List of products by manufacturer SIBA

Fuse 7,2kV 63,5x254 F01 oiltight 31,5A

Fuse 7,2kV 63,5x254 F01 oiltight 31,5A

Reference 3013236.31,5.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 31,5
Rated Voltage Un AC (V) 7200
Applicable standards IEC
Fuse Dimension (mm) 63,5x254
Melting I²t value (A²s) 1000
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 7200
Total clearing I²t @Un AC (A²s) 10000
Rated breaking capacity I1 AC (kA) 40000
Weight (gr) 1780
Price List €112.30/pc
Quantity
lock Datasheet
Fuse 7,2kV 63,5x254 F01 oiltight 40A

Fuse 7,2kV 63,5x254 F01 oiltight 40A

Reference 3013236.40.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 40
Rated Voltage Un AC (V) 7200
Applicable standards IEC
Fuse Dimension (mm) 63,5x254
Melting I²t value (A²s) 2300
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 7200
Total clearing I²t @Un AC (A²s) 22300
Rated breaking capacity I1 AC (kA) 40000
Weight (gr) 1940
Price List €225.55/pc
Quantity
lock Datasheet
Fuse 7,2kV 63,5x254 F01 oiltight 50A

Fuse 7,2kV 63,5x254 F01 oiltight 50A

Reference 3013236.50.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 50
Rated Voltage Un AC (V) 7200
Applicable standards IEC
Fuse Dimension (mm) 63,5x254
Melting I²t value (A²s) 2800
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 7200
Total clearing I²t @Un AC (A²s) 36000
Rated breaking capacity I1 AC (kA) 40000
Weight (gr) 1940
Price List €236.25/pc
Quantity
lock Datasheet
Fuse 7,2kV 63,5x254 F01 oiltight 6,3A

Fuse 7,2kV 63,5x254 F01 oiltight 6,3A

Reference 3013236.6,3.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 6,3
Rated Voltage Un AC (V) 7200
Applicable standards IEC
Fuse Dimension (mm) 63,5x254
Melting I²t value (A²s) 14
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 7200
Total clearing I²t @Un AC (A²s) 140
Rated breaking capacity I1 AC (kA) 40000
Weight (gr) 1780
Price List €295.73/pc
Quantity
lock Datasheet
Fuse 7,2kV 63,5x254 F01 oiltight 63A

Fuse 7,2kV 63,5x254 F01 oiltight 63A

Reference 3013236.63.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 63
Rated Voltage Un AC (V) 7200
Applicable standards IEC
Fuse Dimension (mm) 63,5x254
Melting I²t value (A²s) 6500
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 7200
Total clearing I²t @Un AC (A²s) 65500
Rated breaking capacity I1 AC (kA) 40000
Weight (gr) 2058
Price List €238.30/pc
Quantity
lock Datasheet
Fuse 7,2kV 63,5x254 F01 oiltight 80A

Fuse 7,2kV 63,5x254 F01 oiltight 80A

Reference 3013236.80.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 80
Rated Voltage Un AC (V) 7200
Applicable standards IEC
Fuse Dimension (mm) 63,5x254
Melting I²t value (A²s) 9900
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 7200
Total clearing I²t @Un AC (A²s) 100000
Rated breaking capacity I1 AC (kA) 40000
Weight (gr) 1780
Price List €246.69/pc
Quantity
lock Datasheet
Fuse 7,2kV 63,5x254 F01 oiltight 90A

Fuse 7,2kV 63,5x254 F01 oiltight 90A

Reference 3013236.90.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 90
Rated Voltage Un AC (V) 7200
Applicable standards IEC
Fuse Dimension (mm) 63,5x254
Melting I²t value (A²s) 15500
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 7200
Total clearing I²t @Un AC (A²s) 157000
Rated breaking capacity I1 AC (kA) 40000
Weight (gr) 1780
Product available on request Ask for more information
Fuse 7,2kV 76x254 back-up FA1 80A

Fuse 7,2kV 76x254 back-up FA1 80A

Reference 3013536.80.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 80
Rated Voltage Un AC (V) 7200
Applicable standards IEC
Fuse Dimension (mm) 76x254
Melting I²t value (A²s) 27200
Fuse Connection/Terminal type BS
Voltage of total clearing I2t test 7200
Total clearing I²t @Un AC (A²s) 81000
Rated breaking capacity I1 AC (kA) 40000
Product available on request Ask for more information
Fuse 7,2kV 76x254 back-up FA1 100A

Fuse 7,2kV 76x254 back-up FA1 100A

Reference 3013536.100.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 100
Rated Voltage Un AC (V) 7200
Applicable standards IEC
Fuse Dimension (mm) 76x254
Melting I²t value (A²s) 52900
Fuse Connection/Terminal type BS
Voltage of total clearing I2t test 7200
Total clearing I²t @Un AC (A²s) 158000
Rated breaking capacity I1 AC (kA) 40000
Product available on request Ask for more information
Fuse 12kV 51x254 back-up 16A

Fuse 12kV 51x254 back-up 16A

Reference 3014136.16.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 16
Rated Voltage Un AC (V) 12000
Applicable standards IEC
Fuse Dimension (mm) 51x254
Melting I²t value (A²s) 270
Fuse Connection/Terminal type BS
Voltage of total clearing I2t test 12000
Total clearing I²t @Un AC (A²s) 800
Rated breaking capacity I1 AC (kA) 40000
Product available on request Ask for more information
Fuse 12kV 51x254 back-up 10A

Fuse 12kV 51x254 back-up 10A

Reference 3014136.10.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 10
Rated Voltage Un AC (V) 12000
Applicable standards IEC
Fuse Dimension (mm) 51x254
Melting I²t value (A²s) 120
Fuse Connection/Terminal type BS
Voltage of total clearing I2t test 12000
Total clearing I²t @Un AC (A²s) 340
Rated breaking capacity I1 AC (kA) 40000
Product available on request Ask for more information
Fuse 7,2kV 76x359 back-up FA2 160A

Fuse 7,2kV 76x359 back-up FA2 160A

Reference 3013736.160.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 160
Rated Voltage Un AC (V) 7200
Applicable standards IEC
Fuse Dimension (mm) 76x359
Melting I²t value (A²s) 126000
Fuse Connection/Terminal type BS
Voltage of total clearing I2t test 7200
Total clearing I²t @Un AC (A²s) 378000
Rated breaking capacity I1 AC (kA) 40000
Weight (gr) 2000
Price List €422.84/pc
Quantity
lock Datasheet
Fuse 7,2kV 76x359 back-up FA2 125A

Fuse 7,2kV 76x359 back-up FA2 125A

Reference 3013736.125.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 125
Rated Voltage Un AC (V) 7200
Applicable standards IEC
Fuse Dimension (mm) 76x359
Melting I²t value (A²s) 81000
Fuse Connection/Terminal type BS
Voltage of total clearing I2t test 7200
Total clearing I²t @Un AC (A²s) 241000
Rated breaking capacity I1 AC (kA) 40000
Weight (gr) 2000
Product available on request Ask for more information
Fuse 7,2kV 76x359 back-up FA2 100A

Fuse 7,2kV 76x359 back-up FA2 100A

Reference 3013736.100.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 100
Rated Voltage Un AC (V) 7200
Applicable standards IEC
Fuse Dimension (mm) 76x359
Melting I²t value (A²s) 52900
Fuse Connection/Terminal type BS
Voltage of total clearing I2t test 7200
Total clearing I²t @Un AC (A²s) 158000
Rated breaking capacity I1 AC (kA) 40000
Weight (gr) 2000
Price List €378.16/pc
Quantity
lock Datasheet
Fuse 7,2kV 76x359 back-up FA2 140A

Fuse 7,2kV 76x359 back-up FA2 140A

Reference 3013736.140.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 140
Rated Voltage Un AC (V) 7200
Applicable standards IEC
Fuse Dimension (mm) 76x359
Melting I²t value (A²s) 100000
Fuse Connection/Terminal type BS
Voltage of total clearing I2t test 7200
Total clearing I²t @Un AC (A²s) 300000
Rated breaking capacity I1 AC (kA) 40000
Weight (gr) 2000
Product available on request Ask for more information
Fuse DIN Motors 12kV 87x442 striker no temp-limit 250A

Fuse DIN Motors 12kV 87x442 striker no temp-limit 250A

Reference 3010354.250LM.0 - Manufacturer SIBA
Class HH Motors
Rated current In (A) 250
Rated Voltage Un AC (V) 12000
Applicable standards IEC
Power loss (W) 120
Fuse Dimension (mm) 87x442
Melting I²t value (A²s) 307000
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 12000
Total clearing I²t @Un AC (A²s) 1900000
Rated breaking capacity I1 AC (kA) 63000
Weight (gr) 5671
Price List €666.88/pc
Quantity
lock Datasheet
Fuse DIN Motors 12kV 85x442 +striker no temp-limit 200A

Fuse DIN Motors 12kV 85x442 +striker no temp-limit 200A

Reference 3010354.200.0 - Manufacturer SIBA
Class HH Motors
Rated current In (A) 200
Rated Voltage Un AC (V) 12000
Applicable standards IEC
Power loss (W) 134
Fuse Dimension (mm) 85x442
Melting I²t value (A²s) 121000
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 12000
Total clearing I²t @Un AC (A²s) 789000
Rated breaking capacity I1 AC (kA) 63000
Weight (gr) 5671
Price List €489.02/pc
Quantity
lock Datasheet
Fuse DIN Motors 12kV 85x442 with striker 160A 80N

Fuse DIN Motors 12kV 85x442 with striker 160A 80N

Reference 3010353.160.0 - Manufacturer SIBA
Class HH Motors
Rated current In (A) 160
Rated Voltage Un AC (V) 12000
Applicable standards IEC
Power loss (W) 126
Fuse Dimension (mm) 85x442
Melting I²t value (A²s) 64000
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 12000
Total clearing I²t @Un AC (A²s) 417000
Rated breaking capacity I1 AC (kA) 63000
Weight (gr) 5600
Price List €389.78/pc
Quantity
lock Datasheet
Fuse 12kV 85x442 SSK with striker 160A 80N

Fuse 12kV 85x442 SSK with striker 160A 80N

Reference 3010343.160.0 - Manufacturer SIBA
Class HH SSK
Rated current In (A) 160
Rated Voltage Un AC (V) 12000
Applicable standards IEC
Power loss (W) 125
Resistance (ohm) 4,5
Fuse Dimension (mm) 85x442
Melting I²t value (A²s) 50000
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 12000
Total clearing I²t @Un AC (A²s) 405000
Rated breaking capacity I1 AC (kA) 63000
Weight (gr) 5720
Price List €305.98/pc
Quantity
Fuse 12kV 85x442 back-up striker no temp.lim200ARC180

Fuse 12kV 85x442 back-up striker no temp.lim200ARC180

Reference 3010314.200.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 200
Rated Voltage Un AC (V) 6000
Applicable standards IEC
Power loss (W) 134
Resistance (ohm) 0,0027
Fuse Dimension (mm) 85x442
Melting I²t value (A²s) 227800
Minimum breaking current (A) 870
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 5220
Total clearing I²t @Un AC (A²s) 1300000
Rated breaking capacity I1 AC (kA) 80000
Weight (gr) 5700
Price List €347.52/pc
Quantity
lock Datasheet
Fuse 12kV 87x442 full range with striker 125A 80N

Fuse 12kV 87x442 full range with striker 125A 80N

Reference 3010303.125.0 - Manufacturer SIBA
Class HHD full
Rated current In (A) 125
Rated Voltage Un AC (V) 12000
Applicable standards IEC
Power loss (W) 122
Resistance (ohm) 4,8
Fuse Dimension (mm) 87x442
Melting I²t value (A²s) 39200
Fuse Connection/Terminal type Cylindrical
Total clearing I²t @Un AC (A²s) 141000
Rated breaking capacity I1 AC (kA) 80000
Price List €1,535.95/pc
Quantity
lock Datasheet
Fuse 12kV 85x442 back-up with striker 160ARC140 80N

Fuse 12kV 85x442 back-up with striker 160ARC140 80N

Reference 3010313.160.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 160
Rated Voltage Un AC (V) 6000
Applicable standards IEC
Power loss (W) 117
Resistance (ohm) 0,004
Fuse Dimension (mm) 85x442
Melting I²t value (A²s) 78000
Minimum breaking current (A) 600
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 5220
Total clearing I²t @Un AC (A²s) 650000
Rated breaking capacity I1 AC (kA) 80000
Weight (gr) 5730
Price List €263.01/pc
Quantity
lock Datasheet
Fuse 12kV 85x442 SSK with striker 125A 80N

Fuse 12kV 85x442 SSK with striker 125A 80N

Reference 3010343.125.0 - Manufacturer SIBA
Class HH SSK
Rated current In (A) 125
Rated Voltage Un AC (V) 12000
Applicable standards IEC
Power loss (W) 128
Resistance (ohm) 4,8
Fuse Dimension (mm) 85x442
Melting I²t value (A²s) 39000
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 12000
Total clearing I²t @Un AC (A²s) 323000
Rated breaking capacity I1 AC (kA) 63000
Weight (gr) 5720
Price List €544.45/pc
Quantity
Fuse 12kV 87x442 back-up striker no temp.lim250ARC200

Fuse 12kV 87x442 back-up striker no temp.lim250ARC200

Reference 3010314.250LM.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 250
Rated Voltage Un AC (V) 6000
Applicable standards IEC
Power loss (W) 148
Resistance (ohm) 0,0024
Fuse Dimension (mm) 85x442
Melting I²t value (A²s) 265700
Minimum breaking current (A) 1000
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 5220
Total clearing I²t @Un AC (A²s) 1800000
Rated breaking capacity I1 AC (kA) 80000
Price List €606.83/pc
Quantity
lock Datasheet
Product added to compare.
Product added to wishlist
