List of products by manufacturer SIBA

Fuse 22x58 gR 690V UL with striker 16A

Fuse 22x58 gR 690V UL with striker 16A

Reference 5014206.16.0 - Manufacturer SIBA
Class gR
Rated current In (A) 16
Rated Voltage Un AC (V) 700
Applicable standards IEC, UL
Power loss (W) 5,5
Fuse Dimension (mm) 22x58
Melting I²t value (A²s) 12
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 660
Total clearing I²t @Un AC (A²s) 53
Rated breaking capacity I1 AC (kA) 200000
Weight (gr) 60
Price List €14.65/pc
Quantity
lock Datasheet
Fuse 22x58 gR 690V UL with striker 25A

Fuse 22x58 gR 690V UL with striker 25A

Reference 5014206.25.0 - Manufacturer SIBA
Class gR
Rated current In (A) 25
Rated Voltage Un AC (V) 700
Applicable standards IEC, UL
Power loss (W) 7,2
Fuse Dimension (mm) 22x58
Melting I²t value (A²s) 32
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 660
Total clearing I²t @Un AC (A²s) 140
Rated breaking capacity I1 AC (kA) 200000
Weight (gr) 60
Price List €14.91/pc
Quantity
lock Datasheet
Fuse 22x58 gR 690V UL with striker 32A

Fuse 22x58 gR 690V UL with striker 32A

Reference 5014206.32.0 - Manufacturer SIBA
Class gR
Rated current In (A) 32
Rated Voltage Un AC (V) 700
Applicable standards IEC, UL
Power loss (W) 9,6
Fuse Dimension (mm) 22x58
Melting I²t value (A²s) 63
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 660
Total clearing I²t @Un AC (A²s) 315
Rated breaking capacity I1 AC (kA) 200000
Weight (gr) 60
Price List €14.09/pc
Quantity
lock Datasheet
Fuse 22x58 with terminals 80mm gR 690V 32A

Fuse 22x58 with terminals 80mm gR 690V 32A

Reference 5014506.32.0 - Manufacturer SIBA
Class gR
Rated current In (A) 32
Rated Voltage Un AC (V) 690
Applicable standards IEC, UL
Power loss (W) 9,6
Fuse Dimension (mm) 22x58
Melting I²t value (A²s) 63
Fuse Connection/Terminal type Screw fixing
Voltage of total clearing I2t test 660
Total clearing I²t @Un AC (A²s) 315
Rated breaking capacity I1 AC (kA) 200000
Weight (gr) 90
Price List €21.25/pc
Quantity
lock Datasheet
Fuse 22x58 with terminals 80mm gR 690V 63A

Fuse 22x58 with terminals 80mm gR 690V 63A

Reference 5014506.63.0 - Manufacturer SIBA
Class gR
Rated current In (A) 63
Rated Voltage Un AC (V) 690
Applicable standards IEC, UL
Power loss (W) 16
Fuse Dimension (mm) 22x58
Melting I²t value (A²s) 510
Fuse Connection/Terminal type Screw fixing
Voltage of total clearing I2t test 660
Total clearing I²t @Un AC (A²s) 2260
Rated breaking capacity I1 AC (kA) 200000
Weight (gr) 80
Price List €31.94/pc
Quantity
lock Datasheet
Fuse 22x58 with terminals 80mm gR 690V 6A

Fuse 22x58 with terminals 80mm gR 690V 6A

Reference 5014506.6.0 - Manufacturer SIBA
Class gR
Rated current In (A) 6
Rated Voltage Un AC (V) 690
Applicable standards IEC, UL
Power loss (W) 3
Fuse Dimension (mm) 22x58
Melting I²t value (A²s) 2
Fuse Connection/Terminal type Screw fixing
Voltage of total clearing I2t test 660
Total clearing I²t @Un AC (A²s) 10
Rated breaking capacity I1 AC (kA) 200000
Weight (gr) 80
Price List €154.63/pc
Quantity
lock Datasheet
Fuse 22x58 with terminals 80mm gR 690V 50A

Fuse 22x58 with terminals 80mm gR 690V 50A

Reference 5014506.50.0 - Manufacturer SIBA
Class gR
Rated current In (A) 50
Rated Voltage Un AC (V) 690
Applicable standards IEC, UL
Power loss (W) 15
Fuse Dimension (mm) 22x58
Melting I²t value (A²s) 210
Fuse Connection/Terminal type Screw fixing
Voltage of total clearing I2t test 660
Total clearing I²t @Un AC (A²s) 910
Rated breaking capacity I1 AC (kA) 200000
Weight (gr) 80
Price List €25.32/pc
Quantity
lock Datasheet
Fuse 22x58 with terminals 80mm gR 690V 40A

Fuse 22x58 with terminals 80mm gR 690V 40A

Reference 5014506.40.0 - Manufacturer SIBA
Class gR
Rated current In (A) 40
Rated Voltage Un AC (V) 690
Applicable standards IEC, UL
Power loss (W) 12
Fuse Dimension (mm) 22x58
Melting I²t value (A²s) 140
Fuse Connection/Terminal type Screw fixing
Voltage of total clearing I2t test 660
Total clearing I²t @Un AC (A²s) 610
Rated breaking capacity I1 AC (kA) 200000
Weight (gr) 80
Price List €24.58/pc
Quantity
lock Datasheet
Fuse 22x58 with terminals 80mm gR 690V 4A

Fuse 22x58 with terminals 80mm gR 690V 4A

Reference 5014506.4.0 - Manufacturer SIBA
Class gR
Rated current In (A) 4
Rated Voltage Un AC (V) 690
Applicable standards IEC, UL
Fuse Dimension (mm) 22x58
Fuse Connection/Terminal type Screw fixing
Voltage of total clearing I2t test 660
Rated breaking capacity I1 AC (kA) 200000
Weight (gr) 80
Price List €154.53/pc
Quantity
lock Datasheet
Fuse 22x58 with terminals 80mm gR 690V 20A

Fuse 22x58 with terminals 80mm gR 690V 20A

Reference 5014506.20.0 - Manufacturer SIBA
Class gR
Rated current In (A) 20
Rated Voltage Un AC (V) 690
Applicable standards IEC, UL
Power loss (W) 6
Fuse Dimension (mm) 22x58
Melting I²t value (A²s) 21
Fuse Connection/Terminal type Screw fixing
Voltage of total clearing I2t test 660
Total clearing I²t @Un AC (A²s) 91
Rated breaking capacity I1 AC (kA) 200000
Weight (gr) 80
Price List €155.56/pc
Quantity
lock Datasheet
Fuse 22x58 with terminals 80mm gR 690V 16A

Fuse 22x58 with terminals 80mm gR 690V 16A

Reference 5014506.16.0 - Manufacturer SIBA
Class gR
Rated current In (A) 16
Rated Voltage Un AC (V) 690
Applicable standards IEC, UL
Power loss (W) 5,5
Fuse Dimension (mm) 22x58
Melting I²t value (A²s) 12
Fuse Connection/Terminal type Screw fixing
Voltage of total clearing I2t test 660
Total clearing I²t @Un AC (A²s) 52
Rated breaking capacity I1 AC (kA) 200000
Weight (gr) 80
Price List €155.30/pc
Quantity
lock Datasheet
Fuse 22x58 with terminals 80mm gR 690V 2A

Fuse 22x58 with terminals 80mm gR 690V 2A

Reference 5014506.2.0 - Manufacturer SIBA
Class gR
Rated current In (A) 2
Rated Voltage Un AC (V) 690
Applicable standards IEC, UL
Fuse Dimension (mm) 22x58
Fuse Connection/Terminal type Screw fixing
Voltage of total clearing I2t test 660
Rated breaking capacity I1 AC (kA) 200000
Weight (gr) 80
Price List €154.53/pc
Quantity
lock Datasheet
