List of products by manufacturer SIBA

Fuse 14x65 gPV 1100VDC plap contacts 8A

Fuse 14x65 gPV 1100VDC plap contacts 8A

Reference 5023926.8.0 - Manufacturer SIBA
Class gPV
Rated current In (A) 8
Applicable standards IEC
Rated Voltage Un DC (V) 1100
Rated breaking capacity I1 DC (kA) 30000
Fuse Dimension (mm) 14x65
Melting I²t value (A²s) 5
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 1100
Total clearing I²t @Un AC (A²s) 22
Product available on request Ask for more information
Fuse 14x65 1100VDC gPV UL2579 plap contacts 10A

Fuse 14x65 1100VDC gPV UL2579 plap contacts 10A

Reference 5023928.10.0 - Manufacturer SIBA
Class gPV
Rated current In (A) 10
Applicable standards IEC, UL
Power loss (W) 4
Rated Voltage Un DC (V) 1100
Rated breaking capacity I1 DC (kA) 30000
Fuse Dimension (mm) 14x65
Melting I²t value (A²s) 3
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 1100
Total clearing I²t @Un AC (A²s) 21
Weight (gr) 20
Product available on request Ask for more information
Fuse 14x65 1100VDC gPV UL2579 plap contacts 12A

Fuse 14x65 1100VDC gPV UL2579 plap contacts 12A

Reference 5023928.12.0 - Manufacturer SIBA
Class gPV
Rated current In (A) 12
Applicable standards IEC, UL
Power loss (W) 4,1
Rated Voltage Un DC (V) 1100
Rated breaking capacity I1 DC (kA) 30000
Fuse Dimension (mm) 14x65
Melting I²t value (A²s) 7,5
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 1100
Total clearing I²t @Un AC (A²s) 51
Weight (gr) 20
Product available on request Ask for more information
Fuse 27x60mm distance 80mm aR 1000VAC 100A

Fuse 27x60mm distance 80mm aR 1000VAC 100A

Reference 5019820.100.0 - Manufacturer SIBA
Class aR
Rated current In (A) 100
Applicable standards IEC
Power loss (W) 26
Fuse Dimension (mm) 27x60
Melting I²t value (A²s) 1000
Fuse Connection/Terminal type Screw fixing
Voltage of total clearing I2t test 1000
Total clearing I²t @Un AC (A²s) 6500
Weight (gr) 27
Price List €434.45/pc
Quantity
Fuse 27x60mm distance 80mm aR 1000VAC 25A

Fuse 27x60mm distance 80mm aR 1000VAC 25A

Reference 5019820.25.0 - Manufacturer SIBA
Class aR
Rated current In (A) 25
Applicable standards IEC
Power loss (W) 15
Fuse Dimension (mm) 27x60
Melting I²t value (A²s) 21
Fuse Connection/Terminal type Screw fixing
Voltage of total clearing I2t test 1000
Total clearing I²t @Un AC (A²s) 135
Weight (gr) 118
Price List €178.68/pc
Quantity
Fuse 27x60mm distance 80mm aR 1000VAC 32A

Fuse 27x60mm distance 80mm aR 1000VAC 32A

Reference 5019820.32.0 - Manufacturer SIBA
Class aR
Rated current In (A) 32
Applicable standards IEC
Power loss (W) 17
Fuse Dimension (mm) 27x60
Melting I²t value (A²s) 32
Fuse Connection/Terminal type Screw fixing
Voltage of total clearing I2t test 1000
Total clearing I²t @Un AC (A²s) 210
Weight (gr) 118
Price List €357.36/pc
Quantity
Fuse 27x60mm distance 80mm aR 1000VAC 63A

Fuse 27x60mm distance 80mm aR 1000VAC 63A

Reference 5019820.63.0 - Manufacturer SIBA
Class aR
Rated current In (A) 63
Applicable standards IEC
Power loss (W) 22
Fuse Dimension (mm) 27x60
Melting I²t value (A²s) 250
Fuse Connection/Terminal type Screw fixing
Voltage of total clearing I2t test 1000
Total clearing I²t @Un AC (A²s) 1630
Weight (gr) 118
Price List €357.36/pc
Quantity
Fuse 27x60mm distance 80mm aR 1000VAC 80A

Fuse 27x60mm distance 80mm aR 1000VAC 80A

Reference 5019820.80.0 - Manufacturer SIBA
Class aR
Rated current In (A) 80
Applicable standards IEC
Power loss (W) 24
Fuse Dimension (mm) 27x60
Melting I²t value (A²s) 512
Fuse Connection/Terminal type Screw fixing
Voltage of total clearing I2t test 1000
Total clearing I²t @Un AC (A²s) 3330
Weight (gr) 27
Price List €357.36/pc
Quantity
Fuse 14x51 aR/aBat 700VDC/500VAC with pins 10A

Fuse 14x51 aR/aBat 700VDC/500VAC with pins 10A

Reference 5020306.10.0 - Manufacturer SIBA
Class aBat, aR
Rated current In (A) 10
Rated Voltage Un AC (V) 500
Power loss (W) 1,1
Rated Voltage Un DC (V) 700
Rated breaking capacity I1 DC (kA) 30000
Fuse Dimension (mm) 14x51
Melting I²t value (A²s) 12
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 700
Total clearing I²t @Un AC (A²s) 67
Rated breaking capacity I1 AC (kA) 100000
Product available on request Ask for more information
Fuse 14x51 aR/aBat 700VDC/500VAC with pins 12A

Fuse 14x51 aR/aBat 700VDC/500VAC with pins 12A

Reference 5020306.12.0 - Manufacturer SIBA
Class aBat, aR
Rated current In (A) 12
Rated Voltage Un AC (V) 500
Power loss (W) 1,2
Rated Voltage Un DC (V) 700
Rated breaking capacity I1 DC (kA) 30000
Fuse Dimension (mm) 14x51
Melting I²t value (A²s) 20
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 700
Total clearing I²t @Un AC (A²s) 120
Rated breaking capacity I1 AC (kA) 100000
Product available on request Ask for more information
Fuse 14x51 aR/aBat 700VDC/500VAC with pins 16A

Fuse 14x51 aR/aBat 700VDC/500VAC with pins 16A

Reference 5020306.16.0 - Manufacturer SIBA
Class aBat, aR
Rated current In (A) 16
Rated Voltage Un AC (V) 500
Power loss (W) 2
Rated Voltage Un DC (V) 700
Rated breaking capacity I1 DC (kA) 30000
Fuse Dimension (mm) 14x51
Melting I²t value (A²s) 32
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 700
Total clearing I²t @Un AC (A²s) 190
Rated breaking capacity I1 AC (kA) 100000
Product available on request Ask for more information
Fuse 14x51 aR/aBat 700VDC/500VAC with pins 20A

Fuse 14x51 aR/aBat 700VDC/500VAC with pins 20A

Reference 5020306.20.0 - Manufacturer SIBA
Class aBat, aR
Rated current In (A) 20
Rated Voltage Un AC (V) 500
Power loss (W) 2,3
Rated Voltage Un DC (V) 700
Rated breaking capacity I1 DC (kA) 30000
Fuse Dimension (mm) 14x51
Melting I²t value (A²s) 63
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 700
Total clearing I²t @Un AC (A²s) 360
Rated breaking capacity I1 AC (kA) 100000
Product available on request Ask for more information
Fuse 14x51 aR/aBat 700VDC/500VAC with pins 25A

Fuse 14x51 aR/aBat 700VDC/500VAC with pins 25A

Reference 5020306.25.0 - Manufacturer SIBA
Class aBat, aR
Rated current In (A) 25
Rated Voltage Un AC (V) 500
Power loss (W) 3,1
Rated Voltage Un DC (V) 700
Rated breaking capacity I1 DC (kA) 30000
Fuse Dimension (mm) 14x51
Melting I²t value (A²s) 82
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 700
Total clearing I²t @Un AC (A²s) 480
Rated breaking capacity I1 AC (kA) 100000
Product available on request Ask for more information
Fuse 14x51 aR/aBat 700VDC/500VAC with pins 32A

Fuse 14x51 aR/aBat 700VDC/500VAC with pins 32A

Reference 5020306.32.0 - Manufacturer SIBA
Class aBat, aR
Rated current In (A) 32
Rated Voltage Un AC (V) 500
Power loss (W) 4,1
Rated Voltage Un DC (V) 700
Rated breaking capacity I1 DC (kA) 30000
Fuse Dimension (mm) 14x51
Melting I²t value (A²s) 130
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 700
Total clearing I²t @Un AC (A²s) 740
Rated breaking capacity I1 AC (kA) 100000
Product available on request Ask for more information
Fuse 14x51 aR/aBat 700VDC/500VAC with pins 63A

Fuse 14x51 aR/aBat 700VDC/500VAC with pins 63A

Reference 5020306.63.0 - Manufacturer SIBA
Class aBat, aR
Rated current In (A) 63
Rated Voltage Un AC (V) 500
Power loss (W) 9.5
Rated Voltage Un DC (V) 700
Rated breaking capacity I1 DC (kA) 30000
Fuse Dimension (mm) 14x51
Melting I²t value (A²s) 512
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 700
Total clearing I²t @Un AC (A²s) 3900
Rated breaking capacity I1 AC (kA) 100000
Product available on request Ask for more information
Fuse 14x51 gRL/gS 800VDC 10A

Fuse 14x51 gRL/gS 800VDC 10A

Reference 5020434.10.0 - Manufacturer SIBA
Class gRL, gS
Rated current In (A) 10
Applicable standards IEC, UL
Power loss (W) 2
Rated Voltage Un DC (V) 800
Time costant L/R (ms) 3
Rated breaking capacity I1 DC (kA) 30000
Fuse Dimension (mm) 14x51
Melting I²t value (A²s) 12
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 900
Total clearing I²t @Un AC (A²s) 80
Price List €16.83/pc
Quantity
lock Datasheet
Fuse 14x51 gRL/gS 800VDC 16A

Fuse 14x51 gRL/gS 800VDC 16A

Reference 5020434.16.0 - Manufacturer SIBA
Class gRL, gS
Rated current In (A) 16
Applicable standards IEC, UL
Power loss (W) 3
Rated Voltage Un DC (V) 800
Time costant L/R (ms) 3
Rated breaking capacity I1 DC (kA) 30000
Fuse Dimension (mm) 14x51
Melting I²t value (A²s) 30
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 900
Total clearing I²t @Un AC (A²s) 200
Price List €12.49/pc
Quantity
lock Datasheet
Fuse 14x51 gRL/gS 800VDC with bolted terminals 10A

Fuse 14x51 gRL/gS 800VDC with bolted terminals 10A

Reference 5020534.10.0 - Manufacturer SIBA
Class gRL, gS
Rated current In (A) 10
Applicable standards IEC, UL
Power loss (W) 3
Rated Voltage Un DC (V) 800
Time costant L/R (ms) 3
Rated breaking capacity I1 DC (kA) 30000
Fuse Dimension (mm) 14x51
Melting I²t value (A²s) 30
Fuse Connection/Terminal type Screw fixing
Voltage of total clearing I2t test 900
Total clearing I²t @Un AC (A²s) 200
Product available on request Ask for more information
Fuse 14x51 gRL/gS 800VDC with bolted terminals 20A

Fuse 14x51 gRL/gS 800VDC with bolted terminals 20A

Reference 5020534.20.0 - Manufacturer SIBA
Class gRL, gS
Rated current In (A) 20
Applicable standards IEC, UL
Power loss (W) 3,5
Rated Voltage Un DC (V) 800
Time costant L/R (ms) 3
Rated breaking capacity I1 DC (kA) 30000
Fuse Dimension (mm) 14x51
Melting I²t value (A²s) 82
Fuse Connection/Terminal type Screw fixing
Voltage of total clearing I2t test 900
Total clearing I²t @Un AC (A²s) 510
Price List €24.95/pc
Quantity
lock Datasheet
Fuse 10x35 DMI aR 1000VAC/DC 0,25A

Fuse 10x35 DMI aR 1000VAC/DC 0,25A

Reference 5021006.0,25.0 - Manufacturer SIBA
Class aR
Rated current In (A) 0,25
Rated Voltage Un AC (V) 1000
Power loss (W) 0,13
Rated Voltage Un DC (V) 1000
Fuse Dimension (mm) 10x35
Melting I²t value (A²s) 0,04
Fuse Connection/Terminal type Cylindrical
Weight (gr) 9
Price List €6.23/pc
Quantity
Fuse 10x35 DMI aR 1000VAC/DC 0,315A

Fuse 10x35 DMI aR 1000VAC/DC 0,315A

Reference 5021006.0,315.0 - Manufacturer SIBA
Class aR
Rated current In (A) 0,315
Rated Voltage Un AC (V) 1000
Power loss (W) 0,16
Rated Voltage Un DC (V) 1000
Fuse Dimension (mm) 10x35
Melting I²t value (A²s) 0,07
Fuse Connection/Terminal type Cylindrical
Weight (gr) 9
Price List €6.23/pc
Quantity
Fuse 10x35 DMI aR 1000VAC/DC 0,4A

Fuse 10x35 DMI aR 1000VAC/DC 0,4A

Reference 5021006.0,4.0 - Manufacturer SIBA
Class aR
Rated current In (A) 0,4
Rated Voltage Un AC (V) 1000
Power loss (W) 0,2
Rated Voltage Un DC (V) 1000
Fuse Dimension (mm) 10x35
Melting I²t value (A²s) 0,11
Fuse Connection/Terminal type Cylindrical
Weight (gr) 9
Price List €6.23/pc
Quantity
Fuse 10x38 gR 1000V UL/900V IEC AC/DC 3,5A

Fuse 10x38 gR 1000V UL/900V IEC AC/DC 3,5A

Reference 5021506.3,5.0 - Manufacturer SIBA
Class gR
Rated current In (A) 3,5
Applicable standards UL
Power loss (W) 0,5
Rated Voltage Un DC (V) 1000
Fuse Dimension (mm) 10x38
Melting I²t value (A²s) 5
Fuse Connection/Terminal type Cylindrical
Weight (gr) 10
Price List €16.41/pc
Quantity
Fuse 10x38 gR 1000V UL/900V IEC AC/DC with pins 0,5A

Fuse 10x38 gR 1000V UL/900V IEC AC/DC with pins 0,5A

Reference 5021606.0,5.0 - Manufacturer SIBA
Class gR
Rated current In (A) 0,5
Applicable standards UL
Power loss (W) 0,2
Rated Voltage Un DC (V) 1000
Fuse Dimension (mm) 10x38
Melting I²t value (A²s) 0,2
Fuse Connection/Terminal type Cylindrical
Weight (gr) 10
Price List €582.90/pc
Quantity
Fuse 10x38 gPV 1000VDC with pins 3,5A

Fuse 10x38 gPV 1000VDC with pins 3,5A

Reference 5021626.3,5.0 - Manufacturer SIBA
Class gPV
Rated current In (A) 3,5
Applicable standards IEC
Power loss (W) 1,5
Rated Voltage Un DC (V) 1000
Rated breaking capacity I1 DC (kA) 30000
Fuse Dimension (mm) 10x38
Melting I²t value (A²s) 8
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 1000
Weight (gr) 10
Product available on request Ask for more information
Fuse 10x38 gPV 1000VDC UL2579 with pins 1A

Fuse 10x38 gPV 1000VDC UL2579 with pins 1A

Reference 5021628.1.0 - Manufacturer SIBA
Class gPV
Rated current In (A) 1
Applicable standards IEC, UL
Power loss (W) 0,8
Rated Voltage Un DC (V) 1000
Rated breaking capacity I1 DC (kA) 30000
Fuse Dimension (mm) 10x38
Melting I²t value (A²s) 0,33
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 1000
Weight (gr) 10
Product available on request Ask for more information
Fuse 10x38 gPV 1000VDC UL2579 with pins 10A

Fuse 10x38 gPV 1000VDC UL2579 with pins 10A

Reference 5021628.10.0 - Manufacturer SIBA
Class gPV
Rated current In (A) 10
Applicable standards IEC, UL
Power loss (W) 2,3
Rated Voltage Un DC (V) 1000
Rated breaking capacity I1 DC (kA) 30000
Fuse Dimension (mm) 10x38
Melting I²t value (A²s) 5
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 1000
Weight (gr) 10
Product available on request Ask for more information
Fuse 10x38 gPV 1000VDC UL2579 with pins 16A

Fuse 10x38 gPV 1000VDC UL2579 with pins 16A

Reference 5021628.16.0 - Manufacturer SIBA
Class gPV
Rated current In (A) 16
Applicable standards IEC, UL
Power loss (W) 3,4
Rated Voltage Un DC (V) 1000
Rated breaking capacity I1 DC (kA) 30000
Fuse Dimension (mm) 10x38
Melting I²t value (A²s) 20
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 1000
Weight (gr) 10
Product available on request Ask for more information
Fuse 10x38 gPV 1000VDC UL2579 with pins 22,4A

Fuse 10x38 gPV 1000VDC UL2579 with pins 22,4A

Reference 5021628.22,4.0 - Manufacturer SIBA
Class gPV
Rated current In (A) 22,4
Applicable standards IEC, UL
Power loss (W) 4,5
Rated Voltage Un DC (V) 1000
Rated breaking capacity I1 DC (kA) 30000
Fuse Dimension (mm) 10x38
Melting I²t value (A²s) 52
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 1000
Weight (gr) 10
Product available on request Ask for more information
Fuse 10x38 gPV 1000VDC UL2579 with pins 3,5A

Fuse 10x38 gPV 1000VDC UL2579 with pins 3,5A

Reference 5021628.3,5.0 - Manufacturer SIBA
Class gPV
Rated current In (A) 3,5
Applicable standards IEC, UL
Power loss (W) 1,5
Rated Voltage Un DC (V) 1000
Rated breaking capacity I1 DC (kA) 30000
Fuse Dimension (mm) 10x38
Melting I²t value (A²s) 8
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 1000
Weight (gr) 10
Product available on request Ask for more information
Fuse 10x38 gPV 1000VDC UL2579 with pins 4A

Fuse 10x38 gPV 1000VDC UL2579 with pins 4A

Reference 5021628.4.0 - Manufacturer SIBA
Class gPV
Rated current In (A) 4
Applicable standards IEC, UL
Power loss (W) 1,8
Rated Voltage Un DC (V) 1000
Rated breaking capacity I1 DC (kA) 30000
Fuse Dimension (mm) 10x38
Melting I²t value (A²s) 10
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 1000
Weight (gr) 10
Product available on request Ask for more information
Fuse 10x38 gPV 1000VDC UL2579 with pins 8A

Fuse 10x38 gPV 1000VDC UL2579 with pins 8A

Reference 5021628.8.0 - Manufacturer SIBA
Class gPV
Rated current In (A) 8
Applicable standards IEC, UL
Power loss (W) 1,9
Rated Voltage Un DC (V) 1000
Rated breaking capacity I1 DC (kA) 30000
Fuse Dimension (mm) 10x38
Melting I²t value (A²s) 3
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 1000
Weight (gr) 10
Product available on request Ask for more information
Product added to compare.
Product added to wishlist
