Fuse NH3 aR 690V/500VDC top indicator low I2t 800A
Fuse NH3 aR 690V/500VDC top indicator low I2t 800A

Fuse NH3 aR 690V/500VDC top indicator low I2t 800A

Reference: 2021332.800.0  -  Manufacturer: SIBA
€236.27 /pc VAT excl.

Product Details

Class
aR
Rated current In (A)
800
Rated Voltage Un AC (V)
690
Dimension
NH3
Applicable standards
IEC, UL
Power loss (W)
47
Rated Voltage Un DC (V)
500
Time costant L/R (ms)
10
Rated breaking capacity I1 DC (kA)
30000
Melting I²t value (A²s)
74000
Fuse Connection/Terminal type
NH knife
Voltage of total clearing I2t test
690
Total clearing I²t @Un AC (A²s)
525000
Rated breaking capacity I1 AC (kA)
120000
Weight (gr)
955
