Fuse SMD 1,6x3,2 FF 63VDC/125VAC UL 3,15A
Fuse SMD 1,6x3,2 FF 63VDC/125VAC UL 3,15A

Fuse SMD 1,6x3,2 FF 63VDC/125VAC UL 3,15A

Reference: 154000.3,15.0  -  Manufacturer: SIBA
Product available on request
Ask for more information

Product Details

Class
FF
Rated current In (A)
3,15
Rated Voltage Un AC (V)
125
Dimension
1206
Applicable standards
IEC, UL
Voltage drop (mV)
153
Rated Voltage Un DC (V)
63
Rated breaking capacity I1 DC (kA)
50
Fuse Dimension (mm)
1,6x3,2
Melting I²t value (A²s)
0,0251
Fuse Connection/Terminal type
SMD
Rated breaking capacity I1 AC (kA)
50
Weight (gr)
1
