Fuses

Fuse BS Motors 12kV 553mm 50A

Fuse BS Motors 12kV 553mm 50A

Reference 3027456.50.0 - Manufacturer SIBA
Class HH Motors
Rated current In (A) 50
Rated Voltage Un AC (V) 12000
Applicable standards IEC
Power loss (W) 55
Melting I²t value (A²s) 3400
Fuse Connection/Terminal type BS
Voltage of total clearing I2t test 10500
Total clearing I²t @Un AC (A²s) 23000
Rated breaking capacity I1 AC (kA) 50000
Product available on request Ask for more information
Fuse BS Motors 12kV 553mm 63A

Fuse BS Motors 12kV 553mm 63A

Reference 3027456.63.0 - Manufacturer SIBA
Class HH Motors
Rated current In (A) 63
Rated Voltage Un AC (V) 12000
Applicable standards IEC
Power loss (W) 74
Melting I²t value (A²s) 5400
Fuse Connection/Terminal type BS
Voltage of total clearing I2t test 10500
Total clearing I²t @Un AC (A²s) 35000
Rated breaking capacity I1 AC (kA) 50000
Price List €376.19/pc
Quantity
lock Datasheet
Fuse BS Motors 12kV 553mm 80A

Fuse BS Motors 12kV 553mm 80A

Reference 3027456.80.0 - Manufacturer SIBA
Class HH Motors
Rated current In (A) 80
Rated Voltage Un AC (V) 12000
Applicable standards IEC
Power loss (W) 100
Melting I²t value (A²s) 6200
Fuse Connection/Terminal type BS
Voltage of total clearing I2t test 10500
Total clearing I²t @Un AC (A²s) 36500
Rated breaking capacity I1 AC (kA) 50000
Price List €141.41/pc
Quantity
lock Datasheet
Fuse BS Mot. 12kV double body 553mm 224A

Fuse BS Mot. 12kV double body 553mm 224A

Reference 3027556.224.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 224
Rated Voltage Un AC (V) 12000
Applicable standards IEC
Power loss (W) 188
Fuse Dimension (mm) 2x 553
Melting I²t value (A²s) 127000
Fuse Connection/Terminal type BS
Voltage of total clearing I2t test 10500
Total clearing I²t @Un AC (A²s) 717000
Rated breaking capacity I1 AC (kA) 50000
Weight (gr) 10800
Product available on request Ask for more information
Fuse BS Mot. 12kV double body 553mm 250A

Fuse BS Mot. 12kV double body 553mm 250A

Reference 3027556.250.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 250
Rated Voltage Un AC (V) 12000
Applicable standards IEC
Power loss (W) 210
Fuse Dimension (mm) 2x 553
Melting I²t value (A²s) 189000
Fuse Connection/Terminal type BS
Voltage of total clearing I2t test 10500
Total clearing I²t @Un AC (A²s) 1100000
Rated breaking capacity I1 AC (kA) 50000
Weight (gr) 10800
Price List €439.40/pc
Quantity
lock Datasheet
Fuse BS Mot. 12kV double body 553mm 355A

Fuse BS Mot. 12kV double body 553mm 355A

Reference 3027556.355.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 355
Rated Voltage Un AC (V) 12000
Applicable standards IEC
Power loss (W) 305
Fuse Dimension (mm) 2x 553
Melting I²t value (A²s) 325000
Fuse Connection/Terminal type BS
Voltage of total clearing I2t test 10500
Total clearing I²t @Un AC (A²s) 1840000
Rated breaking capacity I1 AC (kA) 50000
Weight (gr) 10800
Price List €441.40/pc
Quantity
lock Datasheet
Fuse 15,5kV 63,5x254 F01 oiltight 10A

Fuse 15,5kV 63,5x254 F01 oiltight 10A

Reference 3029336.10.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 10
Rated Voltage Un AC (V) 15500
Applicable standards IEC
Fuse Dimension (mm) 63,5x254
Melting I²t value (A²s) 50
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 15500
Total clearing I²t @Un AC (A²s) 450
Rated breaking capacity I1 AC (kA) 40000
Weight (gr) 1790
Product available on request Ask for more information
Fuse 15,5kV 63,5x254 F01 oiltight 31,5A

Fuse 15,5kV 63,5x254 F01 oiltight 31,5A

Reference 3029336.31,5.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 31,5
Rated Voltage Un AC (V) 15500
Applicable standards IEC
Fuse Dimension (mm) 63,5x254
Melting I²t value (A²s) 1000
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 15500
Total clearing I²t @Un AC (A²s) 10000
Rated breaking capacity I1 AC (kA) 40000
Weight (gr) 1790
Product available on request Ask for more information
Fuse 15,5kV 63,5x359 F02 oiltight 6,3A

Fuse 15,5kV 63,5x359 F02 oiltight 6,3A

Reference 3029436.6,3.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 6,3
Rated Voltage Un AC (V) 15500
Applicable standards IEC
Fuse Dimension (mm) 63,5x359
Melting I²t value (A²s) 14
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 15500
Total clearing I²t @Un AC (A²s) 140
Rated breaking capacity I1 AC (kA) 40000
Weight (gr) 1500
Product available on request Ask for more information
Fuse 27x138 1500VDC 4A

Fuse 27x138 1500VDC 4A

Reference 3030101.4.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 4
Power loss (W) 2
Rated Voltage Un DC (V) 1500
Rated breaking capacity I1 DC (kA) 50000
Fuse Dimension (mm) 138x27
Melting I²t value (A²s) 7,5
Fuse Connection/Terminal type Cylindrical
Weight (gr) 190
Product available on request Ask for more information
Fuse 213x27 1500VDC 16A

Fuse 213x27 1500VDC 16A

Reference 3030301.16.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 16
Power loss (W) 9.5
Rated Voltage Un DC (V) 1500
Rated breaking capacity I1 DC (kA) 50000
Fuse Dimension (mm) 27x213
Melting I²t value (A²s) 185
Fuse Connection/Terminal type Cylindrical
Weight (gr) 290
Product available on request Ask for more information
Fuse 213x27 1500VDC 25A

Fuse 213x27 1500VDC 25A

Reference 3030301.25.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 25
Power loss (W) 10
Rated Voltage Un DC (V) 1500
Rated breaking capacity I1 DC (kA) 50000
Fuse Dimension (mm) 27x213
Melting I²t value (A²s) 650
Fuse Connection/Terminal type Cylindrical
Weight (gr) 290
Product available on request Ask for more information
Fuse 17,5kV 53x192 back-up with striker 3A 80N

Fuse 17,5kV 53x192 back-up with striker 3A 80N

Reference 3017913.3.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 3
Rated Voltage Un AC (V) 17500
Applicable standards IEC
Power loss (W) 13
Resistance (ohm) 0,91
Fuse Dimension (mm) 53x192
Melting I²t value (A²s) 16,5
Minimum breaking current (A) 24
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 15225
Total clearing I²t @Un AC (A²s) 42
Rated breaking capacity I1 AC (kA) 63000
Product available on request Ask for more information
Fuse 24kV 53x537 TV no striker 0,5A

Fuse 24kV 53x537 TV no striker 0,5A

Reference 3020311.0,5.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 0,5
Rated Voltage Un AC (V) 24000
Applicable standards IEC
Power loss (W) 11,2
Resistance (ohm) 40,55
Fuse Dimension (mm) 53x537
Melting I²t value (A²s) 1,6
Minimum breaking current (A) 5
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 20880
Total clearing I²t @Un AC (A²s) 5,9
Rated breaking capacity I1 AC (kA) 63000
Product available on request Ask for more information
Fuse 24kV 53x537 TV no striker 1A

Fuse 24kV 53x537 TV no striker 1A

Reference 3020311.1.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 1
Rated Voltage Un AC (V) 24000
Applicable standards IEC
Power loss (W) 8,6
Resistance (ohm) 6,45
Fuse Dimension (mm) 53x537
Melting I²t value (A²s) 0,63
Minimum breaking current (A) 8
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 20880
Total clearing I²t @Un AC (A²s) 1,8
Rated breaking capacity I1 AC (kA) 63000
Product available on request Ask for more information
Fuse 24kV 53x537 TV no striker 2,5A

Fuse 24kV 53x537 TV no striker 2,5A

Reference 3020313.2,5.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 2,5
Rated Voltage Un AC (V) 10000
Applicable standards IEC
Power loss (W) 16
Resistance (ohm) 1,92
Fuse Dimension (mm) 53x537
Melting I²t value (A²s) 7,2
Minimum breaking current (A) 20
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 8700
Total clearing I²t @Un AC (A²s) 26
Rated breaking capacity I1 AC (kA) 63000
Product available on request Ask for more information
Fuse 24kV 53x537 TV no striker 2A

Fuse 24kV 53x537 TV no striker 2A

Reference 3020313.2.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 2
Rated Voltage Un AC (V) 24000
Applicable standards IEC
Power loss (W) 15
Resistance (ohm) 2,85
Fuse Dimension (mm) 53x537
Melting I²t value (A²s) 3,2
Minimum breaking current (A) 16
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 20880
Total clearing I²t @Un AC (A²s) 9,8
Rated breaking capacity I1 AC (kA) 63000
Product available on request Ask for more information
Fuse 24kV 53x537 TV no striker 3,15A

Fuse 24kV 53x537 TV no striker 3,15A

Reference 3020313.3,15.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 3,15
Rated Voltage Un AC (V) 10000
Applicable standards IEC
Power loss (W) 18
Resistance (ohm) 1,3
Fuse Dimension (mm) 53x537
Melting I²t value (A²s) 17
Minimum breaking current (A) 24
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 8700
Total clearing I²t @Un AC (A²s) 48
Rated breaking capacity I1 AC (kA) 63000
Product available on request Ask for more information
Fuse 24kV 53x537 TV no striker 4A

Fuse 24kV 53x537 TV no striker 4A

Reference 3020313.4.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 4
Rated Voltage Un AC (V) 10000
Applicable standards IEC
Power loss (W) 22
Resistance (ohm) 0,95
Fuse Dimension (mm) 53x537
Melting I²t value (A²s) 31
Minimum breaking current (A) 32
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 8700
Total clearing I²t @Un AC (A²s) 90
Rated breaking capacity I1 AC (kA) 63000
Product available on request Ask for more information
Fuse 24kV 53x537 TV no striker 5A

Fuse 24kV 53x537 TV no striker 5A

Reference 3020313.5.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 5
Rated Voltage Un AC (V) 10000
Applicable standards IEC
Power loss (W) 15
Resistance (ohm) 0,806
Fuse Dimension (mm) 53x537
Melting I²t value (A²s) 40
Minimum breaking current (A) 40
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 8700
Total clearing I²t @Un AC (A²s) 125
Rated breaking capacity I1 AC (kA) 63000
Product available on request Ask for more information
Fuse 12kV 63,5x359 F02 oiltight 112A

Fuse 12kV 63,5x359 F02 oiltight 112A

Reference 3023736.112.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 112
Rated Voltage Un AC (V) 12000
Applicable standards IEC
Fuse Dimension (mm) 63,5x359
Melting I²t value (A²s) 28300
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 12000
Total clearing I²t @Un AC (A²s) 278000
Rated breaking capacity I1 AC (kA) 40000
Weight (gr) 2440
Product available on request Ask for more information
Fuse 7,2kV 53x442 0,5A

Fuse 7,2kV 53x442 0,5A

Reference 3010811.0,5.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 0,5
Rated Voltage Un AC (V) 7200
Applicable standards IEC
Power loss (W) 3,6
Resistance (ohm) 13,25
Fuse Dimension (mm) 53x442
Melting I²t value (A²s) 1,6
Minimum breaking current (A) 5
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 6264
Total clearing I²t @Un AC (A²s) 5,9
Rated breaking capacity I1 AC (kA) 80000
Weight (gr) 1600
Product available on request Ask for more information
Fuse 7,2kV 53x442 1A

Fuse 7,2kV 53x442 1A

Reference 3010811.1.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 1
Rated Voltage Un AC (V) 7200
Applicable standards IEC
Power loss (W) 2,8
Resistance (ohm) 2,1
Fuse Dimension (mm) 53x442
Melting I²t value (A²s) 0,63
Minimum breaking current (A) 8
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 6264
Total clearing I²t @Un AC (A²s) 2,8
Rated breaking capacity I1 AC (kA) 80000
Weight (gr) 1600
Price List €530.92/pc
Quantity
lock Datasheet
Fuse 7,2kV 53x442 back-up with striker 2,5A 80N

Fuse 7,2kV 53x442 back-up with striker 2,5A 80N

Reference 3010813.2,5.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 2,5
Rated Voltage Un AC (V) 7200
Applicable standards IEC
Power loss (W) 5,2
Resistance (ohm) 0,63
Fuse Dimension (mm) 67x442
Melting I²t value (A²s) 7,2
Minimum breaking current (A) 20
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 6264
Total clearing I²t @Un AC (A²s) 22
Rated breaking capacity I1 AC (kA) 80000
Product available on request Ask for more information
Filter by
Manufacturer
Series name
Fuse size
Class
Fuse Connection/Terminal type
Rated current In (A)
Rated Voltage Un AC (V)
Rated Voltage Un DC (V)
Applicable standards
Product added to compare.
Product added to wishlist
