Fuse 22x58 aM 690V 4A
Fuse 22x58 aM 690V 4A

Fuse 22x58 aM 690V 4A

Reference: 5006007.4.0  -  Manufacturer: SIBA
Product available on request
Ask for more information

Product Details

Class
aM
Rated current In (A)
4
Rated Voltage Un AC (V)
690
Applicable standards
IEC
Power loss (W)
0,4
Fuse Dimension (mm)
22x58
Melting I²t value (A²s)
100
Fuse Connection/Terminal type
Cylindrical
Voltage of total clearing I2t test
690
Total clearing I²t @Un AC (A²s)
560
Rated breaking capacity I1 AC (kA)
100000
Weight (gr)
60
