SPK-385-12,5-4(S) SPD 385V T1 2 4 0 with microswitch
SPK-385-12,5-4(S) SPD 385V T1 2 4 0 with microswitch

SPK-385-12,5-4(S) SPD 385V T1 2 4 0 with microswitch

Reference: M52.256.41.0.0  -  Manufacturer: TechnoTeam
€586.85 /pc VAT excl.

Product Details

Rated Voltage Un AC (V)
230
Applicable standards
IEC
Type
1+2
Remote contact
YES
Housing
Plug-in modules
Short circuit current rating Isccr kA
25
Impulse Discharge Current kA (Iimp 10/350us)
12,5
Nominal Dischiarge current kA (In 8/20us)
20
Maximum Discharge Current kA (Imax 8/20μs)
50
Maximum Continuous Operating Voltage AC Uc (V)
385
