Fuse DIN000 80mm aR 690V UL with indicator, w/o lug 315A
Fuse DIN000 80mm aR 690V UL with indicator, w/o lug 315A

Fuse DIN000 80mm aR 690V UL with indicator, w/o lug 315A

Reference: 2028220.315.0  -  Manufacturer: SIBA
€86.85 /pc VAT excl.

This product is only sold in boxes of 6 pcs

Product Details

Class
aR
Rated current In (A)
315
Rated Voltage Un AC (V)
690
Dimension
000
Applicable standards
IEC, UL
Power loss (W)
58
Melting I²t value (A²s)
14000
Fuse Connection/Terminal type
Screw fixing
Fixing connection centres (mm)
80
Voltage of total clearing I2t test
660
Total clearing I²t @Un AC (A²s)
77000
Rated breaking capacity I1 AC (kA)
200000
Weight (gr)
120
Ask for more information
