Fuse 14x51 gRL/gS terminals 63mm 690V 12A
Fuse 14x51 gRL/gS terminals 63mm 690V 12A

Fuse 14x51 gRL/gS terminals 63mm 690V 12A

Reference: 5012934.12.0  -  Manufacturer: SIBA
€15.35 /pc VAT excl.

This product is only sold in boxes of 10 pcs

Product Details

Class
gRL, gS
Rated current In (A)
12
Rated Voltage Un AC (V)
690
Applicable standards
IEC, UL
Power loss (W)
2,3
Rated Voltage Un DC (V)
400
Rated breaking capacity I1 DC (kA)
30000
Fuse Dimension (mm)
14x51
Melting I²t value (A²s)
12
Fuse Connection/Terminal type
Screw fixing
Voltage of total clearing I2t test
690
Total clearing I²t @Un AC (A²s)
105
Rated breaking capacity I1 AC (kA)
200000
Weight (gr)
30
