Fuses

Fuse 14x65 1100VDC gPV UL2579 plap contacts 25A

Fuse 14x65 1100VDC gPV UL2579 plap contacts 25A

Reference 5023928.25.0 - Manufacturer SIBA
Class gPV
Rated current In (A) 25
Applicable standards IEC, UL
Power loss (W) 3,8
Rated Voltage Un DC (V) 1100
Rated breaking capacity I1 DC (kA) 30000
Fuse Dimension (mm) 14x65
Melting I²t value (A²s) 30
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 1100
Total clearing I²t @Un AC (A²s) 143
Weight (gr) 20
Product available on request Ask for more information
Fuse 14x65 1500VDC gPV UL2579 10A

Fuse 14x65 1500VDC gPV UL2579 10A

Reference 5024028.10.0 - Manufacturer SIBA
Class gPV
Rated current In (A) 10
Applicable standards IEC, UL
Power loss (W) 4
Rated Voltage Un DC (V) 1500
Time costant L/R (ms) 3
Rated breaking capacity I1 DC (kA) 30000
Fuse Dimension (mm) 14x65
Melting I²t value (A²s) 5
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 1500
Total clearing I²t @Un AC (A²s) 41
Weight (gr) 28
Price List €38.33/pc
Quantity
Fuse 14x65 1500VDC gPV UL2579 12A

Fuse 14x65 1500VDC gPV UL2579 12A

Reference 5024028.12.0 - Manufacturer SIBA
Class gPV
Rated current In (A) 12
Applicable standards IEC, UL
Power loss (W) 4,2
Rated Voltage Un DC (V) 1500
Time costant L/R (ms) 3
Rated breaking capacity I1 DC (kA) 30000
Fuse Dimension (mm) 14x65
Melting I²t value (A²s) 12
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 1500
Total clearing I²t @Un AC (A²s) 100
Weight (gr) 28
Price List €27.53/pc
Quantity
Fuse 14x65 1500VDC gPV UL2579 15A

Fuse 14x65 1500VDC gPV UL2579 15A

Reference 5024028.15.0 - Manufacturer SIBA
Class gPV
Rated current In (A) 15
Applicable standards IEC, UL
Power loss (W) 4,5
Rated Voltage Un DC (V) 1500
Time costant L/R (ms) 1
Rated breaking capacity I1 DC (kA) 30000
Fuse Dimension (mm) 14x65
Melting I²t value (A²s) 21
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 1500
Total clearing I²t @Un AC (A²s) 170
Weight (gr) 28
Price List €19.11/pc
Quantity
Fuse 14x65 1500VDC gPV UL2579 16A

Fuse 14x65 1500VDC gPV UL2579 16A

Reference 5024028.16.0 - Manufacturer SIBA
Class gPV
Rated current In (A) 16
Applicable standards IEC, UL
Power loss (W) 4,7
Rated Voltage Un DC (V) 1500
Time costant L/R (ms) 3
Rated breaking capacity I1 DC (kA) 30000
Fuse Dimension (mm) 14x65
Melting I²t value (A²s) 26
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 1500
Total clearing I²t @Un AC (A²s) 210
Weight (gr) 28
Price List €38.85/pc
Quantity
Fuse 14x65 1500VDC gPV UL2579 20A

Fuse 14x65 1500VDC gPV UL2579 20A

Reference 5024028.20.0 - Manufacturer SIBA
Class gPV
Rated current In (A) 20
Applicable standards IEC, UL
Power loss (W) 5
Rated Voltage Un DC (V) 1500
Time costant L/R (ms) 3
Rated breaking capacity I1 DC (kA) 30000
Fuse Dimension (mm) 14x65
Melting I²t value (A²s) 66
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 1500
Total clearing I²t @Un AC (A²s) 540
Weight (gr) 27
Price List €37.15/pc
Quantity
Fuse 14x65 1500VDC gPV UL2579 25A

Fuse 14x65 1500VDC gPV UL2579 25A

Reference 5024028.25.0 - Manufacturer SIBA
Class gPV
Rated current In (A) 25
Applicable standards IEC, UL
Power loss (W) 6
Rated Voltage Un DC (V) 1500
Time costant L/R (ms) 3
Rated breaking capacity I1 DC (kA) 30000
Fuse Dimension (mm) 14x65
Melting I²t value (A²s) 90
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 1500
Total clearing I²t @Un AC (A²s) 730
Weight (gr) 28
Price List €39.87/pc
Quantity
Fuse 14x65 1500VDC gPV UL2579 30A

Fuse 14x65 1500VDC gPV UL2579 30A

Reference 5024028.30.0 - Manufacturer SIBA
Class gPV
Rated current In (A) 30
Applicable standards IEC, UL
Power loss (W) 7
Rated Voltage Un DC (V) 1500
Time costant L/R (ms) 3
Rated breaking capacity I1 DC (kA) 30000
Fuse Dimension (mm) 14x65
Melting I²t value (A²s) 149
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 1500
Total clearing I²t @Un AC (A²s) 1350
Weight (gr) 28
Price List €40.44/pc
Quantity
Fuse 14x65 with bolted contats 1500VDC gPV UL2579 10A

Fuse 14x65 with bolted contats 1500VDC gPV UL2579 10A

Reference 5024228.10.0 - Manufacturer SIBA
Class gPV
Rated current In (A) 10
Applicable standards IEC, UL
Power loss (W) 4
Rated Voltage Un DC (V) 1500
Time costant L/R (ms) 3
Rated breaking capacity I1 DC (kA) 30000
Fuse Dimension (mm) 14x65
Melting I²t value (A²s) 5
Fuse Connection/Terminal type Screw fixing
Voltage of total clearing I2t test 1500
Total clearing I²t @Un AC (A²s) 41
Weight (gr) 38
Price List €359.01/pc
Quantity
Fuse 14x65 with bolted contats 1500VDC gPV UL2579 12A

Fuse 14x65 with bolted contats 1500VDC gPV UL2579 12A

Reference 5024228.12.0 - Manufacturer SIBA
Class gPV
Rated current In (A) 12
Applicable standards IEC, UL
Power loss (W) 4,2
Rated Voltage Un DC (V) 1500
Time costant L/R (ms) 3
Rated breaking capacity I1 DC (kA) 30000
Fuse Dimension (mm) 14x65
Melting I²t value (A²s) 12
Fuse Connection/Terminal type Screw fixing
Voltage of total clearing I2t test 1500
Total clearing I²t @Un AC (A²s) 100
Weight (gr) 38
Price List €359.21/pc
Quantity
Fuse 14x65 with bolted contats 1500VDC gPV UL2579 16A

Fuse 14x65 with bolted contats 1500VDC gPV UL2579 16A

Reference 5024228.16.0 - Manufacturer SIBA
Class gPV
Rated current In (A) 16
Applicable standards IEC, UL
Power loss (W) 4,7
Rated Voltage Un DC (V) 1500
Time costant L/R (ms) 3
Rated breaking capacity I1 DC (kA) 30000
Fuse Dimension (mm) 14x65
Melting I²t value (A²s) 26
Fuse Connection/Terminal type Screw fixing
Voltage of total clearing I2t test 1500
Total clearing I²t @Un AC (A²s) 210
Weight (gr) 38
Price List €357.56/pc
Quantity
Fuse 14x65 with bolted contats 1500VDC gPV UL2579 20A

Fuse 14x65 with bolted contats 1500VDC gPV UL2579 20A

Reference 5024228.20.0 - Manufacturer SIBA
Class gPV
Rated current In (A) 20
Applicable standards IEC, UL
Power loss (W) 5
Rated Voltage Un DC (V) 1500
Time costant L/R (ms) 3
Rated breaking capacity I1 DC (kA) 30000
Fuse Dimension (mm) 14x65
Melting I²t value (A²s) 66
Fuse Connection/Terminal type Screw fixing
Voltage of total clearing I2t test 1500
Total clearing I²t @Un AC (A²s) 540
Weight (gr) 38
Price List €358.22/pc
Quantity
Fuse 14x65 with bolted contats 1500VDC gPV UL2579 25A

Fuse 14x65 with bolted contats 1500VDC gPV UL2579 25A

Reference 5024228.25.0 - Manufacturer SIBA
Class gPV
Rated current In (A) 25
Applicable standards IEC, UL
Power loss (W) 6
Rated Voltage Un DC (V) 1500
Time costant L/R (ms) 3
Rated breaking capacity I1 DC (kA) 30000
Fuse Dimension (mm) 14x65
Melting I²t value (A²s) 90
Fuse Connection/Terminal type Screw fixing
Voltage of total clearing I2t test 1500
Total clearing I²t @Un AC (A²s) 730
Weight (gr) 38
Price List €358.63/pc
Quantity
Fuse 14x65 with bolted contats 1500VDC gPV UL2579 30A

Fuse 14x65 with bolted contats 1500VDC gPV UL2579 30A

Reference 5024228.30.0 - Manufacturer SIBA
Class gPV
Rated current In (A) 30
Applicable standards IEC, UL
Power loss (W) 7
Rated Voltage Un DC (V) 1500
Time costant L/R (ms) 3
Rated breaking capacity I1 DC (kA) 30000
Fuse Dimension (mm) 14x65
Melting I²t value (A²s) 149
Fuse Connection/Terminal type Screw fixing
Voltage of total clearing I2t test 1500
Total clearing I²t @Un AC (A²s) 1350
Weight (gr) 38
Price List €28.26/pc
Quantity
Fuse 10x38 1000VDC gPV for cable connection 1A

Fuse 10x38 1000VDC gPV for cable connection 1A

Reference 5021826.1.0 - Manufacturer SIBA
Class gPV
Rated current In (A) 1
Applicable standards IEC, UL
Power loss (W) 0,8
Rated Voltage Un DC (V) 1000
Rated breaking capacity I1 DC (kA) 30000
Fuse Dimension (mm) 10x38
Melting I²t value (A²s) 0,33
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 1000
Weight (gr) 10
Product available on request Ask for more information
Fuse 10x38 1000VDC gPV for cable connection 10A

Fuse 10x38 1000VDC gPV for cable connection 10A

Reference 5021826.10.0 - Manufacturer SIBA
Class gPV
Rated current In (A) 10
Applicable standards IEC, UL
Power loss (W) 2
Rated Voltage Un DC (V) 1000
Rated breaking capacity I1 DC (kA) 30000
Fuse Dimension (mm) 10x38
Melting I²t value (A²s) 7
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 1000
Weight (gr) 10
Product available on request Ask for more information
Fuse 10x38 1000VDC gPV with cable 230mm-550mm 10A

Fuse 10x38 1000VDC gPV with cable 230mm-550mm 10A

Reference 5021826.10PA.0 - Manufacturer SIBA
Class gPV
Rated current In (A) 10
Applicable standards IEC
Power loss (W) 2
Rated Voltage Un DC (V) 1000
Time costant L/R (ms) 2
Rated breaking capacity I1 DC (kA) 30000
Fuse Dimension (mm) 10x38
Melting I²t value (A²s) 7
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 1000
Weight (gr) 10
Product available on request Ask for more information
Fuse 10x38 1000VDC gPV with cable 230mm-700mm 10A

Fuse 10x38 1000VDC gPV with cable 230mm-700mm 10A

Reference 5021826.10PA2.0 - Manufacturer SIBA
Class gPV
Rated current In (A) 10
Applicable standards IEC, UL
Power loss (W) 2
Rated Voltage Un DC (V) 1000
Time costant L/R (ms) 2
Rated breaking capacity I1 DC (kA) 30000
Fuse Dimension (mm) 10x38
Melting I²t value (A²s) 7
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 1000
Weight (gr) 10
Product available on request Ask for more information
Fuse 10x38 1000VDC gPV with cable 230mm-850mm 10A

Fuse 10x38 1000VDC gPV with cable 230mm-850mm 10A

Reference 5021826.10PA3.0 - Manufacturer SIBA
Class gPV
Rated current In (A) 10
Applicable standards IEC, UL
Power loss (W) 2
Rated Voltage Un DC (V) 1000
Time costant L/R (ms) 2
Rated breaking capacity I1 DC (kA) 30000
Fuse Dimension (mm) 10x38
Melting I²t value (A²s) 7
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 1000
Weight (gr) 10
Product available on request Ask for more information
Fuse 10x38 1000VDC gPV with cable 800mm-800mm 10A

Fuse 10x38 1000VDC gPV with cable 800mm-800mm 10A

Reference 5021826.10PA4.0 - Manufacturer SIBA
Class gPV
Rated current In (A) 10
Applicable standards IEC, UL
Power loss (W) 2
Rated Voltage Un DC (V) 1000
Time costant L/R (ms) 2
Rated breaking capacity I1 DC (kA) 30000
Fuse Dimension (mm) 10x38
Melting I²t value (A²s) 7
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 1000
Weight (gr) 10
Product available on request Ask for more information
Fuse 10x38 1000VDC gPV for cable connection 12A

Fuse 10x38 1000VDC gPV for cable connection 12A

Reference 5021826.12.0 - Manufacturer SIBA
Class gPV
Rated current In (A) 12
Applicable standards IEC, UL
Power loss (W) 2,4
Rated Voltage Un DC (V) 1000
Rated breaking capacity I1 DC (kA) 30000
Fuse Dimension (mm) 10x38
Melting I²t value (A²s) 10
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 1000
Weight (gr) 10
Price List €518.53/pc
Quantity
Fuse 10x38 1000VDC gPV with cable 230mm-550mm 12A

Fuse 10x38 1000VDC gPV with cable 230mm-550mm 12A

Reference 5021826.12PA.0 - Manufacturer SIBA
Class gPV
Rated current In (A) 12
Applicable standards IEC
Power loss (W) 2,4
Rated Voltage Un DC (V) 1000
Time costant L/R (ms) 2
Rated breaking capacity I1 DC (kA) 30000
Fuse Dimension (mm) 10x38
Melting I²t value (A²s) 10
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 1000
Weight (gr) 10
Product available on request Ask for more information
Fuse 10x38 1000VDC gPV with cable 230mm-700mm 12A

Fuse 10x38 1000VDC gPV with cable 230mm-700mm 12A

Reference 5021826.12PA2.0 - Manufacturer SIBA
Class gPV
Rated current In (A) 12
Applicable standards IEC, UL
Power loss (W) 2,4
Rated Voltage Un DC (V) 1000
Time costant L/R (ms) 2
Rated breaking capacity I1 DC (kA) 30000
Fuse Dimension (mm) 10x38
Melting I²t value (A²s) 10
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 1000
Weight (gr) 10
Product available on request Ask for more information
Fuse 10x38 1000VDC gPV with cable 230mm-850mm 12A

Fuse 10x38 1000VDC gPV with cable 230mm-850mm 12A

Reference 5021826.12PA3.0 - Manufacturer SIBA
Class gPV
Rated current In (A) 12
Applicable standards IEC, UL
Power loss (W) 2,4
Rated Voltage Un DC (V) 1000
Time costant L/R (ms) 2
Rated breaking capacity I1 DC (kA) 30000
Fuse Dimension (mm) 10x38
Melting I²t value (A²s) 10
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 1000
Weight (gr) 10
Product available on request Ask for more information
Filter by
Manufacturer
Series name
Fuse size
Class
Fuse Connection/Terminal type
Rated current In (A)
Rated Voltage Un AC (V)
Rated Voltage Un DC (V)
Applicable standards
Product added to compare.
Product added to wishlist
