List of products by manufacturer SIBA

Fuse 1500VDC SQB3 gPV screw fixing 450A

Fuse 1500VDC SQB3 gPV screw fixing 450A

Reference 2024728.450.0 - Manufacturer SIBA
Class gPV
Rated current In (A) 450
Voltage of total I2t test 1500
Format Screw fixing
Dimension SQB3
Pre-arcing I2t value (A2s) 153000
Total I2t value (A2s) 920000
Power loss (W) 80
Rated Voltage Un DC (V) 1500
Rated break.capacity I1 DC (A) 50000
Price List €890.41/pc
Quantity
lock Datasheet
Fuse base NH2 690V 1pole M12x50mm

Fuse base NH2 690V 1pole M12x50mm

Reference 2100404.0.0 - Manufacturer SIBA
Rated current In (A) 400
Rated Voltage Un AC (V) 690
Weight (g) 870
Homologations IEC
Fuses format NH knife contact
Fuses dimension NH2
Number of phase 1
Max power dissipation (W) 45
Price List €11.87/pc
Quantity
Fuse NH00 gG 800V 20A

Fuse NH00 gG 800V 20A

Reference 2030913.20.0 - Manufacturer SIBA
Class gG
Rated current In (A) 20
Rated Voltage Un AC (V) 800
Rated break.capacity I1 AC (A) 120000
Voltage of total I2t test 800
Format NH knife contact
Dimension NH00
Pre-arcing I2t value (A2s) 700
Total I2t value (A2s) 12000
Homologations IEC
Power loss (W) 2,5
Price List €19.69/pc
Quantity
Fuse DIN00 110mm 690V aR indicator, no switch adapter 250A

Fuse DIN00 110mm 690V aR indicator, no switch adapter 250A

Reference 2056620.250.0 - Manufacturer SIBA
Class aR
Rated current In (A) 10
Rated Voltage Un AC (V) 690
Rated break.capacity I1 AC (A) 200000
Voltage of total I2t test 660
Format Screw fixing
Dimension 00-110mm
Pre-arcing I2t value (A2s) 5
Total I2t value (A2s) 40
Homologations IEC
Power loss (W) 3,5
Price List €108.38/pc
Quantity
Fuse SQB-DC102 1000VDC aBat/aR 137mm 400A

Fuse SQB-DC102 1000VDC aBat/aR 137mm 400A

Reference 9054525.400.0 - Manufacturer SIBA
Class aBat
Rated current In (A) 400
Voltage of total I2t test 1000
Format Screw fixing
Dimension DC102
Pre-arcing I2t value (A2s) 32000
Total I2t value (A2s) 180000
Power loss (W) 105
Rated Voltage Un DC (V) 1000
Rated break.capacity I1 DC (A) 100000
Time costant L/R (ms) 3
Product available on request Ask for more information
Fuse SQB2 110mm aR/aBat 1000VDC 500A

Fuse SQB2 110mm aR/aBat 1000VDC 500A

Reference 9054625.500.0 - Manufacturer SIBA
Class aR
Rated current In (A) 500
Voltage of total I2t test 1000
Format Screw fixing
Dimension SQB2-110mm
Pre-arcing I2t value (A2s) 59000
Total I2t value (A2s) 320000
Power loss (W) 114
Rated Voltage Un DC (V) 1000
Rated break.capacity I1 DC (A) 100000
Time costant L/R (ms) 3
Product available on request Ask for more information
Fuse SQB2 110mm aR/aBat 1000VDC 450A

Fuse SQB2 110mm aR/aBat 1000VDC 450A

Reference 9054625.450.0 - Manufacturer SIBA
Class aR
Rated current In (A) 450
Voltage of total I2t test 1000
Format Screw fixing
Dimension SQB2-110mm
Pre-arcing I2t value (A2s) 42000
Total I2t value (A2s) 230000
Power loss (W) 110
Rated Voltage Un DC (V) 1000
Rated break.capacity I1 DC (A) 100000
Time costant L/R (ms) 3
Product available on request Ask for more information
Fuse SQB-DC102 1000VDC aBat/aR 137mm 450A

Fuse SQB-DC102 1000VDC aBat/aR 137mm 450A

Reference 9054525.450.0 - Manufacturer SIBA
Class aBat
Rated current In (A) 450
Voltage of total I2t test 1000
Format Screw fixing
Dimension DC102
Pre-arcing I2t value (A2s) 42000
Total I2t value (A2s) 230000
Power loss (W) 110
Rated Voltage Un DC (V) 1000
Rated break.capacity I1 DC (A) 100000
Time costant L/R (ms) 3
Price List €1,561.53/pc
Quantity
lock Datasheet
Fuse SQB2 110mm aR/aBat 1000VDC 400A

Fuse SQB2 110mm aR/aBat 1000VDC 400A

Reference 9054625.400.0 - Manufacturer SIBA
Class aR
Rated current In (A) 400
Voltage of total I2t test 1000
Format Screw fixing
Dimension SQB2-110mm
Pre-arcing I2t value (A2s) 32000
Total I2t value (A2s) 180000
Power loss (W) 105
Rated Voltage Un DC (V) 1000
Rated break.capacity I1 DC (A) 100000
Time costant L/R (ms) 3
Product available on request Ask for more information
Fuse SQB-DC102 1000VDC aBat/aR 137mm 550A

Fuse SQB-DC102 1000VDC aBat/aR 137mm 550A

Reference 9054525.550.0 - Manufacturer SIBA
Class aBat
Rated current In (A) 550
Voltage of total I2t test 1000
Format Screw fixing
Dimension DC102
Pre-arcing I2t value (A2s) 89000
Total I2t value (A2s) 490000
Power loss (W) 116
Rated Voltage Un DC (V) 1000
Rated break.capacity I1 DC (A) 100000
Time costant L/R (ms) 3
Product available on request Ask for more information
