SPH-75-40-2(S) - SPD 75V T2 2+0 with microswitch
SPH-75-40-2(S) - SPD 75V T2 2+0 with microswitch

SPH-75-40-2(S) - SPD 75V T2 2+0 with microswitch

Reference: G21.180.61.0.0  -  Manufacturer: TechnoTeam
$224.16 /pc VAT excl.

Product Details

Rated Voltage Un AC (V)
60
Applicable standards
IEC
Type
2
Protection level Up (kV)
0,4
Remote contact
YES
Housing
Plug-in modules
Series name
SPH-75-40
Short circuit current rating Isccr kA
25
Nominal Dischiarge current kA (In 8/20us)
20
Maximum Discharge Current kA (Imax 8/20μs)
40
Maximum Continuous Operating Voltage AC Uc (V)
75
