List of products by manufacturer SIBA

Fuse DIN00 80mm gR 660V with indicator and lug 100A

Fuse DIN00 80mm gR 660V with indicator and lug 100A

Reference 2041204.100.0 - Manufacturer SIBA
Class gR
Rated current In (A) 100
Rated Voltage Un AC (V) 660
Dimension 00
Applicable standards IEC
Power loss (W) 18
Melting I²t value (A²s) 930
Fuse Connection/Terminal type Screw fixing
Fixing connection centres (mm) 80
Voltage of total clearing I2t test 660
Total clearing I²t @Un AC (A²s) 6400
Rated breaking capacity I1 AC (kA) 100000
Weight (gr) 254
Price List €45.96/pc
Quantity
lock Datasheet
Fuse DIN00 80mm aR 660V with indicator and lug 125A

Fuse DIN00 80mm aR 660V with indicator and lug 125A

Reference 2041204.125.0 - Manufacturer SIBA
Class aR
Rated current In (A) 125
Rated Voltage Un AC (V) 660
Dimension 00
Applicable standards IEC
Power loss (W) 22
Melting I²t value (A²s) 1650
Fuse Connection/Terminal type Screw fixing
Fixing connection centres (mm) 80
Voltage of total clearing I2t test 660
Total clearing I²t @Un AC (A²s) 11200
Rated breaking capacity I1 AC (kA) 100000
Weight (gr) 200
Price List €48.16/pc
Quantity
lock Datasheet
Fuse DIN00 80mm gR 660V with indicator and lug 16A

Fuse DIN00 80mm gR 660V with indicator and lug 16A

Reference 2041204.16.0 - Manufacturer SIBA
Class gR
Rated current In (A) 16
Rated Voltage Un AC (V) 660
Dimension 00
Applicable standards IEC
Power loss (W) 4,6
Melting I²t value (A²s) 10
Fuse Connection/Terminal type Screw fixing
Fixing connection centres (mm) 80
Voltage of total clearing I2t test 660
Total clearing I²t @Un AC (A²s) 70
Rated breaking capacity I1 AC (kA) 100000
Weight (gr) 200
Price List €14.79/pc
Quantity
lock Datasheet
Fuse DIN00 80mm aR 660V with indicator and lug 160A

Fuse DIN00 80mm aR 660V with indicator and lug 160A

Reference 2041204.160.0 - Manufacturer SIBA
Class aR
Rated current In (A) 160
Rated Voltage Un AC (V) 660
Dimension 00
Applicable standards IEC
Power loss (W) 26
Melting I²t value (A²s) 4250
Fuse Connection/Terminal type Screw fixing
Fixing connection centres (mm) 80
Voltage of total clearing I2t test 660
Total clearing I²t @Un AC (A²s) 29000
Rated breaking capacity I1 AC (kA) 100000
Weight (gr) 200
Price List €53.73/pc
Quantity
lock Datasheet
Fuse DIN00 80mm gR 660V with indicator and lug 20A

Fuse DIN00 80mm gR 660V with indicator and lug 20A

Reference 2041204.20.0 - Manufacturer SIBA
Class gR
Rated current In (A) 20
Rated Voltage Un AC (V) 660
Dimension 00
Applicable standards IEC
Power loss (W) 5,5
Melting I²t value (A²s) 17
Fuse Connection/Terminal type Screw fixing
Fixing connection centres (mm) 80
Voltage of total clearing I2t test 660
Total clearing I²t @Un AC (A²s) 120
Rated breaking capacity I1 AC (kA) 100000
Weight (gr) 200
Price List €14.84/pc
Quantity
lock Datasheet
Fuse DIN00 80mm aR 660V with indicator and lug 200A

Fuse DIN00 80mm aR 660V with indicator and lug 200A

Reference 2041204.200.0 - Manufacturer SIBA
Class aR
Rated current In (A) 200
Rated Voltage Un AC (V) 660
Dimension 00
Applicable standards IEC
Power loss (W) 28
Melting I²t value (A²s) 8000
Fuse Connection/Terminal type Screw fixing
Fixing connection centres (mm) 80
Voltage of total clearing I2t test 660
Total clearing I²t @Un AC (A²s) 54400
Rated breaking capacity I1 AC (kA) 100000
Weight (gr) 210
Price List €51.62/pc
Quantity
lock Datasheet
Fuse DIN00 80mm gR 660V with indicator and lug 25A

Fuse DIN00 80mm gR 660V with indicator and lug 25A

Reference 2041204.25.0 - Manufacturer SIBA
Class gR
Rated current In (A) 25
Rated Voltage Un AC (V) 660
Dimension 00
Applicable standards IEC
Power loss (W) 6,7
Melting I²t value (A²s) 29
Fuse Connection/Terminal type Screw fixing
Fixing connection centres (mm) 80
Voltage of total clearing I2t test 660
Total clearing I²t @Un AC (A²s) 200
Rated breaking capacity I1 AC (kA) 100000
Weight (gr) 200
Price List €150.47/pc
Quantity
lock Datasheet
Fuse DIN00 80mm aR 660V with indicator and lug 250A

Fuse DIN00 80mm aR 660V with indicator and lug 250A

Reference 2041204.250.0 - Manufacturer SIBA
Class aR
Rated current In (A) 250
Rated Voltage Un AC (V) 660
Dimension 00
Applicable standards IEC
Power loss (W) 31
Melting I²t value (A²s) 16800
Fuse Connection/Terminal type Screw fixing
Fixing connection centres (mm) 80
Voltage of total clearing I2t test 660
Total clearing I²t @Un AC (A²s) 114300
Rated breaking capacity I1 AC (kA) 100000
Weight (gr) 240
Price List €52.23/pc
Quantity
lock Datasheet
Fuse DIN00 80mm aR 690V UL with indicator and lug 40A

Fuse DIN00 80mm aR 690V UL with indicator and lug 40A

Reference 2041220.40.0 - Manufacturer SIBA
Class aR
Rated current In (A) 40
Rated Voltage Un AC (V) 690
Dimension 00
Applicable standards IEC, UL
Fuse Connection/Terminal type Screw fixing
Fixing connection centres (mm) 80
Voltage of total clearing I2t test 660
Rated breaking capacity I1 AC (kA) 200000
Weight (gr) 250
Price List €42.99/pc
Quantity
lock Datasheet
Fuse DIN00 80mm aR 690VUL with indic and switch adapter 375A

Fuse DIN00 80mm aR 690VUL with indic and switch adapter 375A

Reference 2041220.375.0 - Manufacturer SIBA
Class aR
Rated current In (A) 375
Rated Voltage Un AC (V) 690
Dimension 00
Applicable standards IEC, UL
Fuse Connection/Terminal type Screw fixing
Fixing connection centres (mm) 80
Voltage of total clearing I2t test 660
Rated breaking capacity I1 AC (kA) 200000
Weight (gr) 250
Price List €78.18/pc
Quantity
lock Datasheet
Fuse DIN00 80mm aR 690VUL with indic and switch adapter 350A

Fuse DIN00 80mm aR 690VUL with indic and switch adapter 350A

Reference 2041220.350.0 - Manufacturer SIBA
Class aR
Rated current In (A) 350
Rated Voltage Un AC (V) 690
Dimension 00
Applicable standards IEC, UL
Power loss (W) 57
Melting I²t value (A²s) 20000
Fuse Connection/Terminal type Screw fixing
Fixing connection centres (mm) 80
Voltage of total clearing I2t test 660
Total clearing I²t @Un AC (A²s) 110000
Rated breaking capacity I1 AC (kA) 200000
Weight (gr) 250
Price List €66.17/pc
Quantity
lock Datasheet
Fuse DIN00 80mm aR 690VUL with indic and switch adapter 400A

Fuse DIN00 80mm aR 690VUL with indic and switch adapter 400A

Reference 2041220.400.0 - Manufacturer SIBA
Class aR
Rated current In (A) 400
Rated Voltage Un AC (V) 690
Dimension 00
Applicable standards IEC, UL
Power loss (W) 68
Melting I²t value (A²s) 28400
Fuse Connection/Terminal type Screw fixing
Fixing connection centres (mm) 80
Voltage of total clearing I2t test 660
Total clearing I²t @Un AC (A²s) 156000
Rated breaking capacity I1 AC (kA) 200000
Weight (gr) 250
Price List €70.44/pc
Quantity
lock Datasheet
