List of products by manufacturer SIBA

Fuse DIN Motors 3.6kV 85x292 with striker 355A 120N

Fuse DIN Motors 3.6kV 85x292 with striker 355A 120N

Reference 3020054.355.0 - Manufacturer SIBA
Class HH Motors
Rated current In (A) 355
Rated Voltage Un AC (V) 3600
Applicable standards IEC
Power loss (W) 75
Fuse Dimension (mm) 85x292
Melting I²t value (A²s) 615000
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 50000
Total clearing I²t @Un AC (A²s) 1500000
Rated breaking capacity I1 AC (kA) 50000
Weight (gr) 3800
Product available on request Ask for more information
Fuse DIN Motors 3.6kV 85x292 with striker 315A 120N

Fuse DIN Motors 3.6kV 85x292 with striker 315A 120N

Reference 3020054.315.0 - Manufacturer SIBA
Class HH Motors
Rated current In (A) 315
Rated Voltage Un AC (V) 3600
Applicable standards IEC
Power loss (W) 75
Fuse Dimension (mm) 85x292
Melting I²t value (A²s) 615000
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 50000
Total clearing I²t @Un AC (A²s) 1500000
Rated breaking capacity I1 AC (kA) 50000
Weight (gr) 3890
Price List €645.58/pc
Quantity
lock Datasheet
Fuse DIN Motors 3.6kV 85x292 with striker 250A 120N

Fuse DIN Motors 3.6kV 85x292 with striker 250A 120N

Reference 3020054.250.0 - Manufacturer SIBA
Class HH Motors
Rated current In (A) 250
Rated Voltage Un AC (V) 3600
Applicable standards IEC
Power loss (W) 64
Fuse Dimension (mm) 85x292
Melting I²t value (A²s) 307000
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 50000
Total clearing I²t @Un AC (A²s) 952000
Rated breaking capacity I1 AC (kA) 50000
Weight (gr) 3890
Price List €632.31/pc
Quantity
lock Datasheet
Fuse DIN Motors 3.6kV 85x292 with striker 224A 120N

Fuse DIN Motors 3.6kV 85x292 with striker 224A 120N

Reference 3020054.224.0 - Manufacturer SIBA
Class HH Motors
Rated current In (A) 224
Rated Voltage Un AC (V) 3600
Applicable standards IEC
Power loss (W) 61
Fuse Dimension (mm) 85x292
Melting I²t value (A²s) 144000
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 50000
Total clearing I²t @Un AC (A²s) 448000
Rated breaking capacity I1 AC (kA) 50000
Weight (gr) 3380
Price List €563.38/pc
Quantity
lock Datasheet
Fuse DIN Motors 3.6kV 85x292 with striker 200A 120N

Fuse DIN Motors 3.6kV 85x292 with striker 200A 120N

Reference 3020054.200.0 - Manufacturer SIBA
Class HH Motors
Rated current In (A) 200
Rated Voltage Un AC (V) 3600
Applicable standards IEC
Power loss (W) 58
Fuse Dimension (mm) 85x292
Melting I²t value (A²s) 121000
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 50000
Total clearing I²t @Un AC (A²s) 376000
Rated breaking capacity I1 AC (kA) 50000
Weight (gr) 3890
Price List €535.84/pc
Quantity
lock Datasheet
Fuse 24kV 85x537 back-up with striker 200ARC125 120N

Fuse 24kV 85x537 back-up with striker 200ARC125 120N

Reference 3019614.200.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 200
Rated Voltage Un AC (V) 24000
Applicable standards IEC
Power loss (W) 187
Resistance (ohm) 0,0093
Fuse Dimension (mm) 85x537
Melting I²t value (A²s) 75000
Minimum breaking current (A) 800
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 20880
Total clearing I²t @Un AC (A²s) 313000
Rated breaking capacity I1 AC (kA) 63000
Weight (gr) 6800
Price List €706.92/pc
Quantity
lock Datasheet
Fuse 24kV 85x537 back-up +striker no temp-limiting 160A 120N

Fuse 24kV 85x537 back-up +striker no temp-limiting 160A 120N

Reference 3019614.160.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 160
Rated Voltage Un AC (V) 24000
Applicable standards IEC
Fuse Dimension (mm) 85x537
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 20880
Rated breaking capacity I1 AC (kA) 63000
Weight (gr) 6800
Price List €614.09/pc
Quantity
lock Datasheet
Fuse 24kV 85x537 back-up with striker 200A 80N

Fuse 24kV 85x537 back-up with striker 200A 80N

Reference 3019613.200.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 200
Rated Voltage Un AC (V) 24000
Applicable standards IEC
Fuse Dimension (mm) 85x537
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 20880
Rated breaking capacity I1 AC (kA) 63000
Weight (gr) 6800
Price List €687.01/pc
Quantity
lock Datasheet
Fuse 24kV 85x537 back-up with striker 125ARC100 80N

Fuse 24kV 85x537 back-up with striker 125ARC100 80N

Reference 3019613.125.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 125
Rated Voltage Un AC (V) 24000
Applicable standards IEC
Power loss (W) 179
Resistance (ohm) 0,011
Fuse Dimension (mm) 85x537
Melting I²t value (A²s) 38400
Minimum breaking current (A) 390
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 20880
Total clearing I²t @Un AC (A²s) 348000
Rated breaking capacity I1 AC (kA) 63000
Weight (gr) 6820
Price List €818.93/pc
Quantity
lock Datasheet
Fuse 36kV 53x442 back-up with striker 2,5A 80N

Fuse 36kV 53x442 back-up with striker 2,5A 80N

Reference 3018113.2,5.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 2,5
Rated Voltage Un AC (V) 36000
Applicable standards IEC
Power loss (W) 22
Resistance (ohm) 2,6
Fuse Dimension (mm) 53x442
Melting I²t value (A²s) 7,2
Minimum breaking current (A) 20
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 31320
Total clearing I²t @Un AC (A²s) 23
Rated breaking capacity I1 AC (kA) 40000
Weight (gr) 2320
Price List €435.61/pc
Quantity
lock Datasheet
Fuse 36kV 53x442 back-up with striker 2A 80N

Fuse 36kV 53x442 back-up with striker 2A 80N

Reference 3018113.2.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 2
Rated Voltage Un AC (V) 36000
Applicable standards IEC
Power loss (W) 23
Resistance (ohm) 4,26
Fuse Dimension (mm) 53x442
Melting I²t value (A²s) 3,2
Minimum breaking current (A) 16
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 31320
Total clearing I²t @Un AC (A²s) 9,8
Rated breaking capacity I1 AC (kA) 40000
Weight (gr) 2320
Price List €87.71/pc
Quantity
lock Datasheet
Fuse 36kV 53x442 back-up with striker 3,15A 80N

Fuse 36kV 53x442 back-up with striker 3,15A 80N

Reference 3018113.3,15.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 3,15
Rated Voltage Un AC (V) 36000
Applicable standards IEC
Power loss (W) 26
Resistance (ohm) 1,9
Fuse Dimension (mm) 53x442
Melting I²t value (A²s) 17
Minimum breaking current (A) 24
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 31320
Total clearing I²t @Un AC (A²s) 48
Rated breaking capacity I1 AC (kA) 40000
Weight (gr) 2320
Price List €516.25/pc
Quantity
lock Datasheet
Fuse 36kV 53x442 back-up with striker 4A 80N

Fuse 36kV 53x442 back-up with striker 4A 80N

Reference 3018113.4.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 4
Rated Voltage Un AC (V) 36000
Applicable standards IEC
Power loss (W) 33
Resistance (ohm) 1,42
Fuse Dimension (mm) 53x442
Melting I²t value (A²s) 31
Minimum breaking current (A) 32
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 31320
Total clearing I²t @Un AC (A²s) 90
Rated breaking capacity I1 AC (kA) 40000
Weight (gr) 2320
Price List €516.21/pc
Quantity
lock Datasheet
Fuse 36kV 53x442 back-up with striker 6,3A 80N

Fuse 36kV 53x442 back-up with striker 6,3A 80N

Reference 3018113.6,3.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 6,3
Rated Voltage Un AC (V) 36000
Applicable standards IEC
Power loss (W) 49
Resistance (ohm) 0,831
Fuse Dimension (mm) 53x442
Melting I²t value (A²s) 27
Minimum breaking current (A) 22
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 31320
Total clearing I²t @Un AC (A²s) 300
Rated breaking capacity I1 AC (kA) 20000
Weight (gr) 2320
Price List €153.50/pc
Quantity
lock Datasheet
Fuse 24kV 85x537 back-up with striker 100ARC90 80N

Fuse 24kV 85x537 back-up with striker 100ARC90 80N

Reference 3019613.100.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 100
Rated Voltage Un AC (V) 24000
Applicable standards IEC
Power loss (W) 167
Resistance (ohm) 0,013
Fuse Dimension (mm) 85x537
Melting I²t value (A²s) 28000
Minimum breaking current (A) 320
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 20880
Total clearing I²t @Un AC (A²s) 254000
Rated breaking capacity I1 AC (kA) 63000
Weight (gr) 6820
Price List €759.83/pc
Quantity
lock Datasheet
Fuse 24kV 85x537 back-up with striker 160ARC112 80N

Fuse 24kV 85x537 back-up with striker 160ARC112 80N

Reference 3019613.160.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 160
Rated Voltage Un AC (V) 24000
Applicable standards IEC
Power loss (W) 178
Resistance (ohm) 0,0088
Fuse Dimension (mm) 85x537
Melting I²t value (A²s) 62000
Minimum breaking current (A) 600
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 20880
Total clearing I²t @Un AC (A²s) 378000
Rated breaking capacity I1 AC (kA) 63000
Weight (gr) 6820
Price List €876.16/pc
Quantity
lock Datasheet
Fuse 36kV 53x442 back-up with striker 5A 80N

Fuse 36kV 53x442 back-up with striker 5A 80N

Reference 3018113.5.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 5
Rated Voltage Un AC (V) 36000
Applicable standards IEC
Power loss (W) 23
Resistance (ohm) 0,65
Fuse Dimension (mm) 53x442
Melting I²t value (A²s) 40
Minimum breaking current (A) 40
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 31320
Total clearing I²t @Un AC (A²s) 125
Rated breaking capacity I1 AC (kA) 40000
Weight (gr) 2320
Price List €516.26/pc
Quantity
lock Datasheet
Fuse 24kV 76x565mm back-up FA4 16A

Fuse 24kV 76x565mm back-up FA4 16A

Reference 3016136.16.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 16
Rated Voltage Un AC (V) 24000
Applicable standards IEC
Fuse Dimension (mm) 76x565
Melting I²t value (A²s) 270
Fuse Connection/Terminal type BS
Voltage of total clearing I2t test 24000
Total clearing I²t @Un AC (A²s) 800
Rated breaking capacity I1 AC (kA) 40000
Product available on request Ask for more information
Fuse 24kV 63,5x359 F02 oiltight 16A

Fuse 24kV 63,5x359 F02 oiltight 16A

Reference 3015636.16.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 16
Rated Voltage Un AC (V) 24000
Applicable standards IEC
Fuse Dimension (mm) 63,5x359
Melting I²t value (A²s) 190
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 24000
Total clearing I²t @Un AC (A²s) 1800
Rated breaking capacity I1 AC (kA) 40000
Weight (gr) 2450
Price List €266.61/pc
Quantity
lock Datasheet
Fuse 24kV 76x565mm back-up FA4 50A

Fuse 24kV 76x565mm back-up FA4 50A

Reference 3016136.50.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 50
Rated Voltage Un AC (V) 24000
Applicable standards IEC
Fuse Dimension (mm) 76x565
Melting I²t value (A²s) 8100
Fuse Connection/Terminal type BS
Voltage of total clearing I2t test 24000
Total clearing I²t @Un AC (A²s) 24000
Rated breaking capacity I1 AC (kA) 40000
Product available on request Ask for more information
Fuse 24kV 76x565mm back-up FA4 40A

Fuse 24kV 76x565mm back-up FA4 40A

Reference 3016136.40.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 40
Rated Voltage Un AC (V) 24000
Applicable standards IEC
Fuse Dimension (mm) 76x565
Melting I²t value (A²s) 4900
Fuse Connection/Terminal type BS
Voltage of total clearing I2t test 24000
Total clearing I²t @Un AC (A²s) 14800
Rated breaking capacity I1 AC (kA) 40000
Product available on request Ask for more information
Fuse 24kV 76x565mm back-up FA4 31,5A

Fuse 24kV 76x565mm back-up FA4 31,5A

Reference 3016136.31,5.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 31,5
Rated Voltage Un AC (V) 24000
Applicable standards IEC
Fuse Dimension (mm) 76x565
Melting I²t value (A²s) 2200
Fuse Connection/Terminal type BS
Voltage of total clearing I2t test 24000
Total clearing I²t @Un AC (A²s) 6500
Rated breaking capacity I1 AC (kA) 40000
Product available on request Ask for more information
Fuse 24kV 76x565mm back-up FA4 100A

Fuse 24kV 76x565mm back-up FA4 100A

Reference 3016136.100.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 100
Rated Voltage Un AC (V) 24000
Applicable standards IEC
Fuse Dimension (mm) 76x565
Melting I²t value (A²s) 52900
Fuse Connection/Terminal type BS
Voltage of total clearing I2t test 24000
Total clearing I²t @Un AC (A²s) 158000
Rated breaking capacity I1 AC (kA) 40000
Product available on request Ask for more information
Fuse 24kV 76x565mm back-up FA4 10A

Fuse 24kV 76x565mm back-up FA4 10A

Reference 3016136.10.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 10
Rated Voltage Un AC (V) 24000
Applicable standards IEC
Fuse Dimension (mm) 76x565
Melting I²t value (A²s) 120
Fuse Connection/Terminal type BS
Voltage of total clearing I2t test 24000
Total clearing I²t @Un AC (A²s) 340
Rated breaking capacity I1 AC (kA) 40000
Product available on request Ask for more information
Product added to compare.
Product added to wishlist
