List of products by manufacturer SIBA

Fuse SQB1 110mm aR 1250V switch adapter 90° 80A

Fuse SQB1 110mm aR 1250V switch adapter 90° 80A

Reference 2076632.80.0 - Manufacturer SIBA
Class aR
Rated current In (A) 80
Rated Voltage Un AC (V) 1250
Dimension SQB1
Applicable standards IEC, UL
Power loss (W) 35
Melting I²t value (A²s) 410
Fuse Connection/Terminal type Screw fixing
Fixing connection centres (mm) 110
Voltage of total clearing I2t test 1000
Total clearing I²t @Un AC (A²s) 2300
Rated breaking capacity I1 AC (kA) 1000
Weight (gr) 540
Product available on request Ask for more information
Fuse SQB1 110mm aR 1100V switch adapter 90° 500A

Fuse SQB1 110mm aR 1100V switch adapter 90° 500A

Reference 2076632.500.0 - Manufacturer SIBA
Class aR
Rated current In (A) 500
Rated Voltage Un AC (V) 1100
Dimension SQB1
Applicable standards IEC, UL
Power loss (W) 87
Melting I²t value (A²s) 66000
Fuse Connection/Terminal type Screw fixing
Fixing connection centres (mm) 110
Voltage of total clearing I2t test 1000
Total clearing I²t @Un AC (A²s) 340000
Rated breaking capacity I1 AC (kA) 100000
Weight (gr) 620
Price List €356.76/pc
Quantity
lock Datasheet
Fuse 2xSQB2 1250VaR 2 parallel bars with switch adapter800A

Fuse 2xSQB2 1250VaR 2 parallel bars with switch adapter800A

Reference 2077932.800.0 - Manufacturer SIBA
Class aR
Rated current In (A) 800
Rated Voltage Un AC (V) 1250
Dimension 2x SQB2
Applicable standards IEC, UL
Power loss (W) 158
Fixing dimensions M10
Melting I²t value (A²s) 124000
Fuse Connection/Terminal type Screw fixing
Voltage of total clearing I2t test 1000
Total clearing I²t @Un AC (A²s) 680000
Rated breaking capacity I1 AC (kA) 100000
Weight (gr) 2000
Price List €350.13/pc
Quantity
lock Datasheet
Fuse 2x SQB2 screw M10 aR 1250V lateral switch adapter 800A

Fuse 2x SQB2 screw M10 aR 1250V lateral switch adapter 800A

Reference 2077832.800.0 - Manufacturer SIBA
Class aR
Rated current In (A) 800
Rated Voltage Un AC (V) 1250
Dimension 2x SQB2
Applicable standards IEC, UL
Power loss (W) 158
Fixing dimensions M10
Melting I²t value (A²s) 124000
Fuse Connection/Terminal type Screw fixing
Voltage of total clearing I2t test 1000
Total clearing I²t @Un AC (A²s) 680000
Rated breaking capacity I1 AC (kA) 100000
Weight (gr) 1680
Price List €768.88/pc
Quantity
lock Datasheet
Fuse SQB3 screw M12 aR 800V top indicator 1400A

Fuse SQB3 screw M12 aR 800V top indicator 1400A

Reference 2078032.1400.0 - Manufacturer SIBA
Class aR
Rated current In (A) 1400
Rated Voltage Un AC (V) 800
Dimension SQB3
Applicable standards UL
Power loss (W) 210
Fixing dimensions M12
Melting I²t value (A²s) 852000
Fuse Connection/Terminal type Screw fixing
Voltage of total clearing I2t test 1000
Total clearing I²t @Un AC (A²s) 3900000
Rated breaking capacity I1 AC (kA) 100000
Weight (gr) 1030
Price List €837.40/pc
Quantity
lock Datasheet
Fuse SQB1 screw M8 aR 1250V top indicator 350A

Fuse SQB1 screw M8 aR 1250V top indicator 350A

Reference 2076032.350.0 - Manufacturer SIBA
Class aR
Rated current In (A) 350
Rated Voltage Un AC (V) 1250
Dimension SQB1
Applicable standards IEC, UL
Power loss (W) 70
Fixing dimensions M8
Melting I²t value (A²s) 22000
Fuse Connection/Terminal type Screw fixing
Voltage of total clearing I2t test 1000
Total clearing I²t @Un AC (A²s) 120000
Rated breaking capacity I1 AC (kA) 100000
Weight (gr) 540
Price List €236.52/pc
Quantity
lock Datasheet
Fuse SQB1 screw M8 aR 1100V top indicator 80A

Fuse SQB1 screw M8 aR 1100V top indicator 80A

Reference 2076032.80.0 - Manufacturer SIBA
Class aR
Rated current In (A) 80
Rated Voltage Un AC (V) 1250
Dimension SQB1
Applicable standards IEC, UL
Power loss (W) 35
Fixing dimensions M8
Melting I²t value (A²s) 410
Fuse Connection/Terminal type Screw fixing
Voltage of total clearing I2t test 1000
Total clearing I²t @Un AC (A²s) 2300
Rated breaking capacity I1 AC (kA) 100000
Weight (gr) 490
Price List €24.15/pc
Quantity
lock Datasheet
Fuse SQB1 screw M8 aR 1250V top indicator 250A

Fuse SQB1 screw M8 aR 1250V top indicator 250A

Reference 2076032.250.0 - Manufacturer SIBA
Class aR
Rated current In (A) 250
Rated Voltage Un AC (V) 1250
Dimension SQB1
Applicable standards IEC, UL
Power loss (W) 58
Fixing dimensions M8
Melting I²t value (A²s) 8400
Fuse Connection/Terminal type Screw fixing
Voltage of total clearing I2t test 1000
Total clearing I²t @Un AC (A²s) 46000
Rated breaking capacity I1 AC (kA) 100000
Weight (gr) 520
Price List €208.27/pc
Quantity
lock Datasheet
Fuse SQB1 screw M8 aR 1250V top indicator 315A

Fuse SQB1 screw M8 aR 1250V top indicator 315A

Reference 2076032.315.0 - Manufacturer SIBA
Class aR
Rated current In (A) 315
Rated Voltage Un AC (V) 1250
Dimension SQB1
Applicable standards IEC, UL
Power loss (W) 67
Fixing dimensions M8
Melting I²t value (A²s) 15000
Fuse Connection/Terminal type Screw fixing
Voltage of total clearing I2t test 1000
Total clearing I²t @Un AC (A²s) 81000
Rated breaking capacity I1 AC (kA) 100000
Weight (gr) 540
Price List €228.92/pc
Quantity
lock Datasheet
Fuse SQB1 screw M8 aR 1100V top indicator 630A

Fuse SQB1 screw M8 aR 1100V top indicator 630A

Reference 2076032.630.0 - Manufacturer SIBA
Class aR
Rated current In (A) 630
Rated Voltage Un AC (V) 1100
Dimension SQB1
Applicable standards IEC, UL
Power loss (W) 99
Fixing dimensions M8
Melting I²t value (A²s) 126000
Fuse Connection/Terminal type Screw fixing
Voltage of total clearing I2t test 1000
Total clearing I²t @Un AC (A²s) 670000
Rated breaking capacity I1 AC (kA) 100000
Weight (gr) 510
Price List €1,606.77/pc
Quantity
lock Datasheet
Fuse SQB1 screw M8 aR 1100V top indicator 500A

Fuse SQB1 screw M8 aR 1100V top indicator 500A

Reference 2076032.500.0 - Manufacturer SIBA
Class aR
Rated current In (A) 500
Rated Voltage Un AC (V) 1100
Dimension SQB1
Applicable standards IEC, UL
Power loss (W) 87
Fixing dimensions M8
Melting I²t value (A²s) 66000
Fuse Connection/Terminal type Screw fixing
Voltage of total clearing I2t test 1000
Total clearing I²t @Un AC (A²s) 340000
Rated breaking capacity I1 AC (kA) 100000
Weight (gr) 540
Price List €254.65/pc
Quantity
lock Datasheet
Fuse SQB1 US-UNC 5/16 aR 1100V lateral switch adapter 630A

Fuse SQB1 US-UNC 5/16 aR 1100V lateral switch adapter 630A

Reference 2076432.630.0 - Manufacturer SIBA
Class aR
Rated current In (A) 630
Rated Voltage Un AC (V) 1100
Dimension SQB1
Applicable standards IEC, UL
Power loss (W) 99
Melting I²t value (A²s) 126000
Fuse Connection/Terminal type Screw fixing
Fixing connection centres (mm) US-UNC 5/16
Voltage of total clearing I2t test 1000
Total clearing I²t @Un AC (A²s) 670000
Rated breaking capacity I1 AC (kA) 100000
Weight (gr) 510
Price List €418.13/pc
Quantity
lock Datasheet
