P103 - Fuse 550V DC EV with pins 40 AMP

P103 - Fuse 550V DC EV with pins 40 AMP

Reference 645.069.92.0.0 - Manufacturer FAULTRAP
Rated current In (A) 40
Applicable standards IEC
Power loss (W) 7,9
Rated Voltage Un DC (V) 550
Time costant L/R (ms) 2
Series name P103
Rated breaking capacity I1 DC (kA) 20000
Fuse Dimension (mm) 10x38
Melting I²t value (A²s) 195
Voltage of total clearing I2t test 550
Total clearing I²t @Un AC (A²s) 650
Product available on request Ask for more information
S276 - Fuse 27x60mm 500VAC gS PCB 160A

S276 - Fuse 27x60mm 500VAC gS PCB 160A

Reference 646.629.30.0.0 - Manufacturer FAULTRAP
Class gRL, gS
Rated current In (A) 160
Rated Voltage Un AC (V) 500
Applicable standards IEC
Power loss (W) 13
Series name S276
Rated breaking capacity I1 DC (kA) 100000
Fuse Dimension (mm) 27x60
Melting I²t value (A²s) 18500
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 550
Total clearing I²t @Un AC (A²s) 100000
Product available on request Ask for more information
AB22 - Fuse 22x65 1000VDC aBat 70A

AB22 - Fuse 22x65 1000VDC aBat 70A

Reference 648.814.66.0.0 - Manufacturer FAULTRAP
Class aBat
Rated current In (A) 70
Applicable standards IEC
Power loss (W) 12
Rated Voltage Un DC (V) 1000
Time costant L/R (ms) 1-3
Series name AB22
Rated breaking capacity I1 DC (kA) 10
Fuse Dimension (mm) 22x65
Melting I²t value (A²s) 2100
Minimum breaking current (A) 560
Fuse Connection/Terminal type Cylindrical
Total clearing I²t @Un DC (A²s) 11550
Product available on request Ask for more information
10TD - Fuse 10x38 400VAC aM/aR 20A

10TD - Fuse 10x38 400VAC aM/aR 20A

Reference 651.340.87.0.0 - Manufacturer FAULTRAP
Class aM, aR
Rated current In (A) 20
Rated Voltage Un AC (V) 400
Applicable standards IEC, UL
Series name 10TD
Fuse Dimension (mm) 10x38
Melting I²t value (A²s) 960
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 400
Total clearing I²t @Un AC (A²s) 2460
Rated breaking capacity I1 AC (kA) 50000
Product available on request Ask for more information
BP22 -Fuse 22x65mm cylindrical 10A

BP22 -Fuse 22x65mm cylindrical 10A

Reference 655.286.94.0.0 - Manufacturer FAULTRAP
Class gBat, gR
Rated current In (A) 10
Applicable standards IEC, UL
Power loss (W) 2,4
Rated Voltage Un DC (V) 1000
Series name BP22
Rated breaking capacity I1 DC (kA) 100000
Fuse Dimension (mm) 22x65
Fuse Connection/Terminal type Cylindrical
Total clearing I²t @Un AC (A²s) 10
Product available on request Ask for more information
B050 - Fuse 1000VDC aBat 500A - 118,85mm - Tin Plated

B050 - Fuse 1000VDC aBat 500A - 118,85mm - Tin Plated

Reference 655.460.05.0.0 - Manufacturer FAULTRAP
Class aBat, aR
Rated current In (A) 500
Applicable standards IEC, UL
Power loss (W) 66
Rated Voltage Un DC (V) 1000
Time costant L/R (ms) 2
Series name B050
Rated breaking capacity I1 DC (kA) 100
Fuse Dimension (mm) 50x141
Melting I²t value (A²s) 78500
Minimum breaking current (A) 5000
Fuse Connection/Terminal type Screw fixing
Fixing connection centres (mm) 118
Total clearing I²t @Un DC (A²s) 204000
Price List €122.07/pc
Quantity
lock Datasheet
ZPYT - Fuse holder 22x65 1250VAC/1500VDC 2P

ZPYT - Fuse holder 22x65 1250VAC/1500VDC 2P

Reference 656.687.70.0.0 - Manufacturer FAULTRAP
Rated current In (A) 100
Rated Voltage Un AC (V) 1250
Applicable standards IEC
Rated Voltage Un DC (V) 1500
Series name ZPYT
Fuse Dimension (mm) 22x65
Fuse Connection/Terminal type Cylindrical
Rated Power Acceptance 12
Number of poles 2
Weight (gr) 373
Price List €18.77/pc
Quantity
lock Datasheet
B050 - Fuse 1000VDC aBat 600A - 118,85mm - Tin Plated

B050 - Fuse 1000VDC aBat 600A - 118,85mm - Tin Plated

Reference 656.768.70.0.0 - Manufacturer FAULTRAP
Class aBat, aR
Rated current In (A) 600
Applicable standards IEC, UL
Power loss (W) 79
Rated Voltage Un DC (V) 1000
Time costant L/R (ms) 2
Series name B050
Rated breaking capacity I1 DC (kA) 100
Fuse Dimension (mm) 50x141
Melting I²t value (A²s) 134000
Minimum breaking current (A) 6000
Fuse Connection/Terminal type Screw fixing
Fixing connection centres (mm) 118
Total clearing I²t @Un DC (A²s) 350000
Product available on request Ask for more information
B200 - Fuse 38x73mm 1000VDC Axial aBat 250A

B200 - Fuse 38x73mm 1000VDC Axial aBat 250A

Reference 656.906.03.0.0 - Manufacturer FAULTRAP
Class aBat
Rated current In (A) 250
Applicable standards IEC
Power loss (W) 39
Rated Voltage Un DC (V) 1000
Time costant L/R (ms) 2
Series name B200
Rated breaking capacity I1 DC (kA) 50000
Fuse Dimension (mm) 38x73
Melting I²t value (A²s) 21000
Fuse Connection/Terminal type Screw fixing
Voltage of total clearing I2t test 1000
Total clearing I²t @Un AC (A²s) 79800
Product available on request Ask for more information
NR2A - Fuse DIN000 80mm aR 500VAC no ind 350A

NR2A - Fuse DIN000 80mm aR 500VAC no ind 350A

Reference 657.589.99.0.0 - Manufacturer FAULTRAP
Class aR
Rated current In (A) 350
Rated Voltage Un AC (V) 500
Dimension 000
Applicable standards IEC
Power loss (W) 80
Time costant L/R (ms) 2
Series name NR2A
Melting I²t value (A²s) 21500
Fuse Connection/Terminal type Screw fixing
Fixing connection centres (mm) 80
Voltage of total clearing I2t test 500
Total clearing I²t @Un AC (A²s) 92500
Rated breaking capacity I1 AC (kA) 200000
Product available on request Ask for more information
X100 - Fuse 22x65mm 1000VAC gG 50A

X100 - Fuse 22x65mm 1000VAC gG 50A

Reference 657.855.26.0.0 - Manufacturer FAULTRAP
Class gG
Rated current In (A) 50
Rated Voltage Un AC (V) 1000
Applicable standards IEC
Power loss (W) 8
Series name X100
Fuse Dimension (mm) 22x65
Melting I²t value (A²s) 740
Fuse Connection/Terminal type Cylindrical
Total clearing I²t @Un AC (A²s) 6300
Rated breaking capacity I1 AC (kA) 50
Product available on request Ask for more information
X800 - Fuse 22x65mm 800VAC gG 10A

X800 - Fuse 22x65mm 800VAC gG 10A

Reference 658.578.76.0.0 - Manufacturer FAULTRAP
Class gG
Rated current In (A) 10
Rated Voltage Un AC (V) 800
Applicable standards IEC
Power loss (W) 1,4
Series name X800
Fuse Dimension (mm) 22x65
Melting I²t value (A²s) 140
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 800
Total clearing I²t @Un AC (A²s) 1680
Rated breaking capacity I1 AC (kA) 80000
Price List €34.63/pc
Quantity
lock Datasheet
A145 - Fuse 14x51 690VAC aR 12A

A145 - Fuse 14x51 690VAC aR 12A

Reference 658.591.15.0.0 - Manufacturer FAULTRAP
Class aR
Rated current In (A) 12
Rated Voltage Un AC (V) 690
Applicable standards IEC
Power loss (W) 3,6
Series name A145
Fuse Dimension (mm) 14x51
Melting I²t value (A²s) 9
Fuse Connection/Terminal type Cylindrical
Total clearing I²t @Un AC (A²s) 78
Rated breaking capacity I1 AC (kA) 200
Price List €4.68/pc
Quantity
lock Datasheet
A145 - Fuse 14x51 690VAC aR 16A

A145 - Fuse 14x51 690VAC aR 16A

Reference 659.899.80.0.0 - Manufacturer FAULTRAP
Class aR
Rated current In (A) 16
Rated Voltage Un AC (V) 690
Applicable standards IEC
Power loss (W) 5.4
Series name A145
Fuse Dimension (mm) 14x51
Melting I²t value (A²s) 13
Fuse Connection/Terminal type Cylindrical
Total clearing I²t @Un AC (A²s) 120
Rated breaking capacity I1 AC (kA) 200
Price List €4.68/pc
Quantity
lock Datasheet
C200 - Fuse 690VAC aR 1100A size 2 61x52,4mm M10 flush...

C200 - Fuse 690VAC aR 1100A size 2 61x52,4mm M10 flush end terminals, with microswitch adapter

Reference 657.158.53.0.0 - Manufacturer FAULTRAP
Class aR
Rated current In (A) 1250
Rated Voltage Un AC (V) 600
Dimension SQB2
Applicable standards IEC
Power loss (W) 142
Series name C200
Fuse Dimension (mm) 61x50
Fixing dimensions M10
Melting I²t value (A²s) 370000
Fuse Connection/Terminal type Screw fixing
Total clearing I²t @Un AC (A²s) 2553000
Rated breaking capacity I1 AC (kA) 200
Product available on request Ask for more information
C200 - Fuse 690VAC aR 1000A size 2 61x52,4mm M10 flush end terminals

C200 - Fuse 690VAC aR 1000A size 2 61x52,4mm M10 flush end terminals

Reference 664.965.53.0.0 - Manufacturer FAULTRAP
Class aR
Rated current In (A) 1000
Rated Voltage Un AC (V) 690
Dimension SQB2
Applicable standards IEC
Power loss (W) 113
Series name C200
Fixing dimensions M10
Melting I²t value (A²s) 226000
Fuse Connection/Terminal type Screw fixing
Total clearing I²t @Un AC (A²s) 1550000
Rated breaking capacity I1 AC (kA) 200
Price List €30.36/pc
Quantity
lock Datasheet
C200 - Fuse 690VAC aR 1000A size 2 61x50mm M10 flush end terminals, with microswitch adapter

C200 - Fuse 690VAC aR 1000A size 2 61x50mm M10 flush end terminals, with microswitch adapter

Reference 662.264.49.0.0 - Manufacturer FAULTRAP
Class aR
Rated current In (A) 1000
Rated Voltage Un AC (V) 690
Dimension SQB2
Applicable standards IEC
Power loss (W) 113
Series name C200
Fixing dimensions M10
Melting I²t value (A²s) 226000
Fuse Connection/Terminal type Screw fixing
Total clearing I²t @Un AC (A²s) 1550000
Rated breaking capacity I1 AC (kA) 200
Product available on request Ask for more information
EV38 - Fuse EV 1000V DC 10x38mm 10A

EV38 - Fuse EV 1000V DC 10x38mm 10A

Reference 636.339.44.0.0 - Manufacturer FAULTRAP
Rated current In (A) 10
Applicable standards IEC
Rated Voltage Un DC (V) 1000
Series name EV38
Rated breaking capacity I1 DC (kA) 20
Fuse Dimension (mm) 10x38
Fuse Connection/Terminal type Screw fixing
Product available on request Ask for more information
BPF3 - Fuse 1500VDC aBat M12 1400A

BPF3 - Fuse 1500VDC aBat M12 1400A

Reference 659.248.56.0.0 - Manufacturer FAULTRAP
Class aBat
Rated current In (A) 1400
Applicable standards IEC
Power loss (W) 290
Rated Voltage Un DC (V) 1500
Time costant L/R (ms) 3
Series name BPF3
Rated breaking capacity I1 DC (kA) 100000
Fuse Dimension (mm) 76x140
Fixing dimensions M12
Melting I²t value (A²s) 1350000
Fuse Connection/Terminal type Screw fixing
Voltage of total clearing I2t test 1500
Total clearing I²t @Un AC (A²s) 7695000
Product available on request Ask for more information
PV22 - Fuse 22x65mm 1500VDC gPV UL 50A

PV22 - Fuse 22x65mm 1500VDC gPV UL 50A

Reference 660.156.22.0.0 - Manufacturer FAULTRAP
Class gPV
Rated current In (A) 50
Applicable standards UL
Power loss (W) 11
Rated Voltage Un DC (V) 1500
Time costant L/R (ms) 3
Series name PV22
Rated breaking capacity I1 DC (kA) 10000
Fuse Dimension (mm) 22x65
Melting I²t value (A²s) 685
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 1500
Total clearing I²t @Un AC (A²s) 5600
Price List €181.17/pc
Quantity
lock Datasheet
NR2A - Fuse DIN000 80mm aR 700VDC/690VAC no ind 80A

NR2A - Fuse DIN000 80mm aR 700VDC/690VAC no ind 80A

Reference 663.878.32.0.0 - Manufacturer FAULTRAP
Class aR
Rated current In (A) 80
Rated Voltage Un AC (V) 690
Dimension 000
Applicable standards IEC
Power loss (W) 17
Rated Voltage Un DC (V) 700
Time costant L/R (ms) 2
Series name NR2A
Rated breaking capacity I1 DC (kA) 30000
Melting I²t value (A²s) 750
Fuse Connection/Terminal type Screw fixing
Fixing connection centres (mm) 80
Voltage of total clearing I2t test 700
Total clearing I²t @Un AC (A²s) 2800
Rated breaking capacity I1 AC (kA) 200000
Price List €12.47/pc
Quantity
lock Datasheet
BPF1 - Fuse 1500VDC aBat d:50mm axial 168mm 250A

BPF1 - Fuse 1500VDC aBat d:50mm axial 168mm 250A

Reference 664.460.52.0.0 - Manufacturer FAULTRAP
Class aBat
Rated current In (A) 250
Applicable standards IEC
Power loss (W) 47,5
Rated Voltage Un DC (V) 1500
Time costant L/R (ms) 3
Series name BPF1
Rated breaking capacity I1 DC (kA) 100000
Fuse Dimension (mm) 50x168
Melting I²t value (A²s) 22300
Fuse Connection/Terminal type Screw fixing
Voltage of total clearing I2t test 1500
Total clearing I²t @Un AC (A²s) 78050
Product available on request Ask for more information
G103 - Fuse 500V 10x38 gG 4A

G103 - Fuse 500V 10x38 gG 4A

Reference 664.576.93.0.0 - Manufacturer FAULTRAP
Class gG
Rated current In (A) 4
Rated Voltage Un AC (V) 500
Applicable standards IEC
Power loss (W) 0,8
Fuse Dimension (mm) 10x38
Melting I²t value (A²s) 3,3
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 500
Total clearing I²t @Un AC (A²s) 24
Rated breaking capacity I1 AC (kA) 100000
Product available on request Ask for more information
L226 - In-Line Rugged 22x65 Fuse + Holder 1500VDC 40A

L226 - In-Line Rugged 22x65 Fuse + Holder 1500VDC 40A

Reference 664.427.16.0.0 - Manufacturer FAULTRAP
Class gPV
Rated current In (A) 40
Applicable standards IEC
Power loss (W) 8
Rated Voltage Un DC (V) 1500
Series name L226
Rated breaking capacity I1 DC (kA) 10000
Fuse Dimension (mm) 22x65
Melting I²t value (A²s) 900
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 1500
Total clearing I²t @Un AC (A²s) 4000
Product available on request Ask for more information
Switch disc. NH1 3P bottom bridge clamps - Busbar 100mm

Switch disc. NH1 3P bottom bridge clamps - Busbar 100mm

Reference 63-811750-041.0.0 - Manufacturer APATOR
Rated current In (A) 250
Rated Voltage Un AC (V) 690
Dimension NH1
Applicable standards IEC
Rated Voltage Un DC (V) 440
Max power dissipation (W) 32
Fuse Connection/Terminal type NH knife
Number of poles 3
Weight (gr) 2300
Price List €173.69/pc
Quantity
Switch disconnector NH1 3P bottom Vclamp - Busbar 60mm

Switch disconnector NH1 3P bottom Vclamp - Busbar 60mm

Reference 63-811750-101.0.0 - Manufacturer APATOR
Rated current In (A) 250
Rated Voltage Un AC (V) 690
Dimension NH1
Applicable standards IEC
Rated Voltage Un DC (V) 440
Max power dissipation (W) 32
Fuse Connection/Terminal type NH knife
Number of poles 3
Weight (gr) 2300
Price List €188.54/pc
Quantity
Switch disconnector NH1 3P top bridge clamps - Busbar 60mm

Switch disconnector NH1 3P top bridge clamps - Busbar 60mm

Reference 63-811750-011.0.0 - Manufacturer APATOR
Rated current In (A) 250
Rated Voltage Un AC (V) 690
Dimension NH1
Applicable standards IEC
Rated Voltage Un DC (V) 440
Max power dissipation (W) 32
Fuse Connection/Terminal type NH knife
Number of poles 3
Weight (gr) 2300
Price List €162.42/pc
Quantity
Switch disc. NH1 3P bottom bridge clamps - Busbar 60mm

Switch disc. NH1 3P bottom bridge clamps - Busbar 60mm

Reference 63-811750-021.0.0 - Manufacturer APATOR
Rated current In (A) 250
Rated Voltage Un AC (V) 690
Dimension NH1
Applicable standards IEC
Rated Voltage Un DC (V) 440
Max power dissipation (W) 32
Fuse Connection/Terminal type NH knife
Number of poles 3
Weight (gr) 2300
Price List €162.42/pc
Quantity
Switch disconnector NH1 3P top screw terminal - Busbar 100mm

Switch disconnector NH1 3P top screw terminal - Busbar 100mm

Reference 63-811750-071.0.0 - Manufacturer APATOR
Rated current In (A) 250
Rated Voltage Un AC (V) 690
Dimension NH1
Applicable standards IEC
Rated Voltage Un DC (V) 440
Max power dissipation (W) 32
Fuse Connection/Terminal type NH knife
Number of poles 3
Weight (gr) 2300
Price List €173.69/pc
Quantity
Switch disconnector NH00 3P top M8 screw terminal - Busbar

Switch disconnector NH00 3P top M8 screw terminal - Busbar

Reference 63-823259-021.0.0 - Manufacturer APATOR
Rated current In (A) 160
Rated Voltage Un AC (V) 690
Dimension NH00
Applicable standards IEC
Rated Voltage Un DC (V) 440
Max power dissipation (W) 12
Fuse Connection/Terminal type NH knife
Number of poles 3
Weight (gr) 1100
Price List €121.72/pc
Quantity
Switch disc. NH1 3P bottom screw terminal - Busbar 100mm

Switch disc. NH1 3P bottom screw terminal - Busbar 100mm

Reference 63-811750-081.0.0 - Manufacturer APATOR
Rated current In (A) 250
Rated Voltage Un AC (V) 690
Dimension NH1
Applicable standards IEC
Rated Voltage Un DC (V) 440
Max power dissipation (W) 32
Fuse Connection/Terminal type NH knife
Number of poles 3
Weight (gr) 2300
Price List €173.69/pc
Quantity
Switch disc. NH1 3P top bridge clamps - Busbar 100mm

Switch disc. NH1 3P top bridge clamps - Busbar 100mm

Reference 63-811750-031.0.0 - Manufacturer APATOR
Rated current In (A) 250
Rated Voltage Un AC (V) 690
Dimension NH1
Applicable standards IEC
Rated Voltage Un DC (V) 440
Max power dissipation (W) 32
Fuse Connection/Terminal type NH knife
Number of poles 3
Weight (gr) 2300
Price List €173.69/pc
Quantity
Switch disc. NH1 3P bottom screw terminal - Busbar 60mm

Switch disc. NH1 3P bottom screw terminal - Busbar 60mm

Reference 63-811750-061.0.0 - Manufacturer APATOR
Rated current In (A) 250
Rated Voltage Un AC (V) 690
Dimension NH1
Applicable standards IEC
Rated Voltage Un DC (V) 440
Max power dissipation (W) 32
Fuse Connection/Terminal type NH knife
Number of poles 3
Weight (gr) 2300
Price List €324.84/pc
Quantity
Home
Product added to compare.
Product added to wishlist
