SPH-440-40-4(S) - SPD 440V T2 4+0 with microswitch
SPH-440-40-4(S) - SPD 440V T2 4+0 with microswitch

SPH-440-40-4(S) - SPD 440V T2 4+0 with microswitch

Reference: E04.536.50.0.0  -  Manufacturer: TechnoTeam
€365.15 /pc VAT excl.

Product Details

Rated Voltage Un AC (V)
400
Applicable standards
IEC
Type
2
Protection level Up (kV)
2
Remote contact
YES
Housing
Plug-in modules
Series name
SPH-440-40
Short circuit current rating Isccr kA
25
Nominal Dischiarge current kA (In 8/20us)
20
Maximum Discharge Current kA (Imax 8/20μs)
40
Maximum Continuous Operating Voltage AC Uc (V)
440
