Fuse DIN00 80mm gPV UL2579 600VDC w/o ind. and lug 110A
Fuse DIN00 80mm gPV UL2579 600VDC w/o ind. and lug 110A

Fuse DIN00 80mm gPV UL2579 600VDC w/o ind. and lug 110A

Reference: 2018928.110.0  -  Manufacturer: SIBA
Product available on request
Ask for more information

Product Details

Class
gPV
Rated current In (A)
110
Dimension
00
Applicable standards
IEC, UL
Power loss (W)
17,5
Rated Voltage Un DC (V)
600
Rated breaking capacity I1 DC (kA)
30000
Melting I²t value (A²s)
1300
Fuse Connection/Terminal type
Screw fixing
Fixing connection centres (mm)
80
Voltage of total clearing I2t test
600
Total clearing I²t @Un AC (A²s)
7900
Weight (gr)
300
