All Products

Showing 6553-6576 of 14605 item(s)

Busbar pin 1pole 90° isolated distance 17,6mm

Reference 3860SPM 9TE.0.0 - Manufacturer FTG

Type	Pin
Number of connections	9
Cross section (mm2)	10
Fixing connection centres (mm)	17
Number of poles	1

Product available on request Ask for more information

Busbar pin 1pole 90° isolated distance 17,6mm

Reference 3860SPM.0.0 - Manufacturer FTG

Type	Pin
Number of connections	60
Cross section (mm2)	10
Fixing connection centres (mm)	17
Number of poles	1

Product available on request Ask for more information

Busbar pin 1pole 90° isolated distance 17,6mm

Reference 3860SPM/16 12TE.0.0 - Manufacturer FTG

Type	Pin
Number of connections	12
Cross section (mm2)	16
Fixing connection centres (mm)	17
Number of poles	1

Product available on request Ask for more information

Busbar pin 1pole 90° isolated distance 17,6mm

Reference 3860SPM/16 2TE.0.0 - Manufacturer FTG

Type	Pin
Number of connections	2
Cross section (mm2)	16
Fixing connection centres (mm)	17
Number of poles	1

Product available on request Ask for more information

Busbar pin 1pole 90° isolated distance 17,6mm

Reference 3860SPM/16 3TE.0.0 - Manufacturer FTG

Type	Pin
Number of connections	3
Cross section (mm2)	16
Fixing connection centres (mm)	17
Number of poles	1

Product available on request Ask for more information

Busbar pin 1pole 90° isolated distance 17,6mm

Reference 3860SPM/16 6TE.0.0 - Manufacturer FTG

Type	Pin
Number of connections	6
Cross section (mm2)	16
Fixing connection centres (mm)	17
Number of poles	1

Product available on request Ask for more information

Busbar pin 1pole 90° isolated distance 17,6mm

Reference 3860SPM/16 9TE.0.0 - Manufacturer FTG

Type	Pin
Number of connections	9
Cross section (mm2)	16
Fixing connection centres (mm)	17
Number of poles	1

Product available on request Ask for more information

Busbar pin 1pole 90° isolated distance 17,6mm

Reference 3860SPM/16.0.0 - Manufacturer FTG

Type	Pin
Number of connections	60
Cross section (mm2)	16
Fixing connection centres (mm)	17
Number of poles	1

Product available on request Ask for more information

Block 1pole IN:1x(185mm2) OUT:2x(35mm2)5x(16mm2)4x(10mm2)Al

Reference 38619.0.0 - Manufacturer FTG

Rated Voltage Un AC (V)	1000
Rated Voltage Un DC (V)	1500
Rated current (A)	300
Color	Grey
Load side connections	11
Line side connections	1
Dimensions (mm)	95,5 x 44,5 x 49
Number of poles	1

Product available on request Ask for more information

Fuse NH0S aM 500V double indicator 200A

Reference 383180.0.0 - Manufacturer DF

Class	aM
Rated current In (A)	200
Rated Voltage Un AC (V)	500
Dimension	NH0S
Applicable standards	IEC
Melting I²t value (A²s)	92000
Fuse Connection/Terminal type	NH knife
Voltage of total clearing I2t test	690
Total clearing I²t @Un AC (A²s)	320000
Rated breaking capacity I1 AC (kA)	120000
Weight (gr)	270

Price List €12.38/pc

Quantity

Fuse NH1 aM 500V double indicator 224A

Reference 383265.0.0 - Manufacturer DF

Class	aM
Rated current In (A)	224
Rated Voltage Un AC (V)	500
Dimension	NH1
Applicable standards	IEC
Power loss (W)	14,6
Melting I²t value (A²s)	240000
Fuse Connection/Terminal type	NH knife
Voltage of total clearing I2t test	500
Total clearing I²t @Un AC (A²s)	529312
Rated breaking capacity I1 AC (kA)	120000
Weight (gr)	470

Price List €14.61/pc

Quantity

Fuse NH1 aM 500V double indicator 250A

Reference 383270.0.0 - Manufacturer DF

Class	aM
Rated current In (A)	250
Rated Voltage Un AC (V)	500
Dimension	NH1
Applicable standards	IEC
Power loss (W)	18,1
Melting I²t value (A²s)	291000
Fuse Connection/Terminal type	NH knife
Voltage of total clearing I2t test	500
Total clearing I²t @Un AC (A²s)	641790
Rated breaking capacity I1 AC (kA)	120000
Weight (gr)	470

Price List €14.71/pc

Quantity

Fuse NH2 aM 500V double indicator 400A

Reference 383380.0.0 - Manufacturer DF

Class	aM
Rated current In (A)	400
Rated Voltage Un AC (V)	500
Dimension	NH2
Applicable standards	IEC
Power loss (W)	27,8
Melting I²t value (A²s)	502000
Fuse Connection/Terminal type	NH knife
Voltage of total clearing I2t test	500
Total clearing I²t @Un AC (A²s)	1308183
Rated breaking capacity I1 AC (kA)	120000
Weight (gr)	710

Price List €22.47/pc

Quantity

Fuse NH3 aM 500V double indicator 630A

Reference 383470.0.0 - Manufacturer DF

Class	aM
Rated current In (A)	630
Rated Voltage Un AC (V)	500
Dimension	NH3
Applicable standards	IEC
Power loss (W)	45,9
Melting I²t value (A²s)	1373000
Fuse Connection/Terminal type	NH knife
Voltage of total clearing I2t test	500
Total clearing I²t @Un AC (A²s)	3360000
Rated breaking capacity I1 AC (kA)	120000
Weight (gr)	1200

Price List €45.93/pc

Quantity

Fuse NH4 screw fixing aM 500V double indicator 315A

Reference 383505.0.0 - Manufacturer DF

Class	aM
Rated current In (A)	315
Rated Voltage Un AC (V)	500
Dimension	NH4
Applicable standards	IEC
Power loss (W)	18,8
Melting I²t value (A²s)	463000
Fuse Connection/Terminal type	NH knife
Voltage of total clearing I2t test	500
Total clearing I²t @Un AC (A²s)	1021130
Rated breaking capacity I1 AC (kA)	120000
Weight (gr)	2250

Price List €108.83/pc

Quantity

Fuse NH4 screw fixing aM 500V double indicator 400A

Reference 383510.0.0 - Manufacturer DF

Class	aM
Rated current In (A)	400
Rated Voltage Un AC (V)	500
Dimension	NH4
Applicable standards	IEC
Power loss (W)	23,5
Melting I²t value (A²s)	502000
Fuse Connection/Terminal type	NH knife
Voltage of total clearing I2t test	500
Total clearing I²t @Un AC (A²s)	1308183
Rated breaking capacity I1 AC (kA)	120000
Weight (gr)	2250

Price List €110.57/pc

Quantity

Fuse NH4 screw fixing aM 500V double indicator 500A

Reference 383515.0.0 - Manufacturer DF

Class	aM
Rated current In (A)	500
Rated Voltage Un AC (V)	500
Dimension	NH4
Applicable standards	IEC
Power loss (W)	34
Melting I²t value (A²s)	760000
Fuse Connection/Terminal type	NH knife
Voltage of total clearing I2t test	500
Total clearing I²t @Un AC (A²s)	1980516
Rated breaking capacity I1 AC (kA)	120000
Weight (gr)	2250

Price List €111.74/pc

Quantity

Fuse NH4 screw fixing aM 500V double indicator 630A

Reference 383520.0.0 - Manufacturer DF

Class	aM
Rated current In (A)	630
Rated Voltage Un AC (V)	500
Dimension	NH4
Applicable standards	IEC
Power loss (W)	49
Melting I²t value (A²s)	1423000
Fuse Connection/Terminal type	NH knife
Voltage of total clearing I2t test	500
Total clearing I²t @Un AC (A²s)	3708255
Rated breaking capacity I1 AC (kA)	120000
Weight (gr)	2250

Price List €112.62/pc

Quantity

Fuse NH4 screw fixing aM 500V double indicator 800A

Reference 383525.0.0 - Manufacturer DF

Class	aM
Rated current In (A)	800
Rated Voltage Un AC (V)	500
Dimension	NH4
Applicable standards	IEC
Power loss (W)	52
Melting I²t value (A²s)	1880000
Fuse Connection/Terminal type	NH knife
Voltage of total clearing I2t test	500
Total clearing I²t @Un AC (A²s)	4567527
Rated breaking capacity I1 AC (kA)	120000
Weight (gr)	2250

Price List €116.13/pc

Quantity

Fuse NH4 screw fixing aM 500V double indicator 1000A

Reference 383530.0.0 - Manufacturer DF

Class	aM
Rated current In (A)	1000
Rated Voltage Un AC (V)	500
Dimension	NH4
Applicable standards	IEC
Power loss (W)	80
Melting I²t value (A²s)	4500000
Fuse Connection/Terminal type	NH knife
Voltage of total clearing I2t test	500
Total clearing I²t @Un AC (A²s)	11282902
Rated breaking capacity I1 AC (kA)	120000
Weight (gr)	2250

Price List €118.94/pc

Quantity

Fuse NH4 screw fixing aM 500V double indicator 1250A

Reference 383535.0.0 - Manufacturer DF

Class	aM
Rated current In (A)	1250
Rated Voltage Un AC (V)	500
Dimension	NH4
Applicable standards	IEC
Power loss (W)	108
Melting I²t value (A²s)	7000000
Fuse Connection/Terminal type	NH knife
Voltage of total clearing I2t test	500
Total clearing I²t @Un AC (A²s)	17607924
Rated breaking capacity I1 AC (kA)	120000
Weight (gr)	2250

Price List €149.24/pc

Quantity

EV65.1500 - Fuse 1500VDC 22x65 cylindrical 60A

Reference 384.236.42.0.0 - Manufacturer FAULTRAP

Class	EV full
Rated current In (A)	60
Applicable standards	UL
Power loss (W)	12
Rated Voltage Un DC (V)	1500
Time costant L/R (ms)	2,5
Series name	EV65.1500
Rated breaking capacity I1 DC (kA)	25000
Fuse Dimension (mm)	22x65
Melting I²t value (A²s)	1220
Fuse Connection/Terminal type	Cylindrical
Voltage of total clearing I2t test	1500
Total clearing I²t @Un AC (A²s)	7500

Product available on request Ask for more information

UR22 - Fuse 690V AC 22x58 cylindrical 50A

Reference 384.770.34.0.0 - Manufacturer FAULTRAP

Class	aR
Rated current In (A)	50
Rated Voltage Un AC (V)	550
Applicable standards	IEC, UL
Power loss (W)	13,3
Series name	UR22
Melting I²t value (A²s)	195
Fuse Connection/Terminal type	Cylindrical
Total clearing I²t @Un AC (A²s)	955
Rated breaking capacity I1 AC (kA)	200

Product available on request Ask for more information

Distribution block 1pole IN:1x(25x10mm) OUT:6x(50mm2) Cu

Reference 38401.0.0 - Manufacturer FTG

Rated Voltage Un AC (V)	1000
Rated Voltage Un DC (V)	1500
Rated current (A)	400
Color	Grey
Load side connections	6
Line side connections	1
Dimensions (mm)	103 x 45 x 50,2
Number of poles	1

Product available on request Ask for more information
