Fuse BS 35x85 aR 690V (FM-MT) 315A
Fuse BS 35x85 aR 690V (FM-MT) 315A

Fuse BS 35x85 aR 690V (FM-MT) 315A

Reference: 5007406.315.0  -  Manufacturer: SIBA
€49.66 /pc VAT excl.

This product is only sold in boxes of 3 pcs

Product Details

Class
aR
Rated current In (A)
315
Rated Voltage Un AC (V)
690
Applicable standards
IEC
Power loss (W)
46
Fuse Dimension (mm)
35x85
Melting I²t value (A²s)
27000
Fuse Connection/Terminal type
BS
Voltage of total clearing I2t test
690
Total clearing I²t @Un AC (A²s)
173000
Rated breaking capacity I1 AC (kA)
100000
Weight (gr)
200
