Fuse 1000VDC NH0/95mm gR 63A
Fuse 1000VDC NH0/95mm gR 63A

Fuse 1000VDC NH0/95mm gR 63A

Reference: 2058521.63.0  -  Manufacturer: SIBA
Product available on request
Ask for more information

Product Details

Class
gR
Rated current In (A)
63
Dimension
NH0
Applicable standards
IEC, UL
Power loss (W)
13
Rated Voltage Un DC (V)
1000
Time costant L/R (ms)
3
Rated breaking capacity I1 DC (kA)
100000
Melting I²t value (A²s)
620
Fuse Connection/Terminal type
Screw fixing
Fixing connection centres (mm)
95
Voltage of total clearing I2t test
1000
Total clearing I²t @Un AC (A²s)
2800
