Fuse DIN00 80mm gRL/gS 690V 100A
Fuse DIN00 80mm gRL/gS 690V 100A

Fuse DIN00 80mm gRL/gS 690V 100A

Reference: 2018934.100.0  -  Manufacturer: SIBA
€34.74 /pc VAT excl.

This product is only sold in boxes of 3 pcs

Product Details

Class
gRL, gS
Rated current In (A)
100
Rated Voltage Un AC (V)
690
Dimension
00
Applicable standards
IEC, UL
Power loss (W)
10,5
Melting I²t value (A²s)
3000
Fuse Connection/Terminal type
Screw fixing
Fixing connection centres (mm)
80
Voltage of total clearing I2t test
690
Total clearing I²t @Un AC (A²s)
30000
Rated breaking capacity I1 AC (kA)
200000
Weight (gr)
240
