All Products

ZVJM - Fuse holder 10x38 690VAC-1000VDC 4P with ind

ZVJM - Fuse holder 10x38 690VAC-1000VDC 4P with ind

Reference 691.187.44.0.0 - Manufacturer FAULTRAP
Rated current In (A) 32
Rated Voltage Un AC (V) 690
Applicable standards IEC
Rated Voltage Un DC (V) 1000
Series name ZVJM
Fuse Dimension (mm) 10x38
Fuse Connection/Terminal type Cylindrical
Rated Power Acceptance 4
Number of poles 4
Weight (gr) 248
Product available on request Ask for more information
20PV3 - Fuse 2000VDC gPV 76x269mm axial terminals 225mm 350A

20PV3 - Fuse 2000VDC gPV 76x269mm axial terminals 225mm 350A

Reference 693.162.36.0.0 - Manufacturer FAULTRAP
Class gPV
Rated current In (A) 350
Applicable standards IEC
Power loss (W) 81
Rated Voltage Un DC (V) 2000
Time costant L/R (ms) 1-3
Series name 20PV3
Rated breaking capacity I1 DC (kA) 50
Fuse Dimension (mm) 76x269
Melting I²t value (A²s) 73750
Minimum breaking current (A) 700
Fuse Connection/Terminal type Screw fixing
Product available on request Ask for more information
PV22 - Fuse 22x65mm 1500VDC gPV UL 30A

PV22 - Fuse 22x65mm 1500VDC gPV UL 30A

Reference 693.945.08.0.0 - Manufacturer FAULTRAP
Class gPV
Rated current In (A) 30
Applicable standards UL
Power loss (W) 7
Rated Voltage Un DC (V) 1500
Time costant L/R (ms) 3
Series name PV22
Rated breaking capacity I1 DC (kA) 10000
Fuse Dimension (mm) 22x65
Melting I²t value (A²s) 230
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 1500
Total clearing I²t @Un AC (A²s) 1800
Product available on request Ask for more information
B300 - Fuse 1000V DC aBat DC 2xM12 1000A

B300 - Fuse 1000V DC aBat DC 2xM12 1000A

Reference 695.363.75.0.0 - Manufacturer FAULTRAP
Class aBat
Rated current In (A) 1000
Applicable standards IEC
Power loss (W) 200
Rated Voltage Un DC (V) 1000
Time costant L/R (ms) 2
Series name B300
Rated breaking capacity I1 DC (kA) 100
Fuse Dimension (mm) 86x106
Fixing dimensions M12
Melting I²t value (A²s) 267000
Minimum breaking current (A) 10000
Fuse Connection/Terminal type Screw fixing
Total clearing I²t @Un DC (A²s) 801000
Product available on request Ask for more information
NR2A - Fuse DIN000 80mm aR 700VDC/690VAC with ind. lug 180A

NR2A - Fuse DIN000 80mm aR 700VDC/690VAC with ind. lug 180A

Reference 696.362.07.0.0 - Manufacturer FAULTRAP
Class aR
Rated current In (A) 180
Rated Voltage Un AC (V) 690
Dimension 000
Applicable standards IEC
Power loss (W) 42.5
Rated Voltage Un DC (V) 700
Time costant L/R (ms) 2
Series name NR2A
Rated breaking capacity I1 DC (kA) 30000
Melting I²t value (A²s) 4120
Fuse Connection/Terminal type Screw fixing
Fixing connection centres (mm) 80
Voltage of total clearing I2t test 700
Total clearing I²t @Un AC (A²s) 15100
Rated breaking capacity I1 AC (kA) 200000
Product available on request Ask for more information
