List of products by manufacturer SIBA

Showing 865-900 of 3503 item(s)

Fuse SQB2 110mmgRL/gS 690VAC/500VDC lat switch adapt 90 160A

Reference 2027834.160.0 - Manufacturer SIBA

Rated current In (A)	160
Rated Voltage Un AC (V)	690
Rated break.capacity I1 AC (A)	200000
Voltage of total I2t test	690
Format	Screw fixing
Dimension	SQB2-110mm
Pre-arcing I2t value (A2s)	7400
Total I2t value (A2s)	47000
Homologations	IEC
Power loss (W)	23
Rated Voltage Un DC (V)	500
Rated break.capacity I1 DC (A)	32000
Time costant L/R (ms)	15

Product available on request Ask for more information

Fuse SQB2 110mmgRL/gS 690VAC/500VDC lat switch adapt 90 200A

Reference 2027834.200.0 - Manufacturer SIBA

Rated current In (A)	200
Rated Voltage Un AC (V)	690
Rated break.capacity I1 AC (A)	200000
Voltage of total I2t test	690
Format	Screw fixing
Dimension	SQB2-110mm
Pre-arcing I2t value (A2s)	15000
Total I2t value (A2s)	95000
Homologations	IEC
Power loss (W)	27
Rated Voltage Un DC (V)	500
Rated break.capacity I1 DC (A)	32000

Product available on request Ask for more information

Fuse SQB2 110mmgRL/gS 690VAC/500VDC lat switch adapt 90 250A

Reference 2027834.250.0 - Manufacturer SIBA

Rated current In (A)	250
Rated Voltage Un AC (V)	690
Rated break.capacity I1 AC (A)	200000
Voltage of total I2t test	690
Format	Screw fixing
Dimension	SQB2-110mm
Pre-arcing I2t value (A2s)	30000
Total I2t value (A2s)	190000
Homologations	IEC
Power loss (W)	30
Rated Voltage Un DC (V)	500
Rated break.capacity I1 DC (A)	32000

Product available on request Ask for more information

Fuse SQB2 110mmgRL/gS 690VAC/500VDC lat switch adapt 90 315A

Reference 2027834.315.0 - Manufacturer SIBA

Rated current In (A)	315
Rated Voltage Un AC (V)	690
Rated break.capacity I1 AC (A)	200000
Voltage of total I2t test	690
Format	Screw fixing
Dimension	SQB2-110mm
Pre-arcing I2t value (A2s)	43000
Total I2t value (A2s)	271000
Homologations	IEC
Power loss (W)	40
Rated Voltage Un DC (V)	500
Rated break.capacity I1 DC (A)	32000
Time costant L/R (ms)	15

Product available on request Ask for more information

Fuse SQB2 110mmgRL/gS 690VAC/500VDC lat switch adapt 90 350A

Reference 2027834.350.0 - Manufacturer SIBA

Rated current In (A)	350
Rated Voltage Un AC (V)	690
Rated break.capacity I1 AC (A)	200000
Voltage of total I2t test	690
Format	Screw fixing
Dimension	SQB2-110mm
Pre-arcing I2t value (A2s)	58000
Total I2t value (A2s)	310000
Homologations	IEC
Power loss (W)	43
Rated Voltage Un DC (V)	500
Rated break.capacity I1 DC (A)	32000
Time costant L/R (ms)	15

Product available on request Ask for more information

Fuse SQB2 110mmgRL/gS 690VAC/500VDC lat switch adapt 90 400A

Reference 2027834.400.0 - Manufacturer SIBA

Rated current In (A)	400
Rated Voltage Un AC (V)	690
Rated break.capacity I1 AC (A)	200000
Voltage of total I2t test	690
Format	Screw fixing
Dimension	SQB2-110mm
Pre-arcing I2t value (A2s)	85000
Total I2t value (A2s)	442000
Homologations	IEC
Power loss (W)	48
Rated Voltage Un DC (V)	500
Rated break.capacity I1 DC (A)	32000
Time costant L/R (ms)	15

Product available on request Ask for more information

Fuse SQB2 110mmgRL/gS 690VAC/500VDC lat switch adapt 90 450A

Reference 2027834.450.0 - Manufacturer SIBA

Rated current In (A)	450
Rated Voltage Un AC (V)	690
Rated break.capacity I1 AC (A)	200000
Voltage of total I2t test	690
Format	Screw fixing
Dimension	SQB2-110mm
Pre-arcing I2t value (A2s)	107000
Total I2t value (A2s)	560000
Homologations	IEC
Power loss (W)	50
Rated Voltage Un DC (V)	500
Rated break.capacity I1 DC (A)	32000

Product available on request Ask for more information

Fuse SQB2 110mmgRL/gS 690VAC/500VDC lat switch adapt 90 500A

Reference 2027834.500.0 - Manufacturer SIBA

Rated current In (A)	500
Rated Voltage Un AC (V)	690
Rated break.capacity I1 AC (A)	200000
Voltage of total I2t test	690
Format	Screw fixing
Dimension	SQB2-110mm
Pre-arcing I2t value (A2s)	170000
Total I2t value (A2s)	880000
Homologations	IEC
Power loss (W)	63
Rated Voltage Un DC (V)	500
Rated break.capacity I1 DC (A)	32000

Product available on request Ask for more information

Fuse NH1 800V gG 50A

Reference 2031113.50.0 - Manufacturer SIBA

Class	gG
Rated current In (A)	50
Rated Voltage Un AC (V)	800
Rated break.capacity I1 AC (A)	120000
Voltage of total I2t test	800
Format	NH knife contact
Dimension	NH1
Pre-arcing I2t value (A2s)	2700
Total I2t value (A2s)	22000
Homologations	IEC
Power loss (W)	5,5

Price List €88.86/pc

Quantity

Fuse NH1 gRL 800V 100A

Reference 2031134.100.0 - Manufacturer SIBA

Rated current In (A)	100
Rated Voltage Un AC (V)	800
Rated break.capacity I1 AC (A)	120000
Voltage of total I2t test	800
Format	NH knife contact
Dimension	NH1
Pre-arcing I2t value (A2s)	2250
Total I2t value (A2s)	10400
Homologations	IEC
Power loss (W)	15

Price List €56.21/pc

Quantity

Fuse NH1 gRL 800V 80A

Reference 2031134.80.0 - Manufacturer SIBA

Rated current In (A)	80
Rated Voltage Un AC (V)	800
Rated break.capacity I1 AC (A)	120000
Voltage of total I2t test	800
Format	NH knife contact
Dimension	NH1
Pre-arcing I2t value (A2s)	1400
Total I2t value (A2s)	6400
Homologations	IEC
Power loss (W)	13

Price List €305.91/pc

Quantity

Fuse NH3 800V gG 160A

Reference 2031313.160.0 - Manufacturer SIBA

Class	gG
Rated current In (A)	160
Rated Voltage Un AC (V)	800
Rated break.capacity I1 AC (A)	120000
Voltage of total I2t test	800
Weight (g)	1080
Format	NH knife contact
Dimension	NH3
Pre-arcing I2t value (A2s)	60000
Total I2t value (A2s)	310000
Homologations	IEC
Power loss (W)	12

Price List €53.88/pc

Quantity

Fuse NH000/NH00C gG 500V insulated cover double ind 10A

Reference 2043813.10.0 - Manufacturer SIBA

Class	gG
Rated current In (A)	10
Rated Voltage Un AC (V)	500
Rated break.capacity I1 AC (A)	120000
Voltage of total I2t test	440
Weight (g)	130
Format	NH knife contact
Dimension	NH00C NH000
Pre-arcing I2t value (A2s)	230
Total I2t value (A2s)	560
Homologations	IEC
Power loss (W)	2,4

Price List €12.72/pc

Quantity

lock Datasheet

Fuse NH000/NH00C gG 500V insulated cover double ind 100A

Reference 2043813.100.0 - Manufacturer SIBA

Class	gG
Rated current In (A)	100
Rated Voltage Un AC (V)	500
Rated break.capacity I1 AC (A)	120000
Voltage of total I2t test	440
Weight (g)	130
Format	NH knife contact
Dimension	NH00C NH000
Pre-arcing I2t value (A2s)	28900
Total I2t value (A2s)	88600
Homologations	IEC
Power loss (W)	6,8

Price List €6.04/pc

Quantity

lock Datasheet

Fuse 22x58 500V DC gBat with pins 80mm 50A

Reference 5016236.50.0 - Manufacturer SIBA

Class	gBat
Rated current In (A)	870
Rated Voltage Un AC (V)	500
Format	Cylindrical
Dimension	22x58mm
Pre-arcing I2t value (A2s)	4200
Total I2t value (A2s)	500
Homologations	IEC
Power loss (W)	5,4
Rated Voltage Un DC (V)	50
Rated break.capacity I1 DC (A)	100000

Product available on request Ask for more information

Fuse 22x58 500V DC gBat with terminals 80mm 30A

Reference 5016136.30.0 - Manufacturer SIBA

Class	gBat
Rated current In (A)	190
Rated Voltage Un AC (V)	500
Format	Cylindrical
Dimension	22x58mm
Pre-arcing I2t value (A2s)	910
Total I2t value (A2s)	500
Homologations	IEC
Power loss (W)	4,6
Rated Voltage Un DC (V)	30
Rated break.capacity I1 DC (A)	100000

Product available on request Ask for more information

Fuse 22x58 500V DC gBat with terminals 80mm 32A

Reference 5016136.32.0 - Manufacturer SIBA

Class	gBat
Rated current In (A)	250
Rated Voltage Un AC (V)	500
Format	Cylindrical
Dimension	22x58mm
Pre-arcing I2t value (A2s)	1200
Total I2t value (A2s)	500
Homologations	IEC
Power loss (W)	4,8
Rated Voltage Un DC (V)	32
Rated break.capacity I1 DC (A)	100000

Product available on request Ask for more information

Fuse 22x58 500V DC gBat with terminals 80mm 35A

Reference 5016136.35.0 - Manufacturer SIBA

Class	gBat
Rated current In (A)	330
Rated Voltage Un AC (V)	500
Format	Cylindrical
Dimension	22x58mm
Pre-arcing I2t value (A2s)	1600
Total I2t value (A2s)	500
Homologations	IEC
Power loss (W)	5
Rated Voltage Un DC (V)	35
Rated break.capacity I1 DC (A)	100000

Product available on request Ask for more information

Fuse 22x58 500V DC gBat with terminals 80mm 40A

Reference 5016136.40.0 - Manufacturer SIBA

Class	gBat
Rated current In (A)	420
Rated Voltage Un AC (V)	500
Format	Cylindrical
Dimension	22x58mm
Pre-arcing I2t value (A2s)	2000
Total I2t value (A2s)	500
Homologations	IEC
Power loss (W)	5,2
Rated Voltage Un DC (V)	40
Rated break.capacity I1 DC (A)	100000

Product available on request Ask for more information

Fuse 22x58 500V DC gBat with terminals 80mm 50A

Reference 5016136.50.0 - Manufacturer SIBA

Class	gBat
Rated current In (A)	870
Rated Voltage Un AC (V)	500
Format	Cylindrical
Dimension	22x58mm
Pre-arcing I2t value (A2s)	4200
Total I2t value (A2s)	500
Homologations	IEC
Power loss (W)	5,4
Rated Voltage Un DC (V)	50
Rated break.capacity I1 DC (A)	100000

Product available on request Ask for more information

Fuse 22x58 500V DC gBat with terminals 80mm 63A

Reference 5016136.63.0 - Manufacturer SIBA

Class	gBat
Rated current In (A)	1300
Rated Voltage Un AC (V)	500
Format	Cylindrical
Dimension	22x58mm
Pre-arcing I2t value (A2s)	6300
Total I2t value (A2s)	500
Homologations	IEC
Power loss (W)	6,8
Rated Voltage Un DC (V)	63
Rated break.capacity I1 DC (A)	100000

Product available on request Ask for more information

Fuse 22x58 500V DC gBat with terminals 80mm 80A

Reference 5016136.80.0 - Manufacturer SIBA

Class	gBat
Rated current In (A)	2500
Rated Voltage Un AC (V)	500
Format	Cylindrical
Dimension	22x58mm
Pre-arcing I2t value (A2s)	12000
Total I2t value (A2s)	500
Homologations	IEC
Power loss (W)	7,5
Rated Voltage Un DC (V)	80
Rated break.capacity I1 DC (A)	100000

Product available on request Ask for more information

Fuse 22x58 500V DC gBat with pins 80mm 100A

Reference 5016236.100.0 - Manufacturer SIBA

Class	gBat
Rated current In (A)	4600
Rated Voltage Un AC (V)	500
Format	Cylindrical
Dimension	22x58mm
Pre-arcing I2t value (A2s)	22000
Total I2t value (A2s)	500
Homologations	IEC
Power loss (W)	9,7
Rated Voltage Un DC (V)	100
Rated break.capacity I1 DC (A)	100000

Product available on request Ask for more information

Fuse 22x58 500V DC gBat with pins 80mm 25A

Reference 5016236.25.0 - Manufacturer SIBA

Class	gBat
Rated current In (A)	100
Rated Voltage Un AC (V)	500
Format	Cylindrical
Dimension	22x58mm
Pre-arcing I2t value (A2s)	480
Total I2t value (A2s)	500
Homologations	IEC
Power loss (W)	3,6
Rated Voltage Un DC (V)	25
Rated break.capacity I1 DC (A)	100000

Product available on request Ask for more information

Fuse 22x58 500V DC gBat with pins 80mm 30A

Reference 5016236.30.0 - Manufacturer SIBA

Class	gBat
Rated current In (A)	190
Rated Voltage Un AC (V)	500
Format	Cylindrical
Dimension	22x58mm
Pre-arcing I2t value (A2s)	910
Total I2t value (A2s)	500
Homologations	IEC
Power loss (W)	4,6
Rated Voltage Un DC (V)	30
Rated break.capacity I1 DC (A)	100000

Product available on request Ask for more information

Fuse 22x58 500V DC gBat with pins 80mm 32A

Reference 5016236.32.0 - Manufacturer SIBA

Class	gBat
Rated current In (A)	250
Rated Voltage Un AC (V)	500
Format	Cylindrical
Dimension	22x58mm
Pre-arcing I2t value (A2s)	1200
Total I2t value (A2s)	500
Homologations	IEC
Power loss (W)	4,8
Rated Voltage Un DC (V)	32
Rated break.capacity I1 DC (A)	100000

Product available on request Ask for more information

Fuse 22x58 500V DC gBat with pins 80mm 35A

Reference 5016236.35.0 - Manufacturer SIBA

Class	gBat
Rated current In (A)	330
Rated Voltage Un AC (V)	500
Format	Cylindrical
Dimension	22x58mm
Pre-arcing I2t value (A2s)	1600
Total I2t value (A2s)	500
Homologations	IEC
Power loss (W)	5
Rated Voltage Un DC (V)	35
Rated break.capacity I1 DC (A)	100000

Product available on request Ask for more information

Fuse 22x58 500V DC gBat with pins 80mm 40A

Reference 5016236.40.0 - Manufacturer SIBA

Class	gBat
Rated current In (A)	420
Rated Voltage Un AC (V)	500
Format	Cylindrical
Dimension	22x58mm
Pre-arcing I2t value (A2s)	2000
Total I2t value (A2s)	500
Homologations	IEC
Power loss (W)	5,2
Rated Voltage Un DC (V)	40
Rated break.capacity I1 DC (A)	100000

Product available on request Ask for more information

Fuse SQB1 1500V DC knife US aBat/aR 250A

Reference 9044538.250.0 - Manufacturer SIBA

Rated current In (A)	250
Voltage of total I2t test	1500
Format	Screw fixing
Dimension	SQB-DC151
Pre-arcing I2t value (A2s)	20000
Total I2t value (A2s)	120000
Power loss (W)	70
Rated Voltage Un DC (V)	1500
Rated break.capacity I1 DC (A)	260000
Time costant L/R (ms)	3

Price List €147.35/pc

Quantity

Fuse SQB1 1500V DC knife US aBat/aR 550A

Reference 9044538.550.0 - Manufacturer SIBA

Rated current In (A)	550
Voltage of total I2t test	1500
Format	Screw fixing
Dimension	SQB-DC151
Pre-arcing I2t value (A2s)	190000
Total I2t value (A2s)	1140000
Power loss (W)	120
Rated Voltage Un DC (V)	1500
Rated break.capacity I1 DC (A)	260000
Time costant L/R (ms)	3

Product available on request Ask for more information

Fuse SQB1 1500V DC knife US aBat/aR 500A

Reference 9044538.500.0 - Manufacturer SIBA

Rated current In (A)	500
Voltage of total I2t test	1500
Format	Screw fixing
Dimension	SQB-DC151
Pre-arcing I2t value (A2s)	137000
Total I2t value (A2s)	820000
Power loss (W)	110
Rated Voltage Un DC (V)	1500
Rated break.capacity I1 DC (A)	260000
Time costant L/R (ms)	3

Product available on request Ask for more information

Fuse SQB1 1500V DC knife US aBat/aR 450A

Reference 9044538.450.0 - Manufacturer SIBA

Rated current In (A)	450
Voltage of total I2t test	1500
Format	Screw fixing
Dimension	SQB-DC151
Pre-arcing I2t value (A2s)	106000
Total I2t value (A2s)	640000
Power loss (W)	100
Rated Voltage Un DC (V)	1500
Rated break.capacity I1 DC (A)	260000
Time costant L/R (ms)	3

Product available on request Ask for more information

Fuse SQB1 1500V DC knife US aBat/aR 400A

Reference 9044538.400.0 - Manufacturer SIBA

Rated current In (A)	400
Voltage of total I2t test	1500
Format	Screw fixing
Dimension	SQB-DC151
Pre-arcing I2t value (A2s)	77000
Total I2t value (A2s)	460000
Power loss (W)	95
Rated Voltage Un DC (V)	1500
Rated break.capacity I1 DC (A)	260000
Time costant L/R (ms)	3

Product available on request Ask for more information

Fuse SQB1 1500V DC knife US aBat/aR 350A

Reference 9044538.350.0 - Manufacturer SIBA

Rated current In (A)	350
Voltage of total I2t test	1500
Format	Screw fixing
Dimension	SQB-DC151
Pre-arcing I2t value (A2s)	52000
Total I2t value (A2s)	315000
Power loss (W)	90
Rated Voltage Un DC (V)	1500
Rated break.capacity I1 DC (A)	260000
Time costant L/R (ms)	3

Price List €137.58/pc

Quantity

Fuse SQB1 1500V DC knife US aBat/aR 315A

Reference 9044538.315.0 - Manufacturer SIBA

Rated current In (A)	315
Voltage of total I2t test	1500
Format	Screw fixing
Dimension	SQB-DC151
Pre-arcing I2t value (A2s)	38000
Total I2t value (A2s)	230000
Power loss (W)	80
Rated Voltage Un DC (V)	1500
Rated break.capacity I1 DC (A)	260000
Time costant L/R (ms)	3

Price List €154.68/pc

Quantity

Fuse 22x58 500V DC gBat with pins 80mm 80A

Reference 5016236.80.0 - Manufacturer SIBA

Class	gBat
Rated current In (A)	2500
Rated Voltage Un AC (V)	500
Format	Cylindrical
Dimension	22x58mm
Pre-arcing I2t value (A2s)	12000
Total I2t value (A2s)	500
Homologations	IEC
Power loss (W)	7,5
Rated Voltage Un DC (V)	80
Rated break.capacity I1 DC (A)	100000

Product available on request Ask for more information

3503 products

01
• • •
24
•
25
•
26
• • •
98

List of products by manufacturer SIBA

INFORMATIONS

ACCOUNT

CONTACT US

NEWSLETTER
