List of products by manufacturer SIBA

Fuse DIN000 80mm aR 500V with indicator, w/o lug 400A

Fuse DIN000 80mm aR 500V with indicator, w/o lug 400A

Reference 2028220.400.0 - Manufacturer SIBA
Class aR
Rated current In (A) 400
Rated Voltage Un AC (V) 690
Dimension 000
Applicable standards IEC
Power loss (W) 70
Melting I²t value (A²s) 32100
Fuse Connection/Terminal type Screw fixing
Fixing connection centres (mm) 80
Voltage of total clearing I2t test 550
Total clearing I²t @Un AC (A²s) 106000
Rated breaking capacity I1 AC (kA) 200000
Weight (gr) 140
Price List €31.24/pc
Quantity
lock Datasheet
Fuse DIN000 80mm aR 690V UL with indicator, w/o lug 50A

Fuse DIN000 80mm aR 690V UL with indicator, w/o lug 50A

Reference 2028220.50.0 - Manufacturer SIBA
Class aR
Rated current In (A) 50
Rated Voltage Un AC (V) 690
Dimension 000
Applicable standards IEC, UL
Power loss (W) 12
Melting I²t value (A²s) 140
Fuse Connection/Terminal type Screw fixing
Fixing connection centres (mm) 80
Voltage of total clearing I2t test 660
Total clearing I²t @Un AC (A²s) 770
Rated breaking capacity I1 AC (kA) 200000
Weight (gr) 130
Price List €49.61/pc
Quantity
lock Datasheet
Fuse DIN000 80mm aR 690V UL with indicator, w/o lug 63A

Fuse DIN000 80mm aR 690V UL with indicator, w/o lug 63A

Reference 2028220.63.0 - Manufacturer SIBA
Class aR
Rated current In (A) 63
Rated Voltage Un AC (V) 690
Dimension 000
Applicable standards IEC, UL
Power loss (W) 14
Melting I²t value (A²s) 250
Fuse Connection/Terminal type Screw fixing
Fixing connection centres (mm) 80
Voltage of total clearing I2t test 660
Total clearing I²t @Un AC (A²s) 1400
Rated breaking capacity I1 AC (kA) 200000
Weight (gr) 130
Price List €50.47/pc
Quantity
lock Datasheet
Fuse DIN000 80mm aR 690V UL with indicator, w/o lug 80A

Fuse DIN000 80mm aR 690V UL with indicator, w/o lug 80A

Reference 2028220.80.0 - Manufacturer SIBA
Class aR
Rated current In (A) 80
Rated Voltage Un AC (V) 690
Dimension 000
Applicable standards IEC, UL
Power loss (W) 18
Melting I²t value (A²s) 470
Fuse Connection/Terminal type Screw fixing
Fixing connection centres (mm) 80
Voltage of total clearing I2t test 660
Total clearing I²t @Un AC (A²s) 2600
Rated breaking capacity I1 AC (kA) 200000
Weight (gr) 124
Price List €52.28/pc
Quantity
lock Datasheet
Fuse NH000 80mm 690V aR w/o lug 100A

Fuse NH000 80mm 690V aR w/o lug 100A

Reference 2028221.100.0 - Manufacturer SIBA
Class aR
Rated current In (A) 100
Rated Voltage Un AC (V) 690
Applicable standards IEC, UL
Power loss (W) 22
Melting I²t value (A²s) 730
Fuse Connection/Terminal type Screw fixing
Total clearing I²t @Un AC (A²s) 4000
Rated breaking capacity I1 AC (kA) 200000
Price List €214.26/pc
Quantity
lock Datasheet
Fuse NH000 80mm 690V aR w/o lug 110A

Fuse NH000 80mm 690V aR w/o lug 110A

Reference 2028221.110.0 - Manufacturer SIBA
Class aR
Rated current In (A) 110
Rated Voltage Un AC (V) 690
Applicable standards IEC, UL
Power loss (W) 24
Melting I²t value (A²s) 890
Fuse Connection/Terminal type Screw fixing
Total clearing I²t @Un AC (A²s) 4900
Rated breaking capacity I1 AC (kA) 200000
Product available on request Ask for more information
Fuse NH000 80mm 690V aR w/o lug 125A

Fuse NH000 80mm 690V aR w/o lug 125A

Reference 2028221.125.0 - Manufacturer SIBA
Class aR
Rated current In (A) 125
Rated Voltage Un AC (V) 690
Applicable standards IEC, UL
Power loss (W) 26
Melting I²t value (A²s) 1300
Fuse Connection/Terminal type Screw fixing
Total clearing I²t @Un AC (A²s) 7200
Rated breaking capacity I1 AC (kA) 200000
Price List €235.95/pc
Quantity
lock Datasheet
Fuse NH000 80mm 690V aR w/o lug 150A

Fuse NH000 80mm 690V aR w/o lug 150A

Reference 2028221.150.0 - Manufacturer SIBA
Class aR
Rated current In (A) 150
Rated Voltage Un AC (V) 690
Applicable standards IEC, UL
Power loss (W) 29
Melting I²t value (A²s) 2000
Fuse Connection/Terminal type Screw fixing
Total clearing I²t @Un AC (A²s) 11000
Rated breaking capacity I1 AC (kA) 200000
Product available on request Ask for more information
Fuse NH000 80mm 690V aR w/o lug 160A

Fuse NH000 80mm 690V aR w/o lug 160A

Reference 2028221.160.0 - Manufacturer SIBA
Class aR
Rated current In (A) 160
Rated Voltage Un AC (V) 690
Applicable standards IEC, UL
Power loss (W) 32
Melting I²t value (A²s) 2800
Fuse Connection/Terminal type Screw fixing
Total clearing I²t @Un AC (A²s) 15400
Rated breaking capacity I1 AC (kA) 200000
Price List €274.98/pc
Quantity
lock Datasheet
Fuse NH000 80mm 690V aR w/o lug 180A

Fuse NH000 80mm 690V aR w/o lug 180A

Reference 2028221.180.0 - Manufacturer SIBA
Class aR
Rated current In (A) 180
Rated Voltage Un AC (V) 690
Applicable standards IEC, UL
Power loss (W) 35
Melting I²t value (A²s) 3700
Fuse Connection/Terminal type Screw fixing
Total clearing I²t @Un AC (A²s) 20400
Rated breaking capacity I1 AC (kA) 200000
Product available on request Ask for more information
Fuse NH000 80mm 690V aR w/o lug 200A

Fuse NH000 80mm 690V aR w/o lug 200A

Reference 2028221.200.0 - Manufacturer SIBA
Class aR
Rated current In (A) 200
Rated Voltage Un AC (V) 690
Applicable standards IEC, UL
Power loss (W) 39
Melting I²t value (A²s) 4500
Fuse Connection/Terminal type Screw fixing
Total clearing I²t @Un AC (A²s) 25000
Rated breaking capacity I1 AC (kA) 200000
Price List €275.65/pc
Quantity
lock Datasheet
Fuse NH000 80mm 690V aR w/o lug 225A

Fuse NH000 80mm 690V aR w/o lug 225A

Reference 2028221.225.0 - Manufacturer SIBA
Class aR
Rated current In (A) 225
Rated Voltage Un AC (V) 690
Applicable standards IEC, UL
Power loss (W) 44
Melting I²t value (A²s) 6600
Fuse Connection/Terminal type Screw fixing
Total clearing I²t @Un AC (A²s) 37000
Rated breaking capacity I1 AC (kA) 200000
Product available on request Ask for more information
