List of products by manufacturer SIBA

Showing 9001-9036 of 9238 item(s)

Fuse 750V NH3L / SQB2 aSt 250A

Reference 2003166.250.0 - Manufacturer SIBA

Class	aSt
Rated current In (A)	250
Power loss (W)	51
Melting I²t value (A²s)	26500
Fuse Connection/Terminal type	NH knife
Total clearing I²t @Un AC (A²s)	188000

Product available on request Ask for more information

Fuse 750V NH3L / SQB2 aSt 315A

Reference 2003166.315.0 - Manufacturer SIBA

Class	aSt
Rated current In (A)	315
Power loss (W)	61
Melting I²t value (A²s)	47200
Fuse Connection/Terminal type	NH knife
Total clearing I²t @Un AC (A²s)	335000

Product available on request Ask for more information

Fuse SQB2 US style gPV 1100VDC 300A

Reference 2003429.300.0 - Manufacturer SIBA

Class	gPV
Rated current In (A)	300
Rated Voltage Un AC (V)	11000
Dimension	SQB2
Applicable standards	IEC, UL
Power loss (W)	56
Melting I²t value (A²s)	38000
Fuse Connection/Terminal type	Screw fixing
Voltage of total clearing I2t test	1100
Total clearing I²t @Un AC (A²s)	185000
Rated breaking capacity I1 AC (kA)	30000
Weight (gr)	1380

Price List €493.63/pc

Quantity

lock Datasheet

Fuse SQB2 US style gPV UL 2579 1100VDC 350A

Reference 2003429.350.0 - Manufacturer SIBA

Class	gPV
Rated current In (A)	350
Rated Voltage Un AC (V)	11000
Dimension	SQB2
Applicable standards	IEC, UL
Power loss (W)	62
Melting I²t value (A²s)	57000
Fuse Connection/Terminal type	Screw fixing
Voltage of total clearing I2t test	1100
Total clearing I²t @Un AC (A²s)	280000
Rated breaking capacity I1 AC (kA)	30000
Weight (gr)	1380

Price List €316.48/pc

Quantity

lock Datasheet

Fuse 900V NH3L / SQB-DC93 gR 125A

Reference 2003435.125.0 - Manufacturer SIBA

Class	gR
Rated current In (A)	125
Dimension	SQB3
Applicable standards	IEC, UL
Power loss (W)	22
Rated Voltage Un DC (V)	900
Rated breaking capacity I1 DC (kA)	100000
Melting I²t value (A²s)	5400
Fuse Connection/Terminal type	Screw fixing
Voltage of total clearing I2t test	900
Total clearing I²t @Un AC (A²s)	30000
Weight (gr)	21000

Product available on request Ask for more information

Fuse 900V NH3L / SQB-DC93 gR 160A

Reference 2003435.160.0 - Manufacturer SIBA

Class	gR
Rated current In (A)	160
Dimension	SQB3
Applicable standards	IEC, UL
Power loss (W)	27
Rated Voltage Un DC (V)	900
Rated breaking capacity I1 DC (kA)	100000
Melting I²t value (A²s)	9500
Fuse Connection/Terminal type	Screw fixing
Voltage of total clearing I2t test	900
Total clearing I²t @Un AC (A²s)	52000
Weight (gr)	2100

Product available on request Ask for more information

Fuse 900V NH3L / SQB-DC93 gR 200A

Reference 2003435.200.0 - Manufacturer SIBA

Class	gR
Rated current In (A)	200
Dimension	SQB3
Applicable standards	IEC, UL
Power loss (W)	30
Rated Voltage Un DC (V)	900
Rated breaking capacity I1 DC (kA)	100000
Melting I²t value (A²s)	21500
Fuse Connection/Terminal type	Screw fixing
Voltage of total clearing I2t test	900
Total clearing I²t @Un AC (A²s)	116000
Weight (gr)	2100

Product available on request Ask for more information

Fuse 900V NH3L / SQB-DC93 gR 250A

Reference 2003435.250.0 - Manufacturer SIBA

Class	gR
Rated current In (A)	250
Dimension	SQB3
Applicable standards	IEC, UL
Power loss (W)	34
Rated Voltage Un DC (V)	900
Rated breaking capacity I1 DC (kA)	100000
Melting I²t value (A²s)	38200
Fuse Connection/Terminal type	Screw fixing
Voltage of total clearing I2t test	900
Total clearing I²t @Un AC (A²s)	206000
Weight (gr)	2100

Product available on request Ask for more information

Fuse 900V NH3L / SQB-DC93 gR 315A

Reference 2003435.315.0 - Manufacturer SIBA

Class	gR
Rated current In (A)	315
Dimension	SQB3
Applicable standards	IEC, UL
Power loss (W)	50
Rated Voltage Un DC (V)	900
Rated breaking capacity I1 DC (kA)	100000
Melting I²t value (A²s)	57100
Fuse Connection/Terminal type	Screw fixing
Voltage of total clearing I2t test	900
Total clearing I²t @Un AC (A²s)	307000
Weight (gr)	2100

Product available on request Ask for more information

Fuse 900V NH3L / SQB-DC93 gR 350A

Reference 2003435.350.0 - Manufacturer SIBA

Class	gR
Rated current In (A)	350
Applicable standards	IEC, UL
Power loss (W)	52
Melting I²t value (A²s)	79700
Fuse Connection/Terminal type	NH knife
Total clearing I²t @Un AC (A²s)	428000

Product available on request Ask for more information

Fuse 800V NH3L / SQB-DC93 gR 400A

Reference 2003435.400.0 - Manufacturer SIBA

Class	gR
Rated current In (A)	400
Dimension	SQB3
Applicable standards	IEC, UL
Power loss (W)	58
Rated Voltage Un DC (V)	800
Rated breaking capacity I1 DC (kA)	100000
Melting I²t value (A²s)	106000
Fuse Connection/Terminal type	Screw fixing
Voltage of total clearing I2t test	900
Total clearing I²t @Un AC (A²s)	561000
Weight (gr)	2100

Product available on request Ask for more information

Fuse 800V NH3L / SQB-DC93 gR 500A

Reference 2003435.500.0 - Manufacturer SIBA

Class	gR
Rated current In (A)	500
Dimension	SQB3
Applicable standards	IEC, UL
Power loss (W)	74
Rated Voltage Un DC (V)	800
Rated breaking capacity I1 DC (kA)	100000
Melting I²t value (A²s)	189000
Fuse Connection/Terminal type	Screw fixing
Voltage of total clearing I2t test	900
Total clearing I²t @Un AC (A²s)	975000
Weight (gr)	2100

Product available on request Ask for more information

Fuse 800V NH3L / SQB-DC93 gR 550A

Reference 2003435.550.0 - Manufacturer SIBA

Class	gR
Rated current In (A)	550
Dimension	SQB3
Applicable standards	IEC, UL
Power loss (W)	79
Rated Voltage Un DC (V)	800
Rated breaking capacity I1 DC (kA)	100000
Melting I²t value (A²s)	258000
Fuse Connection/Terminal type	Screw fixing
Voltage of total clearing I2t test	900
Total clearing I²t @Un AC (A²s)	1330000
Weight (gr)	2100

Product available on request Ask for more information

Fuse 800V NH3L / SQB-DC93 gR 630A

Reference 2003435.630.0 - Manufacturer SIBA

Class	gR
Rated current In (A)	630
Dimension	SQB3
Applicable standards	IEC, UL
Power loss (W)	90
Rated Voltage Un DC (V)	800
Rated breaking capacity I1 DC (kA)	100000
Melting I²t value (A²s)	331000
Fuse Connection/Terminal type	Screw fixing
Voltage of total clearing I2t test	900
Total clearing I²t @Un AC (A²s)	1700000
Weight (gr)	2100

Product available on request Ask for more information

Fuse NH1XL 1500DC gPV UL without indicator 50A

Reference 2004128.50.0 - Manufacturer SIBA

Class	gPV
Rated current In (A)	50
Dimension	NH1XL
Applicable standards	IEC, UL
Power loss (W)	18
Voltage drop (mV)	3
Rated Voltage Un DC (V)	1500
Rated breaking capacity I1 DC (kA)	100000
Melting I²t value (A²s)	361
Fuse Connection/Terminal type	NH knife
Voltage of total clearing I2t test	1500
Total clearing I²t @Un AC (A²s)	2200

Product available on request Ask for more information

Fuse SQB1 1500VDC gPV UL2579 USA knife contacts 100A

Reference 2004528.100.0 - Manufacturer SIBA

Class	gPV
Rated current In (A)	100
Dimension	SQB1
Applicable standards	IEC, UL
Power loss (W)	25
Rated Voltage Un DC (V)	1500
Time costant L/R (ms)	3
Melting I²t value (A²s)	1650
Fuse Connection/Terminal type	NH knife
Voltage of total clearing I2t test	1500
Total clearing I²t @Un AC (A²s)	9900

Product available on request Ask for more information

Fuse SQB1 1500VDC gPV UL2579 USA knife contacts 50A

Reference 2004528.50.0 - Manufacturer SIBA

Class	gPV
Rated current In (A)	50
Dimension	SQB1
Applicable standards	IEC, UL
Power loss (W)	18
Rated Voltage Un DC (V)	1500
Time costant L/R (ms)	3
Melting I²t value (A²s)	361
Fuse Connection/Terminal type	NH knife
Voltage of total clearing I2t test	1500
Total clearing I²t @Un AC (A²s)	2200

Product available on request Ask for more information

Fuse SQB1 1500VDC gPV UL2579 USA knife contacts 63A

Reference 2004528.63.0 - Manufacturer SIBA

Class	gPV
Rated current In (A)	63
Dimension	SQB1
Applicable standards	IEC, UL
Power loss (W)	22
Rated Voltage Un DC (V)	1500
Time costant L/R (ms)	3
Melting I²t value (A²s)	480
Fuse Connection/Terminal type	NH knife
Voltage of total clearing I2t test	1500
Total clearing I²t @Un AC (A²s)	2900

Product available on request Ask for more information

Fuse SQB1 1500VDC gPV UL2579 USA knife contacts 80A

Reference 2004528.80.0 - Manufacturer SIBA

Class	gPV
Rated current In (A)	80
Dimension	SQB1
Applicable standards	IEC, UL
Power loss (W)	24
Rated Voltage Un DC (V)	1500
Time costant L/R (ms)	3
Melting I²t value (A²s)	1060
Fuse Connection/Terminal type	NH knife
Voltage of total clearing I2t test	1500
Total clearing I²t @Un AC (A²s)	6400

Product available on request Ask for more information

Fuse SQB1 1500VDC gPV UL2579 USA knife contacts +ind. 100A

Reference 2004529.100.0 - Manufacturer SIBA

Class	gPV
Rated current In (A)	100
Dimension	SQB1
Applicable standards	IEC, UL
Power loss (W)	25
Rated Voltage Un DC (V)	1500
Time costant L/R (ms)	3
Melting I²t value (A²s)	1650
Fuse Connection/Terminal type	NH knife
Voltage of total clearing I2t test	1500
Total clearing I²t @Un AC (A²s)	9900

Price List €180.77/pc

Quantity

lock Datasheet

Fuse SQB1 1500VDC gPV UL2579 USA knife contacts +ind. 125A

Reference 2004529.125.0 - Manufacturer SIBA

Class	gPV
Rated current In (A)	125
Dimension	SQB1
Applicable standards	IEC, UL
Power loss (W)	27
Rated Voltage Un DC (V)	1500
Time costant L/R (ms)	3
Melting I²t value (A²s)	2950
Fuse Connection/Terminal type	NH knife
Voltage of total clearing I2t test	1500
Total clearing I²t @Un AC (A²s)	18000

Product available on request Ask for more information

Fuse SQB1 1500VDC gPV UL2579 USA knife contacts +ind. 200A

Reference 2004529.200.0 - Manufacturer SIBA

Class	gPV
Rated current In (A)	200
Dimension	SQB1
Applicable standards	IEC, UL
Power loss (W)	44
Rated Voltage Un DC (V)	1500
Time costant L/R (ms)	3
Melting I²t value (A²s)	14300
Fuse Connection/Terminal type	NH knife
Voltage of total clearing I2t test	1500
Total clearing I²t @Un AC (A²s)	85000

Product available on request Ask for more information

Fuse SQB1 1500VDC gPV UL2579 USA knife contacts +ind. 50A

Reference 2004529.50.0 - Manufacturer SIBA

Class	gPV
Rated current In (A)	50
Dimension	SQB1
Applicable standards	IEC, UL
Power loss (W)	18
Rated Voltage Un DC (V)	1500
Time costant L/R (ms)	3
Melting I²t value (A²s)	361
Fuse Connection/Terminal type	NH knife
Voltage of total clearing I2t test	1500
Total clearing I²t @Un AC (A²s)	2200

Product available on request Ask for more information

Fuse SQB1 1500VDC gPV UL2579 USA knife contacts +ind. 63A

Reference 2004529.63.0 - Manufacturer SIBA

Class	gPV
Rated current In (A)	63
Dimension	SQB1
Applicable standards	IEC, UL
Power loss (W)	22
Rated Voltage Un DC (V)	1500
Time costant L/R (ms)	3
Melting I²t value (A²s)	480
Fuse Connection/Terminal type	NH knife
Voltage of total clearing I2t test	1500
Total clearing I²t @Un AC (A²s)	2900

Product available on request Ask for more information

Fuse SQB1 1500VDC gPV UL2579 USA knife contacts +ind. 80A

Reference 2004529.80.0 - Manufacturer SIBA

Class	gPV
Rated current In (A)	80
Dimension	SQB1
Applicable standards	IEC, UL
Power loss (W)	24
Rated Voltage Un DC (V)	1500
Time costant L/R (ms)	3
Melting I²t value (A²s)	1060
Fuse Connection/Terminal type	NH knife
Voltage of total clearing I2t test	1500
Total clearing I²t @Un AC (A²s)	6400

Product available on request Ask for more information

Fuse NH1XL 1500V DC gBat US blade without ind. 100A

Reference 2004536.100.0 - Manufacturer SIBA

Class	gBat, gR
Rated current In (A)	100
Dimension	NH1XL
Applicable standards	IEC, UL
Power loss (W)	25
Rated Voltage Un DC (V)	1500
Time costant L/R (ms)	3
Rated breaking capacity I1 DC (kA)	100000
Melting I²t value (A²s)	1650
Fuse Connection/Terminal type	NH knife
Voltage of total clearing I2t test	1500
Total clearing I²t @Un AC (A²s)	9900

Product available on request Ask for more information

Fuse NH1XL 1500V DC gBat US blade without ind. 125A

Reference 2004536.125.0 - Manufacturer SIBA

Class	gBat, gR
Rated current In (A)	125
Dimension	NH1XL
Applicable standards	IEC, UL
Power loss (W)	27
Rated Voltage Un DC (V)	1500
Time costant L/R (ms)	3
Rated breaking capacity I1 DC (kA)	100000
Melting I²t value (A²s)	2950
Fuse Connection/Terminal type	NH knife
Voltage of total clearing I2t test	1500
Total clearing I²t @Un AC (A²s)	18000

Product available on request Ask for more information

Fuse NH1XL 1500V DC gBat US blade without ind.160A

Reference 2004536.160.0 - Manufacturer SIBA

Class	gBat, gR
Rated current In (A)	160
Dimension	NH1XL
Applicable standards	IEC, UL
Power loss (W)	37
Rated Voltage Un DC (V)	1500
Time costant L/R (ms)	3
Rated breaking capacity I1 DC (kA)	100000
Melting I²t value (A²s)	5600
Fuse Connection/Terminal type	NH knife
Voltage of total clearing I2t test	1500
Total clearing I²t @Un AC (A²s)	34000

Product available on request Ask for more information

Fuse NH1XL 1500V DC gBat US blade without ind. 200A

Reference 2004536.200.0 - Manufacturer SIBA

Class	gBat, gR
Rated current In (A)	200
Dimension	NH1XL
Applicable standards	IEC, UL
Power loss (W)	44
Rated Voltage Un DC (V)	1500
Time costant L/R (ms)	3
Rated breaking capacity I1 DC (kA)	100000
Melting I²t value (A²s)	14300
Fuse Connection/Terminal type	NH knife
Voltage of total clearing I2t test	1500
Total clearing I²t @Un AC (A²s)	85000

Price List €1,114.60/pc

Quantity

lock Datasheet

Fuse NH1XL 1500V DC gBat US blade without ind. 50A

Reference 2004536.50.0 - Manufacturer SIBA

Class	gBat, gR
Rated current In (A)	50
Dimension	NH1XL
Applicable standards	IEC, UL
Power loss (W)	18
Rated Voltage Un DC (V)	1500
Time costant L/R (ms)	3
Rated breaking capacity I1 DC (kA)	100000
Melting I²t value (A²s)	361
Fuse Connection/Terminal type	NH knife
Voltage of total clearing I2t test	1500
Total clearing I²t @Un AC (A²s)	2200

Product available on request Ask for more information

Fuse NH1XL 1500V DC gBat US blade without ind. 63A

Reference 2004536.63.0 - Manufacturer SIBA

Class	gBat, gR
Rated current In (A)	63
Dimension	NH1XL
Applicable standards	IEC, UL
Power loss (W)	22
Rated Voltage Un DC (V)	1500
Time costant L/R (ms)	3
Rated breaking capacity I1 DC (kA)	100000
Melting I²t value (A²s)	480
Fuse Connection/Terminal type	NH knife
Voltage of total clearing I2t test	1500
Total clearing I²t @Un AC (A²s)	2900

Product available on request Ask for more information

Fuse NH1XL 1500V DC gBat US blade without ind. 80A

Reference 2004536.80.0 - Manufacturer SIBA

Class	gBat, gR
Rated current In (A)	80
Dimension	NH1XL
Applicable standards	IEC, UL
Power loss (W)	24
Rated Voltage Un DC (V)	1500
Time costant L/R (ms)	3
Rated breaking capacity I1 DC (kA)	100000
Melting I²t value (A²s)	1060
Fuse Connection/Terminal type	NH knife
Voltage of total clearing I2t test	1500
Total clearing I²t @Un AC (A²s)	6400

Product available on request Ask for more information

Fuse NH1XL 1500V DC gBat US with ind. 100A

Reference 2004537.100.0 - Manufacturer SIBA

Class	gBat, gR
Rated current In (A)	100
Dimension	NH1XL
Applicable standards	IEC, UL
Power loss (W)	25
Rated Voltage Un DC (V)	1500
Time costant L/R (ms)	3
Rated breaking capacity I1 DC (kA)	100000
Melting I²t value (A²s)	1650
Fuse Connection/Terminal type	NH knife
Voltage of total clearing I2t test	1500
Total clearing I²t @Un AC (A²s)	9900

Product available on request Ask for more information

Fuse NH1XL 1500V DC gBat US with ind. 125A

Reference 2004537.125.0 - Manufacturer SIBA

Class	gBat, gR
Rated current In (A)	125
Dimension	NH1XL
Applicable standards	IEC, UL
Power loss (W)	27
Rated Voltage Un DC (V)	1500
Time costant L/R (ms)	3
Rated breaking capacity I1 DC (kA)	100000
Melting I²t value (A²s)	2950
Fuse Connection/Terminal type	NH knife
Voltage of total clearing I2t test	1500
Total clearing I²t @Un AC (A²s)	18000

Product available on request Ask for more information

Fuse NH1XL 1500V DC gBat US with ind. 160A

Reference 2004537.160.0 - Manufacturer SIBA

Class	gBat, gR
Rated current In (A)	160
Dimension	NH1XL
Applicable standards	IEC, UL
Power loss (W)	37
Rated Voltage Un DC (V)	1500
Time costant L/R (ms)	3
Rated breaking capacity I1 DC (kA)	100000
Melting I²t value (A²s)	5600
Fuse Connection/Terminal type	NH knife
Voltage of total clearing I2t test	1500
Total clearing I²t @Un AC (A²s)	34000

Product available on request Ask for more information

Fuse NH1XL 1500V DC gBat US with ind. 200A

Reference 2004537.200.0 - Manufacturer SIBA

Class	gBat, gR
Rated current In (A)	200
Dimension	NH1XL
Applicable standards	IEC, UL
Power loss (W)	44
Rated Voltage Un DC (V)	1500
Time costant L/R (ms)	3
Rated breaking capacity I1 DC (kA)	100000
Melting I²t value (A²s)	14300
Fuse Connection/Terminal type	NH knife
Voltage of total clearing I2t test	1500
Total clearing I²t @Un AC (A²s)	85000

Price List €1,160.90/pc

Quantity

lock Datasheet

9238 products

01
• • •
250
•
251
•
252
• • •
257

List of products by manufacturer SIBA

INFORMATIONS

ACCOUNT

CONTACT US

NEWSLETTER
