Fuse 22x58 with terminals 80mm gR 690V 6A

Fuse 22x58 with terminals 80mm gR 690V 6A

Reference 5014506.6.0 - Manufacturer SIBA
Class gR
Rated current In (A) 6
Rated Voltage Un AC (V) 690
Applicable standards IEC, UL
Power loss (W) 3
Fuse Dimension (mm) 22x58
Melting I²t value (A²s) 2
Fuse Connection/Terminal type Screw fixing
Voltage of total clearing I2t test 660
Total clearing I²t @Un AC (A²s) 10
Rated breaking capacity I1 AC (kA) 200000
Weight (gr) 80
Price List €154.63/pc
Quantity
lock Datasheet
Fuse 22x58 with terminals 80mm gR 690V 63A

Fuse 22x58 with terminals 80mm gR 690V 63A

Reference 5014506.63.0 - Manufacturer SIBA
Class gR
Rated current In (A) 63
Rated Voltage Un AC (V) 690
Applicable standards IEC, UL
Power loss (W) 16
Fuse Dimension (mm) 22x58
Melting I²t value (A²s) 510
Fuse Connection/Terminal type Screw fixing
Voltage of total clearing I2t test 660
Total clearing I²t @Un AC (A²s) 2260
Rated breaking capacity I1 AC (kA) 200000
Weight (gr) 80
Price List €31.94/pc
Quantity
lock Datasheet
Fuse 22x58 with terminals 80mm gRL 690V/500VDC 32A

Fuse 22x58 with terminals 80mm gRL 690V/500VDC 32A

Reference 5014534.32.0 - Manufacturer SIBA
Class gRL, gS
Rated current In (A) 32
Rated Voltage Un AC (V) 690
Applicable standards IEC, UL
Power loss (W) 4,8
Fuse Dimension (mm) 22x58
Melting I²t value (A²s) 250
Fuse Connection/Terminal type Screw fixing
Voltage of total clearing I2t test 690
Total clearing I²t @Un AC (A²s) 2000
Rated breaking capacity I1 AC (kA) 200000
Product available on request Ask for more information
Fuse 22x58 with terminals 80mm gRL 690V/500VDC 63A

Fuse 22x58 with terminals 80mm gRL 690V/500VDC 63A

Reference 5014534.63.0 - Manufacturer SIBA
Class gRL, gS
Rated current In (A) 63
Rated Voltage Un AC (V) 690
Applicable standards IEC, UL
Power loss (W) 6,8
Fuse Dimension (mm) 22x58
Melting I²t value (A²s) 1300
Fuse Connection/Terminal type Screw fixing
Voltage of total clearing I2t test 690
Total clearing I²t @Un AC (A²s) 10500
Rated breaking capacity I1 AC (kA) 200000
Price List €105.46/pc
Quantity
Fuse 22x58 with terminals 80mm gRL 690V/500VDC 50A

Fuse 22x58 with terminals 80mm gRL 690V/500VDC 50A

Reference 5014534.50.0 - Manufacturer SIBA
Class gRL, gS
Rated current In (A) 50
Rated Voltage Un AC (V) 690
Applicable standards IEC, UL
Power loss (W) 5,4
Fuse Dimension (mm) 22x58
Melting I²t value (A²s) 870
Fuse Connection/Terminal type Screw fixing
Voltage of total clearing I2t test 690
Total clearing I²t @Un AC (A²s) 7000
Rated breaking capacity I1 AC (kA) 200000
Product available on request Ask for more information
Fuse 22x58 with terminals 80mm gRL 690V/500VDC 40A

Fuse 22x58 with terminals 80mm gRL 690V/500VDC 40A

Reference 5014534.40.0 - Manufacturer SIBA
Class gRL, gS
Rated current In (A) 40
Rated Voltage Un AC (V) 690
Applicable standards IEC, UL
Power loss (W) 5,2
Fuse Dimension (mm) 22x58
Melting I²t value (A²s) 420
Fuse Connection/Terminal type Screw fixing
Voltage of total clearing I2t test 690
Total clearing I²t @Un AC (A²s) 3400
Rated breaking capacity I1 AC (kA) 200000
Price List €105.46/pc
Quantity
Fuse 22x58 with terminals 80mm gRL 690V/500VDC 35A

Fuse 22x58 with terminals 80mm gRL 690V/500VDC 35A

Reference 5014534.35.0 - Manufacturer SIBA
Class gRL, gS
Rated current In (A) 35
Rated Voltage Un AC (V) 690
Applicable standards IEC, UL
Power loss (W) 5
Fuse Dimension (mm) 22x58
Melting I²t value (A²s) 370
Fuse Connection/Terminal type Screw fixing
Voltage of total clearing I2t test 690
Total clearing I²t @Un AC (A²s) 3000
Rated breaking capacity I1 AC (kA) 200000
Product available on request Ask for more information
Fuse 22x58 with terminals 80mm gRL 690V/500VDC 25A

Fuse 22x58 with terminals 80mm gRL 690V/500VDC 25A

Reference 5014534.25.0 - Manufacturer SIBA
Class gRL, gS
Rated current In (A) 25
Rated Voltage Un AC (V) 690
Applicable standards IEC, UL
Power loss (W) 3,6
Fuse Dimension (mm) 22x58
Melting I²t value (A²s) 100
Fuse Connection/Terminal type Screw fixing
Voltage of total clearing I2t test 690
Total clearing I²t @Un AC (A²s) 800
Rated breaking capacity I1 AC (kA) 200000
Price List €85.25/pc
Quantity
Fuse 22x58 with terminals 80mm gR 690V 80A

Fuse 22x58 with terminals 80mm gR 690V 80A

Reference 5014506.80.0 - Manufacturer SIBA
Class gR
Rated current In (A) 80
Rated Voltage Un AC (V) 690
Applicable standards IEC, UL
Power loss (W) 18
Fuse Dimension (mm) 22x58
Melting I²t value (A²s) 1000
Fuse Connection/Terminal type Screw fixing
Voltage of total clearing I2t test 660
Total clearing I²t @Un AC (A²s) 4400
Rated breaking capacity I1 AC (kA) 200000
Weight (gr) 80
Price List €34.31/pc
Quantity
lock Datasheet
Fuse 22x58 with terminals 80mm gRL 690V/500VDC 100A

Fuse 22x58 with terminals 80mm gRL 690V/500VDC 100A

Reference 5014534.100.0 - Manufacturer SIBA
Class gRL, gS
Rated current In (A) 100
Rated Voltage Un AC (V) 690
Applicable standards IEC, UL
Power loss (W) 9,7
Fuse Dimension (mm) 22x58
Melting I²t value (A²s) 4600
Fuse Connection/Terminal type Screw fixing
Voltage of total clearing I2t test 690
Total clearing I²t @Un AC (A²s) 37000
Rated breaking capacity I1 AC (kA) 200000
Price List €123.86/pc
Quantity
Fuse 22x58 gR 690V UL with striker 40A

Fuse 22x58 gR 690V UL with striker 40A

Reference 5014206.40.0 - Manufacturer SIBA
Class gR
Rated current In (A) 40
Rated Voltage Un AC (V) 700
Applicable standards IEC, UL
Power loss (W) 12
Fuse Dimension (mm) 22x58
Melting I²t value (A²s) 140
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 660
Total clearing I²t @Un AC (A²s) 610
Rated breaking capacity I1 AC (kA) 200000
Weight (gr) 60
Price List €17.19/pc
Quantity
lock Datasheet
Fuse 22x58 with terminals 80mm gRL 690V/500VDC 30A

Fuse 22x58 with terminals 80mm gRL 690V/500VDC 30A

Reference 5014534.30.0 - Manufacturer SIBA
Class gRL, gS
Rated current In (A) 30
Rated Voltage Un AC (V) 690
Applicable standards IEC, UL
Power loss (W) 4,6
Fuse Dimension (mm) 22x58
Melting I²t value (A²s) 190
Fuse Connection/Terminal type Screw fixing
Voltage of total clearing I2t test 690
Total clearing I²t @Un AC (A²s) 1500
Rated breaking capacity I1 AC (kA) 200000
Price List €83.82/pc
Quantity
