Fuse 22x58 gRL/gS 690VAC/500VDC with striker 63A
Fuse 22x58 gRL/gS 690VAC/500VDC with striker 63A

Fuse 22x58 gRL/gS 690VAC/500VDC with striker 63A

Reference: 5014234.63.0  -  Manufacturer: SIBA
€23.55 /pc VAT excl.

This product is only sold in boxes of 10 pcs

Product Details

Class
gRL, gS
Rated current In (A)
63
Rated Voltage Un AC (V)
700
Applicable standards
IEC, UL
Rated Voltage Un DC (V)
500
Fuse Dimension (mm)
22x58
Melting I²t value (A²s)
1300
Fuse Connection/Terminal type
Cylindrical
Voltage of total clearing I2t test
690
Total clearing I²t @Un AC (A²s)
10500
Rated breaking capacity I1 AC (kA)
200000
Weight (gr)
30
