List of products by manufacturer SIBA

Fuse 24kV 53x442 back-up with striker 40A 80N

Fuse 24kV 53x442 back-up with striker 40A 80N

Reference 3000513.40.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 40
Rated Voltage Un AC (V) 24000
Applicable standards IEC
Power loss (W) 106
Resistance (ohm) 43
Fuse Dimension (mm) 53x442
Melting I²t value (A²s) 2900
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 20880
Total clearing I²t @Un AC (A²s) 19000
Rated breaking capacity I1 AC (kA) 63000
Price List €560.25/pc
Quantity
lock Datasheet
Fuse 24kV 53x442 full range with striker 10A 80N

Fuse 24kV 53x442 full range with striker 10A 80N

Reference 3000603.10.0 - Manufacturer SIBA
Class HHD full
Rated current In (A) 10
Rated Voltage Un AC (V) 24000
Applicable standards IEC
Power loss (W) 38
Fuse Dimension (mm) 53x442
Melting I²t value (A²s) 85
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 24000
Total clearing I²t @Un AC (A²s) 420
Rated breaking capacity I1 AC (kA) 63000
Weight (gr) 1656
Price List €180.19/pc
Quantity
lock Datasheet
Fuse 24kV 53x442mm back up no lim. temp. 120N 25A

Fuse 24kV 53x442mm back up no lim. temp. 120N 25A

Reference 3000614.25.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 25
Rated Voltage Un AC (V) 24000
Power loss (W) 56
Fuse Dimension (mm) 53x442
Melting I²t value (A²s) 1,05
Minimum breaking current (A) 90
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 24000
Total clearing I²t @Un AC (A²s) 7,5
Rated breaking capacity I1 AC (kA) 63000
Weight (gr) 2283
Price List €85.95/pc
Quantity
Fuse 24kV 53x442 back-up with striker 31,5A 80N

Fuse 24kV 53x442 back-up with striker 31,5A 80N

Reference 3000613.31,5.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 31,5
Rated Voltage Un AC (V) 10000
Applicable standards IEC
Power loss (W) 73
Resistance (ohm) 0,054
Fuse Dimension (mm) 53x442
Melting I²t value (A²s) 1400
Minimum breaking current (A) 110
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 8700
Total clearing I²t @Un AC (A²s) 16000
Rated breaking capacity I1 AC (kA) 63000
Weight (gr) 2400
Price List €99.62/pc
Quantity
lock Datasheet
Fuse 24kV 53x442 TV with striker 4A 80N

Fuse 24kV 53x442 TV with striker 4A 80N

Reference 3000613.4.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 4
Rated Voltage Un AC (V) 10000
Applicable standards IEC
Power loss (W) 22
Resistance (ohm) 0,95
Fuse Dimension (mm) 53x442
Melting I²t value (A²s) 31
Minimum breaking current (A) 32
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 8700
Total clearing I²t @Un AC (A²s) 90
Rated breaking capacity I1 AC (kA) 63000
Weight (gr) 2280
Price List €73.93/pc
Quantity
lock Datasheet
Fuse 24kV 53x442 TV with striker 5A 80N

Fuse 24kV 53x442 TV with striker 5A 80N

Reference 3000613.5.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 5
Rated Voltage Un AC (V) 10000
Applicable standards IEC
Power loss (W) 15
Resistance (ohm) 0,806
Fuse Dimension (mm) 53x442
Melting I²t value (A²s) 40
Minimum breaking current (A) 40
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 8700
Total clearing I²t @Un AC (A²s) 125
Rated breaking capacity I1 AC (kA) 63000
Weight (gr) 2270
Price List €448.74/pc
Quantity
lock Datasheet
Fuse 24kV 53x442 back-up with striker 40A 80N

Fuse 24kV 53x442 back-up with striker 40A 80N

Reference 3000613.50.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 50
Rated Voltage Un AC (V) 10000
Applicable standards IEC
Power loss (W) 117
Resistance (ohm) 0,028
Fuse Dimension (mm) 53x442
Melting I²t value (A²s) 4900
Minimum breaking current (A) 160
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 8700
Total clearing I²t @Un AC (A²s) 35000
Rated breaking capacity I1 AC (kA) 63000
Weight (gr) 2290
Price List €80.54/pc
Quantity
lock Datasheet
Fuse 24kV 53x442 back-up with striker 6,3A 80N

Fuse 24kV 53x442 back-up with striker 6,3A 80N

Reference 3000613.6,3.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 6,3
Rated Voltage Un AC (V) 10000
Applicable standards IEC
Power loss (W) 27
Resistance (ohm) 0,553
Fuse Dimension (mm) 53x442
Melting I²t value (A²s) 27
Minimum breaking current (A) 22
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 8700
Total clearing I²t @Un AC (A²s) 530
Rated breaking capacity I1 AC (kA) 63000
Weight (gr) 2320
Price List €73.41/pc
Quantity
lock Datasheet
Fuse 24kV 53x442mm back up no temp lim.10A 120N

Fuse 24kV 53x442mm back up no temp lim.10A 120N

Reference 3000614.10.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 10
Rated Voltage Un AC (V) 24000
Power loss (W) 52
Fuse Dimension (mm) 53x442
Melting I²t value (A²s) 75
Minimum breaking current (A) 34
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 24000
Total clearing I²t @Un AC (A²s) 560
Rated breaking capacity I1 AC (kA) 63000
Weight (gr) 2210
Price List €71.26/pc
Quantity
Fuse 24kV 53x442mm back up no temp lim.16A 120N

Fuse 24kV 53x442mm back up no temp lim.16A 120N

Reference 3000614.16.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 16
Rated Voltage Un AC (V) 24000
Power loss (W) 59
Fuse Dimension (mm) 53x442
Melting I²t value (A²s) 2
Minimum breaking current (A) 56
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 24000
Total clearing I²t @Un AC (A²s) 250
Rated breaking capacity I1 AC (kA) 63000
Weight (gr) 2210
Price List €77.67/pc
Quantity
Fuse 36kV 53x537 back-up without striker 2A

Fuse 36kV 53x537 back-up without striker 2A

Reference 3000811.2.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 2
Rated Voltage Un AC (V) 36000
Applicable standards IEC
Power loss (W) 23
Resistance (ohm) 4,26
Fuse Dimension (mm) 53x537
Melting I²t value (A²s) 3,2
Minimum breaking current (A) 16
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 31320
Total clearing I²t @Un AC (A²s) 9,8
Rated breaking capacity I1 AC (kA) 63000
Weight (gr) 2690
Price List €89.83/pc
Quantity
lock Datasheet
Fuse 36kV 53x537 back-up no striker 1A

Fuse 36kV 53x537 back-up no striker 1A

Reference 3000811.1.0 - Manufacturer SIBA
Class HH Back up
Rated current In (A) 1
Rated Voltage Un AC (V) 36000
Applicable standards IEC
Power loss (W) 13
Resistance (ohm) 9,57
Fuse Dimension (mm) 53x292
Melting I²t value (A²s) 0,63
Minimum breaking current (A) 8
Fuse Connection/Terminal type Cylindrical
Voltage of total clearing I2t test 31320
Total clearing I²t @Un AC (A²s) 1,8
Rated breaking capacity I1 AC (kA) 40000
Weight (gr) 2690
Price List €89.71/pc
Quantity
lock Datasheet
