List of products by manufacturer SIBA

Fuse 12kV 63,5x310 M8-M8 oiltight 6,3A

Fuse 12kV 63,5x310 M8-M8 oiltight 6,3A

Reference 3031011.6,3.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 6,3
Rated Voltage Un AC (V) 12000
Applicable standards IEC
Power loss (W) 16
Fuse Dimension (mm) 63,5x371
Melting I²t value (A²s) 45
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 12000
Total clearing I²t @Un AC (A²s) 360
Rated breaking capacity I1 AC (kA) 63000
Weight (gr) 2540
Price List €180.89/pc
Quantity
lock Datasheet
Fuse 12kV 63,5x371 M8-M8 oiltight 50A

Fuse 12kV 63,5x371 M8-M8 oiltight 50A

Reference 3031011.50.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 50
Rated Voltage Un AC (V) 12000
Applicable standards IEC
Power loss (W) 56
Fuse Dimension (mm) 63,5x371
Melting I²t value (A²s) 5700
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 12000
Total clearing I²t @Un AC (A²s) 33000
Rated breaking capacity I1 AC (kA) 63000
Weight (gr) 2540
Price List €171.08/pc
Quantity
lock Datasheet
Fuse 12kV 63,5x371 M8-M8 oiltight 40A

Fuse 12kV 63,5x371 M8-M8 oiltight 40A

Reference 3031011.40.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 40
Rated Voltage Un AC (V) 12000
Applicable standards IEC
Power loss (W) 50
Fuse Dimension (mm) 63,5x371
Melting I²t value (A²s) 2900
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 12000
Total clearing I²t @Un AC (A²s) 19000
Rated breaking capacity I1 AC (kA) 63000
Weight (gr) 2540
Product available on request Ask for more information
Fuse 12kV 63,5x371 M8-M8 oiltight 31,5A

Fuse 12kV 63,5x371 M8-M8 oiltight 31,5A

Reference 3031011.31,5.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 31,5
Rated Voltage Un AC (V) 12000
Applicable standards IEC
Power loss (W) 38
Fuse Dimension (mm) 63,5x371
Melting I²t value (A²s) 1700
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 12000
Total clearing I²t @Un AC (A²s) 12000
Rated breaking capacity I1 AC (kA) 63000
Weight (gr) 2540
Product available on request Ask for more information
Fuse 12kV 63,5x371 M8-M8 oiltight 25A

Fuse 12kV 63,5x371 M8-M8 oiltight 25A

Reference 3031011.25.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 25
Rated Voltage Un AC (V) 12000
Applicable standards IEC
Power loss (W) 29
Fuse Dimension (mm) 63,5x371
Melting I²t value (A²s) 1050
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 12000
Total clearing I²t @Un AC (A²s) 7500
Rated breaking capacity I1 AC (kA) 63000
Weight (gr) 2540
Price List €982.52/pc
Quantity
lock Datasheet
Fuse 12kV 63,5x371 M8-M8 oiltight 20A

Fuse 12kV 63,5x371 M8-M8 oiltight 20A

Reference 3031011.20.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 20
Rated Voltage Un AC (V) 12000
Applicable standards IEC
Power loss (W) 23
Fuse Dimension (mm) 63,5x371
Melting I²t value (A²s) 640
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 12000
Total clearing I²t @Un AC (A²s) 4800
Rated breaking capacity I1 AC (kA) 63000
Weight (gr) 2540
Product available on request Ask for more information
Fuse 12kV 63,5x371 M8-M8 oiltight 16A

Fuse 12kV 63,5x371 M8-M8 oiltight 16A

Reference 3031011.16.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 16
Rated Voltage Un AC (V) 12000
Applicable standards IEC
Power loss (W) 28
Fuse Dimension (mm) 63,5x371
Melting I²t value (A²s) 250
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 12000
Total clearing I²t @Un AC (A²s) 2000
Rated breaking capacity I1 AC (kA) 63000
Weight (gr) 2540
Price List €186.25/pc
Quantity
lock Datasheet
Fuse 12kV 63,5x371 M8-M8 oiltight 125A

Fuse 12kV 63,5x371 M8-M8 oiltight 125A

Reference 3031011.125.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 125
Rated Voltage Un AC (V) 12000
Applicable standards IEC
Power loss (W) 181
Fuse Dimension (mm) 63,5x371
Melting I²t value (A²s) 56500
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 12000
Total clearing I²t @Un AC (A²s) 565000
Rated breaking capacity I1 AC (kA) 63000
Weight (gr) 2540
Price List €161.58/pc
Quantity
lock Datasheet
Fuse 12kV 63,5x371 M8-M8 oiltight 100A

Fuse 12kV 63,5x371 M8-M8 oiltight 100A

Reference 3031011.100.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 100
Rated Voltage Un AC (V) 12000
Applicable standards IEC
Power loss (W) 136
Fuse Dimension (mm) 63,5x371
Melting I²t value (A²s) 41500
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 12000
Total clearing I²t @Un AC (A²s) 415000
Rated breaking capacity I1 AC (kA) 63000
Weight (gr) 2540
Price List €1,049.59/pc
Quantity
lock Datasheet
Fuse 213x27 3000V DC 2A

Fuse 213x27 3000V DC 2A

Reference 3030801.2.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 2
Power loss (W) 1,3
Rated Voltage Un DC (V) 3000
Time costant L/R (ms) 10
Rated breaking capacity I1 DC (kA) 50000
Fuse Dimension (mm) 27x213
Melting I²t value (A²s) 3,1
Fuse Connection/Terminal type Cylindrical
Weight (gr) 480
Product available on request Ask for more information
Fuse 213x27 3000V DC 6,3A

Fuse 213x27 3000V DC 6,3A

Reference 3030801.6,3.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 6,3
Power loss (W) 6,2
Rated Voltage Un DC (V) 3000
Time costant L/R (ms) 10
Rated breaking capacity I1 DC (kA) 50000
Fuse Dimension (mm) 27x213
Melting I²t value (A²s) 28
Fuse Connection/Terminal type Cylindrical
Weight (gr) 480
Product available on request Ask for more information
Fuse 12kV 63,5x371 M8-M8 oiltight 63A

Fuse 12kV 63,5x371 M8-M8 oiltight 63A

Reference 3031011.63.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 63
Rated Voltage Un AC (V) 12000
Applicable standards IEC
Power loss (W) 63
Fuse Dimension (mm) 63,5x371
Melting I²t value (A²s) 10700
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 12000
Total clearing I²t @Un AC (A²s) 66000
Rated breaking capacity I1 AC (kA) 63000
Weight (gr) 2540
Product available on request Ask for more information
Fuse BS Motors 12kV 553mm 80A

Fuse BS Motors 12kV 553mm 80A

Reference 3027456.80.0 - Manufacturer SIBA
Class HH Motors
Rated current In (A) 80
Rated Voltage Un AC (V) 12000
Applicable standards IEC
Power loss (W) 100
Melting I²t value (A²s) 6200
Fuse Connection/Terminal type BS
Voltage of total clearing I2t test 10500
Total clearing I²t @Un AC (A²s) 36500
Rated breaking capacity I1 AC (kA) 50000
Price List €141.41/pc
Quantity
lock Datasheet
Fuse BS Mot. 12kV double body 553mm 224A

Fuse BS Mot. 12kV double body 553mm 224A

Reference 3027556.224.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 224
Rated Voltage Un AC (V) 12000
Applicable standards IEC
Power loss (W) 188
Fuse Dimension (mm) 2x 553
Melting I²t value (A²s) 127000
Fuse Connection/Terminal type BS
Voltage of total clearing I2t test 10500
Total clearing I²t @Un AC (A²s) 717000
Rated breaking capacity I1 AC (kA) 50000
Weight (gr) 10800
Product available on request Ask for more information
Fuse BS Mot. 12kV double body 553mm 250A

Fuse BS Mot. 12kV double body 553mm 250A

Reference 3027556.250.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 250
Rated Voltage Un AC (V) 12000
Applicable standards IEC
Power loss (W) 210
Fuse Dimension (mm) 2x 553
Melting I²t value (A²s) 189000
Fuse Connection/Terminal type BS
Voltage of total clearing I2t test 10500
Total clearing I²t @Un AC (A²s) 1100000
Rated breaking capacity I1 AC (kA) 50000
Weight (gr) 10800
Price List €439.40/pc
Quantity
lock Datasheet
Fuse BS Mot. 12kV double body 553mm 315A

Fuse BS Mot. 12kV double body 553mm 315A

Reference 3027556.315.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 315
Rated Voltage Un AC (V) 12000
Applicable standards IEC
Power loss (W) 270
Fuse Dimension (mm) 2x 553
Melting I²t value (A²s) 257000
Fuse Connection/Terminal type BS
Voltage of total clearing I2t test 10500
Total clearing I²t @Un AC (A²s) 1450000
Rated breaking capacity I1 AC (kA) 50000
Weight (gr) 10800
Price List €692.28/pc
Quantity
lock Datasheet
Fuse BS Mot. 12kV double body 553mm 355A

Fuse BS Mot. 12kV double body 553mm 355A

Reference 3027556.355.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 355
Rated Voltage Un AC (V) 12000
Applicable standards IEC
Power loss (W) 305
Fuse Dimension (mm) 2x 553
Melting I²t value (A²s) 325000
Fuse Connection/Terminal type BS
Voltage of total clearing I2t test 10500
Total clearing I²t @Un AC (A²s) 1840000
Rated breaking capacity I1 AC (kA) 50000
Weight (gr) 10800
Price List €441.40/pc
Quantity
lock Datasheet
Fuse BS Mot. 12kV double body 553mm 400A

Fuse BS Mot. 12kV double body 553mm 400A

Reference 3027556.400.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 400
Rated Voltage Un AC (V) 12000
Applicable standards IEC
Power loss (W) 325
Fuse Dimension (mm) 2x 553
Melting I²t value (A²s) 486000
Fuse Connection/Terminal type BS
Voltage of total clearing I2t test 10500
Total clearing I²t @Un AC (A²s) 2740000
Rated breaking capacity I1 AC (kA) 50000
Weight (gr) 10800
Price List €748.33/pc
Quantity
lock Datasheet
Fuse 27kV 67x442 back-up with striker 20A 80N

Fuse 27kV 67x442 back-up with striker 20A 80N

Reference 3028813.20.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 20
Rated Voltage Un AC (V) 27000
Applicable standards IEC
Power loss (W) 49
Melting I²t value (A²s) 640
Minimum breaking current (A) 390
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 27000
Total clearing I²t @Un AC (A²s) 4800
Rated breaking capacity I1 AC (kA) 63000
Weight (gr) 3640
Price List €692.89/pc
Quantity
lock Datasheet
Fuse 27kV 67x442 back-up with striker 40A 80N

Fuse 27kV 67x442 back-up with striker 40A 80N

Reference 3028813.40.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 40
Rated Voltage Un AC (V) 27000
Applicable standards IEC
Power loss (W) 109
Melting I²t value (A²s) 2900
Minimum breaking current (A) 390
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 27000
Total clearing I²t @Un AC (A²s) 19000
Rated breaking capacity I1 AC (kA) 63000
Weight (gr) 3640
Price List €904.05/pc
Quantity
lock Datasheet
Fuse 27kV 67x442 back-up with striker 31,5A 80N

Fuse 27kV 67x442 back-up with striker 31,5A 80N

Reference 3028813.31,5.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 31,5
Rated Voltage Un AC (V) 27000
Applicable standards IEC
Power loss (W) 79
Melting I²t value (A²s) 1700
Minimum breaking current (A) 390
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 27000
Total clearing I²t @Un AC (A²s) 12000
Rated breaking capacity I1 AC (kA) 63000
Weight (gr) 3640
Price List €894.55/pc
Quantity
lock Datasheet
Fuse 27kV 67x442 back-up with striker 25A 80N

Fuse 27kV 67x442 back-up with striker 25A 80N

Reference 3028813.25.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 25
Rated Voltage Un AC (V) 27000
Applicable standards IEC
Power loss (W) 59
Melting I²t value (A²s) 1050
Minimum breaking current (A) 390
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 27000
Total clearing I²t @Un AC (A²s) 7500
Rated breaking capacity I1 AC (kA) 63000
Weight (gr) 3640
Price List €694.58/pc
Quantity
lock Datasheet
Fuse 27kV 85x442 back-up con percussore 100LM 80N

Fuse 27kV 85x442 back-up con percussore 100LM 80N

Reference 3028713.100LM.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 100
Rated Voltage Un AC (V) 27000
Applicable standards IEC
Power loss (W) 234
Melting I²t value (A²s) 33000
Minimum breaking current (A) 320
Fuse Connection/Terminal type Cylindrical
Total clearing I²t @Un AC (A²s) 210000
Rated breaking capacity I1 AC (kA) 63000
Price List €2,365.38/pc
Quantity
lock Datasheet
Fuse 27kV 85x442 back-up with striker 80A 80N

Fuse 27kV 85x442 back-up with striker 80A 80N

Reference 3028713.80.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 80
Rated Voltage Un AC (V) 27000
Applicable standards IEC
Power loss (W) 174
Melting I²t value (A²s) 21000
Minimum breaking current (A) 390
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 27000
Total clearing I²t @Un AC (A²s) 140000
Rated breaking capacity I1 AC (kA) 63000
Weight (gr) 5400
Price List €279.18/pc
Quantity
lock Datasheet
Product added to compare.
Product added to wishlist
