I²t value (A²s) 1065
Fuse Connection/Terminal type Cylindrical
Product available on request Ask for more information
20PV22 - Fuse 2000VDC gPV 22x85 45A

20PV22 - Fuse 2000VDC gPV 22x85 45A

Reference 279.406.19.0.0 - Manufacturer FAULTRAP
Class gPV
Rated current In (A) 45
Applicable standards IEC
Power loss (W) 11.9
Rated Voltage Un DC (V) 2000
Time costant L/R (ms) 1-3
Series name 20PV22
Rated breaking capacity I1 DC (kA) 50
Fuse Dimension (mm) 22x85
Melting I²t value (A²s) 6600
Fuse Connection/Terminal type Cylindrical
Product available on request Ask for more information
20BP3 - Fuse 2000VDC aBat 2x76x194mm Flush-End M12 800A

20BP3 - Fuse 2000VDC aBat 2x76x194mm Flush-End M12 800A

Reference 244.549.60.0.0 - Manufacturer FAULTRAP
Class aBat
Rated current In (A) 800
Applicable standards IEC
Power loss (W) 241
Rated Voltage Un DC (V) 2000
Time costant L/R (ms) 1-3
Series name 20BP3
Rated breaking capacity I1 DC (kA) 50
Fuse Dimension (mm) 76x218
Fixing dimensions M12
Melting I²t value (A²s) 226000
Minimum breaking current (A) 8000
Fuse Connection/Terminal type Screw fixing
Product available on request Ask for more information
NR2B - Fuse DIN00 80mm aR 700VDC/690VAC with ind. lug 80A

NR2B - Fuse DIN00 80mm aR 700VDC/690VAC with ind. lug 80A

Reference 245.542.07.0.0 - Manufacturer FAULTRAP
Class aR
Rated current In (A) 80
Rated Voltage Un AC (V) 690
Dimension 000
Applicable standards IEC, UL
Power loss (W) 17
Rated Voltage Un DC (V) 700
Time costant L/R (ms) 2
Series name NR2B
Rated breaking capacity I1 DC (kA) 30000
Melting I²t value (A²s) 750
Fuse Connection/Terminal type Screw fixing
Fixing connection centres (mm) 80
Voltage of total clearing I2t test 700
Total clearing I²t @Un AC (A²s) 2800
Rated breaking capacity I1 AC (kA) 200000
Product available on request Ask for more information
NR2A-Fuse 000/80 aR 700VDC/690VAC with ind. w/o lug 63A

NR2A-Fuse 000/80 aR 700VDC/690VAC with ind. w/o lug 63A

Reference 247.278.11.0.0 - Manufacturer FAULTRAP
Class aR
Rated current In (A) 63
Rated Voltage Un AC (V) 690
Dimension 000
Applicable standards IEC
Power loss (W) 9.5
Rated Voltage Un DC (V) 700
Time costant L/R (ms) 2
Series name NR2A
Rated breaking capacity I1 DC (kA) 30000
Melting I²t value (A²s) 520
Fuse Connection/Terminal type Screw fixing
Fixing connection centres (mm) 80
Voltage of total clearing I2t test 700
Total clearing I²t @Un AC (A²s) 1900
Rated breaking capacity I1 AC (kA) 200000
Product available on request Ask for more information
24E1 - Fuse BS 17,2x42 aR 240V 160A

24E1 - Fuse BS 17,2x42 aR 240V 160A

Reference 247.730.22.0.0 - Manufacturer FAULTRAP
Class aR
Rated current In (A) 160
Rated Voltage Un AC (V) 240
Applicable standards IEC
Power loss (W) 21,9
Rated Voltage Un DC (V) 150
Series name 24E1
Rated breaking capacity I1 DC (kA) 20
Fuse Dimension (mm) 17x56
Melting I²t value (A²s) 990
Fuse Connection/Terminal type Screw fixing
Total clearing I²t @Un AC (A²s) 8590
Rated breaking capacity I1 AC (kA) 100
Weight (gr) 29,5
Price List €31.93/pc
Quantity
lock Datasheet
EV65.1000 - Fuse 1000VDC 22x65 cylindrical 30A

EV65.1000 - Fuse 1000VDC 22x65 cylindrical 30A

Reference 247.896.25.0.0 - Manufacturer FAULTRAP
Class EV full
Rated current In (A) 30
Applicable standards UL
Power loss (W) 7
Rated Voltage Un DC (V) 1000
Time costant L/R (ms) 2,5
Series name EV65.1000
Rated breaking capacity I1 DC (kA) 25000
Fuse Dimension (mm) 22x65
Melting I²t value (A²s) 230
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 1000
Total clearing I²t @Un AC (A²s) 910
Product available on request Ask for more information
B200 - Fuse 38x73mm 1000VDC BS aBat 63A

B200 - Fuse 38x73mm 1000VDC BS aBat 63A

Reference 250.111.16.0.0 - Manufacturer FAULTRAP
Class aBat
Rated current In (A) 63
Applicable standards IEC
Power loss (W) 11
Rated Voltage Un DC (V) 1000
Time costant L/R (ms) 2
Series name B200
Rated breaking capacity I1 DC (kA) 50000
Fuse Dimension (mm) 38x73
Melting I²t value (A²s) 750
Fuse Connection/Terminal type Screw fixing
Voltage of total clearing I2t test 1000
Total clearing I²t @Un AC (A²s) 2850
Product available on request Ask for more information
Fuse SQB1 screw M8 aR 690V lateral switch adapter 80A

Fuse SQB1 screw M8 aR 690V lateral switch adapter 80A

Reference 250325.0.0 - Manufacturer DF
Class aR
Rated current In (A) 80
Rated Voltage Un AC (V) 690
Dimension SQB1
Applicable standards IEC, UL
Power loss (W) 15
Melting I²t value (A²s) 350
Fuse Connection/Terminal type Screw fixing
Voltage of total clearing I2t test 690
Total clearing I²t @Un AC (A²s) 2570
Rated breaking capacity I1 AC (kA) 120000
Price List €83.43/pc
Quantity
lock Datasheet
Fuse SQB1 screw M8 aR 690V lateral switch adapter 100A

Fuse SQB1 screw M8 aR 690V lateral switch adapter 100A

Reference 250330.0.0 - Manufacturer DF
Class aR
Rated current In (A) 100
Rated Voltage Un AC (V) 690
Dimension SQB1
Applicable standards IEC, UL
Power loss (W) 20
Melting I²t value (A²s) 550
Fuse Connection/Terminal type Screw fixing
Voltage of total clearing I2t test 690
Total clearing I²t @Un AC (A²s) 4000
Rated breaking capacity I1 AC (kA) 120000
Price List €83.43/pc
Quantity
lock Datasheet
Fuse SQB1 screw M8 aR 690V lateral switch adapter 125A

Fuse SQB1 screw M8 aR 690V lateral switch adapter 125A

Reference 250335.0.0 - Manufacturer DF
Class aR
Rated current In (A) 125
Rated Voltage Un AC (V) 690
Dimension SQB1
Applicable standards IEC, UL
Power loss (W) 125
Melting I²t value (A²s) 795
Fuse Connection/Terminal type Screw fixing
Voltage of total clearing I2t test 690
Total clearing I²t @Un AC (A²s) 5750
Rated breaking capacity I1 AC (kA) 120000
Price List €83.43/pc
Quantity
lock Datasheet
Fuse SQB1 screw M8 aR 690V lateral switch adapter 160A

Fuse SQB1 screw M8 aR 690V lateral switch adapter 160A

Reference 250340.0.0 - Manufacturer DF
Class aR
Rated current In (A) 160
Rated Voltage Un AC (V) 690
Dimension SQB1
Applicable standards IEC, UL
Power loss (W) 33
Melting I²t value (A²s) 1400
Fuse Connection/Terminal type Screw fixing
Voltage of total clearing I2t test 690
Total clearing I²t @Un AC (A²s) 10250
Rated breaking capacity I1 AC (kA) 120000
Price List €77.87/pc
Quantity
lock Datasheet
Filter by
Manufacturer
Series name
Fuse size
Class
Fuse Connection/Terminal type
Rated current In (A)
Rated Voltage Un AC (V)
Rated Voltage Un DC (V)
Applicable standards
Product added to compare.
Product added to wishlist
