List of products by manufacturer SIBA

"Fuse 17,5kV 63,5x360 general purpose M8-M8 w/o striker 10A

Fuse 17,5kV 63,5x360 general purpose M8-M8 w/o striker 10A

Reference 3031091.10.0 - Manufacturer SIBA
Class HH G P
Rated current In (A) 10
Rated Voltage Un AC (V) 12000
Applicable standards IEC
Power loss (W) 11
Fuse Dimension (mm) 63,5x360
Melting I²t value (A²s) 250
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 12000
Total clearing I²t @Un AC (A²s) 2800
Rated breaking capacity I1 AC (kA) 63000
Weight (gr) 2600
Product available on request Ask for more information
aa

Fuse SQB1 110mm aR 1100V top switch adapter 80A

Reference 2071432.80.0 - Manufacturer SIBA
Class aR
Rated current In (A) 80
Rated Voltage Un AC (V) 1250
Dimension SQB1
Applicable standards IEC, UL
Power loss (W) 35
Melting I²t value (A²s) 410
Fuse Connection/Terminal type Screw fixing
Fixing connection centres (mm) 110
Voltage of total clearing I2t test 1000
Total clearing I²t @Un AC (A²s) 2300
Rated breaking capacity I1 AC (kA) 100000
Price List €53.78/pc
Quantity
lock Datasheet
Fuse SQB3 screw M12 aR 1500V lateral switch adapter 550A

Fuse SQB3 screw M12 aR 1500V lateral switch adapter 550A

Reference 2074352.550.0 - Manufacturer SIBA
Rated current In (A) 550
Rated Voltage Un AC (V) 1500
Dimension SQB3
Applicable standards IEC, UL
Power loss (W) 110
Fixing dimensions M12
Melting I²t value (A²s) 124600
Fuse Connection/Terminal type Screw fixing
Voltage of total clearing I2t test 1650
Total clearing I²t @Un AC (A²s) 1015000
Rated breaking capacity I1 AC (kA) 100000
Price List €171.59/pc
Quantity
lock Datasheet
Fuse DIN00 80mm 690V aR UL w/o ind, w/o lug 315A

Fuse DIN00 80mm 690V aR UL w/o ind, w/o lug 315A

Reference 2018921.315.0 - Manufacturer SIBA
Class aR
Rated current In (A) 315
Rated Voltage Un AC (V) 690
Dimension 00
Applicable standards IEC, UL
Power loss (W) 53
Melting I²t value (A²s) 15600
Fuse Connection/Terminal type Screw fixing
Fixing connection centres (mm) 80
Voltage of total clearing I2t test 660
Total clearing I²t @Un AC (A²s) 86000
Rated breaking capacity I1 AC (kA) 200000
Price List €40.60/pc
Quantity
lock Datasheet
Fuse SQB0 axial contacts aR 3600V/4000VDC 100A

Fuse SQB0 axial contacts aR 3600V/4000VDC 100A

Reference 9023027.100.0 - Manufacturer SIBA
Class aR
Rated current In (A) 100
Dimension SQB0
Rated Voltage Un DC (V) 4000
Time costant L/R (ms) 15
Rated breaking capacity I1 DC (kA) 300000
Fuse Connection/Terminal type Screw fixing
Voltage of total clearing I2t test 4000
Weight (gr) 2500
Price List €403.55/pc
Quantity
Fuse SQB0 axial contacts aR 3600V/4000VDC 125A

Fuse SQB0 axial contacts aR 3600V/4000VDC 125A

Reference 9023027.125.0 - Manufacturer SIBA
Class aR
Rated current In (A) 125
Dimension SQB0
Rated Voltage Un DC (V) 4000
Time costant L/R (ms) 15
Rated breaking capacity I1 DC (kA) 300000
Fuse Connection/Terminal type Screw fixing
Voltage of total clearing I2t test 4000
Weight (gr) 2500
Price List €414.67/pc
Quantity
Fuse SQB0 axial contacts aR 3600V/4000VDC 40A

Fuse SQB0 axial contacts aR 3600V/4000VDC 40A

Reference 9023027.40.0 - Manufacturer SIBA
Class aR
Rated current In (A) 40
Dimension SQB0
Power loss (W) 31
Rated Voltage Un DC (V) 4000
Rated breaking capacity I1 DC (kA) 3000
Melting I²t value (A²s) 184
Fuse Connection/Terminal type Screw fixing
Voltage of total clearing I2t test 4000
Total clearing I²t @Un AC (A²s) 1380
Weight (gr) 2500
Product available on request Ask for more information
Fuse SQB0 gR 1800V/2000VDC knife contacts 20A

Fuse SQB0 gR 1800V/2000VDC knife contacts 20A

Reference 9023120.20.0 - Manufacturer SIBA
Class gR
Rated current In (A) 20
Dimension SQB0
Applicable standards IEC
Power loss (W) 17
Rated Voltage Un DC (V) 1800
Time costant L/R (ms) 15
Rated breaking capacity I1 DC (kA) 30000
Melting I²t value (A²s) 20
Fuse Connection/Terminal type NH knife
Voltage of total clearing I2t test 2000
Total clearing I²t @Un AC (A²s) 170
Product available on request Ask for more information
Fuse SQB0 gR 1800V/2000VDC knife contacts 25A

Fuse SQB0 gR 1800V/2000VDC knife contacts 25A

Reference 9023120.25.0 - Manufacturer SIBA
Class gR
Rated current In (A) 25
Dimension SQB0
Applicable standards IEC
Power loss (W) 22
Rated Voltage Un DC (V) 1800
Time costant L/R (ms) 15
Rated breaking capacity I1 DC (kA) 30000
Melting I²t value (A²s) 32
Fuse Connection/Terminal type NH knife
Voltage of total clearing I2t test 2000
Total clearing I²t @Un AC (A²s) 270
Product available on request Ask for more information
Fuse SQB0 gR 1800V/2000VDC knife contacts 32A

Fuse SQB0 gR 1800V/2000VDC knife contacts 32A

Reference 9023120.32.0 - Manufacturer SIBA
Class gR
Rated current In (A) 32
Dimension SQB0
Applicable standards IEC
Power loss (W) 27
Rated Voltage Un DC (V) 1800
Time costant L/R (ms) 15
Rated breaking capacity I1 DC (kA) 30000
Melting I²t value (A²s) 46
Fuse Connection/Terminal type NH knife
Voltage of total clearing I2t test 2000
Total clearing I²t @Un AC (A²s) 380
Price List €340.39/pc
Quantity
Fuse SQB0 gR 1800V/2000VDC knife contacts 40A

Fuse SQB0 gR 1800V/2000VDC knife contacts 40A

Reference 9023120.40.0 - Manufacturer SIBA
Class gR
Rated current In (A) 40
Dimension SQB0
Applicable standards IEC
Power loss (W) 35
Rated Voltage Un DC (V) 1800
Time costant L/R (ms) 15
Rated breaking capacity I1 DC (kA) 30000
Melting I²t value (A²s) 82
Fuse Connection/Terminal type NH knife
Voltage of total clearing I2t test 2000
Total clearing I²t @Un AC (A²s) 680
Product available on request Ask for more information
Fuse SQB0 gR 1800V/2000VDC knife contacts 63A

Fuse SQB0 gR 1800V/2000VDC knife contacts 63A

Reference 9023120.63.0 - Manufacturer SIBA
Class gR
Rated current In (A) 63
Dimension SQB0
Applicable standards IEC
Power loss (W) 48
Rated Voltage Un DC (V) 1800
Time costant L/R (ms) 15
Rated breaking capacity I1 DC (kA) 30000
Melting I²t value (A²s) 251
Fuse Connection/Terminal type NH knife
Voltage of total clearing I2t test 2000
Total clearing I²t @Un AC (A²s) 2100
Product available on request Ask for more information
Fuse SQB0 gR 1800V/2000VDC with indicator 25A

Fuse SQB0 gR 1800V/2000VDC with indicator 25A

Reference 9022121.25.0 - Manufacturer SIBA
Class gR
Rated current In (A) 25
Dimension SQB0
Applicable standards IEC
Power loss (W) 22
Rated Voltage Un DC (V) 1800
Time costant L/R (ms) 15
Rated breaking capacity I1 DC (kA) 30000
Melting I²t value (A²s) 32
Fuse Connection/Terminal type Screw fixing
Voltage of total clearing I2t test 2000
Total clearing I²t @Un AC (A²s) 270
Weight (gr) 1191
Product available on request Ask for more information
Fuse SQB0 gR 1800V/2000VDC with indicator 32A

Fuse SQB0 gR 1800V/2000VDC with indicator 32A

Reference 9022121.32.0 - Manufacturer SIBA
Class gR
Rated current In (A) 32
Dimension SQB0
Applicable standards IEC
Power loss (W) 27
Rated Voltage Un DC (V) 1800
Time costant L/R (ms) 15
Rated breaking capacity I1 DC (kA) 30000
Melting I²t value (A²s) 46
Fuse Connection/Terminal type Screw fixing
Voltage of total clearing I2t test 2000
Total clearing I²t @Un AC (A²s) 380
Weight (gr) 1191
Product available on request Ask for more information
Fuse SQB0 gR 1800V/2000VDC with indicator 40A

Fuse SQB0 gR 1800V/2000VDC with indicator 40A

Reference 9022121.40.0 - Manufacturer SIBA
Class gR
Rated current In (A) 40
Dimension SQB0
Applicable standards IEC
Power loss (W) 35
Rated Voltage Un DC (V) 1800
Time costant L/R (ms) 15
Rated breaking capacity I1 DC (kA) 30000
Melting I²t value (A²s) 82
Fuse Connection/Terminal type Screw fixing
Voltage of total clearing I2t test 2000
Total clearing I²t @Un AC (A²s) 680
Weight (gr) 1191
Product available on request Ask for more information
Fuse 6,3x32 FF 600V AC UL ceramic 10A

Fuse 6,3x32 FF 600V AC UL ceramic 10A

Reference 7012540.10.0 - Manufacturer SIBA
Class FF
Rated current In (A) 10
Rated Voltage Un AC (V) 600
Applicable standards UL
Power loss (W) 3,5
Voltage drop (mV) 350
Fuse Dimension (mm) 6,3x32
Melting I²t value (A²s) 12
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 500
Total clearing I²t @Un AC (A²s) 55
Rated breaking capacity I1 AC (kA) 50000
Weight (gr) 3
Price List €2.70/pc
Quantity
Fuse 6,3x32 FF 500V AC UL ceramic 12,5A

Fuse 6,3x32 FF 500V AC UL ceramic 12,5A

Reference 7012540.12,5.0 - Manufacturer SIBA
Class FF
Rated current In (A) 12,5
Rated Voltage Un AC (V) 500
Applicable standards UL
Power loss (W) 3,8
Voltage drop (mV) 300
Fuse Dimension (mm) 6,3x32
Melting I²t value (A²s) 18
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 500
Total clearing I²t @Un AC (A²s) 80
Rated breaking capacity I1 AC (kA) 50000
Weight (gr) 3
Price List €2.70/pc
Quantity
Fuse 6,3x32 FF 500V AC UL ceramic 16A

Fuse 6,3x32 FF 500V AC UL ceramic 16A

Reference 7012540.16.0 - Manufacturer SIBA
Class FF
Rated current In (A) 16
Rated Voltage Un AC (V) 500
Applicable standards UL
Power loss (W) 4,8
Voltage drop (mV) 300
Fuse Dimension (mm) 6,3x32
Melting I²t value (A²s) 31
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 500
Total clearing I²t @Un AC (A²s) 140
Rated breaking capacity I1 AC (kA) 50000
Weight (gr) 3
Price List €2.70/pc
Quantity
Fuse 6,3x32 FF 600VAC/500VDC UL ceramic 2,5A

Fuse 6,3x32 FF 600VAC/500VDC UL ceramic 2,5A

Reference 7012540.2,5.0 - Manufacturer SIBA
Class FF
Rated current In (A) 2,5
Rated Voltage Un AC (V) 600
Applicable standards UL
Power loss (W) 1,4
Voltage drop (mV) 550
Rated Voltage Un DC (V) 500
Fuse Dimension (mm) 6,3x32
Melting I²t value (A²s) 1,2
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 500
Total clearing I²t @Un AC (A²s) 3
Rated breaking capacity I1 AC (kA) 50000
Weight (gr) 3
Price List €2.67/pc
Quantity
Fuse 6,3x32 FF 700VAC/500VDC UL ceramic 2A

Fuse 6,3x32 FF 700VAC/500VDC UL ceramic 2A

Reference 7012540.2.0 - Manufacturer SIBA
Class FF
Rated current In (A) 2
Rated Voltage Un AC (V) 700
Applicable standards UL
Power loss (W) 1,4
Voltage drop (mV) 650
Rated Voltage Un DC (V) 500
Fuse Dimension (mm) 6,3x32
Melting I²t value (A²s) 0,64
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 700
Total clearing I²t @Un AC (A²s) 2,2
Rated breaking capacity I1 AC (kA) 50000
Weight (gr) 3
Price List €2.49/pc
Quantity
Fuse 6,3x32 FF 500V AC UL ceramic 20A

Fuse 6,3x32 FF 500V AC UL ceramic 20A

Reference 7012540.20.0 - Manufacturer SIBA
Class FF
Rated current In (A) 20
Rated Voltage Un AC (V) 500
Applicable standards UL
Power loss (W) 5,6
Voltage drop (mV) 280
Fuse Dimension (mm) 6,3x32
Melting I²t value (A²s) 46
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 500
Total clearing I²t @Un AC (A²s) 200
Rated breaking capacity I1 AC (kA) 50000
Weight (gr) 3
Price List €4.32/pc
Quantity
Fuse 6,3x32 FF 600VAC/500VDC UL ceramic 3,15A

Fuse 6,3x32 FF 600VAC/500VDC UL ceramic 3,15A

Reference 7012540.3,15.0 - Manufacturer SIBA
Class FF
Rated current In (A) 3,15
Rated Voltage Un AC (V) 600
Applicable standards UL
Power loss (W) 1,6
Voltage drop (mV) 500
Rated Voltage Un DC (V) 500
Fuse Dimension (mm) 6,3x32
Melting I²t value (A²s) 2
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 500
Total clearing I²t @Un AC (A²s) 5
Rated breaking capacity I1 AC (kA) 50000
Weight (gr) 3
Price List €2.67/pc
Quantity
Fuse 6,3x32 FF 600VAC/500VDC UL ceramic 4A

Fuse 6,3x32 FF 600VAC/500VDC UL ceramic 4A

Reference 7012540.4.0 - Manufacturer SIBA
Class FF
Rated current In (A) 4
Rated Voltage Un AC (V) 600
Applicable standards UL
Power loss (W) 1,8
Voltage drop (mV) 450
Rated Voltage Un DC (V) 500
Fuse Dimension (mm) 6,3x32
Melting I²t value (A²s) 5
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 500
Total clearing I²t @Un AC (A²s) 13
Rated breaking capacity I1 AC (kA) 50000
Weight (gr) 3
Price List €2.67/pc
Quantity
Fuse 6,3x32 FF 600VAC/500VDC UL ceramic 5A

Fuse 6,3x32 FF 600VAC/500VDC UL ceramic 5A

Reference 7012540.5.0 - Manufacturer SIBA
Class FF
Rated current In (A) 5
Rated Voltage Un AC (V) 600
Applicable standards UL
Power loss (W) 2
Voltage drop (mV) 400
Rated Voltage Un DC (V) 500
Fuse Dimension (mm) 6,3x32
Melting I²t value (A²s) 10
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 500
Total clearing I²t @Un AC (A²s) 25
Rated breaking capacity I1 AC (kA) 50000
Weight (gr) 3
Price List €2.67/pc
Quantity
Product added to compare.
Product added to wishlist
