Fuse 14x65 1100VDC gPV UL2579 20A
Fuse 14x65 1100VDC gPV UL2579 20A

Fuse 14x65 1100VDC gPV UL2579 20A

Reference: 5023528.20.0  -  Manufacturer: SIBA
Product available on request
Ask for more information

Product Details

Class
gPV
Rated current In (A)
20
Applicable standards
IEC, UL
Power loss (W)
4,6
Rated Voltage Un DC (V)
1100
Rated breaking capacity I1 DC (kA)
30000
Fuse Dimension (mm)
14x65
Melting I²t value (A²s)
30
Fuse Connection/Terminal type
Cylindrical
Voltage of total clearing I2t test
1100
Total clearing I²t @Un AC (A²s)
205
Weight (gr)
28
