List of products by manufacturer SIBA

Showing 721-756 of 3503 item(s)

Fuse NH2 gR 500V top indicator 32A

Reference 2000404.32.0 - Manufacturer SIBA

Class	gR
Rated current In (A)	32
Rated Voltage Un AC (V)	500
Rated break.capacity I1 AC (A)	120000
Voltage of total I2t test	500
Weight (g)	650
Format	NH knife contact
Dimension	NH2
Pre-arcing I2t value (A2s)	67
Total I2t value (A2s)	550
Power loss (W)	7,4

Price List €722.14/pc

Quantity

lock Datasheet

Fuse holder 5x20 with screw for panel

Reference 199070.0.0 - Manufacturer SIBA

Rated current In (A)	10
Rated Voltage Un AC (V)	250
Weight (g)	6
Power loss (W)	2,5
Fuses format	Cylindrical
Fuses dimension	5x20mm

Price List €5.72/pc

Quantity

Fuse 6,3x32 T 250V glass 2,8A 7005976.2,8

Reference 189500.2,8.0 - Manufacturer SIBA

Rated current In (A)	2,8
Rated Voltage Un AC (V)	250
Rated break.capacity I1 AC (A)	100
Voltage of total I2t test	250
Weight (g)	3
Format	Cylindrical
Dimension	6,3x32mm
Pre-arcing I2t value (A2s)	120
Homologations	UL
Power loss (W)	0,76
Voltage drop (mV)	270

Product available on request Ask for more information

Fuse 6,3x32 T 250V glass 3A 7005961.3

Reference 189100.3.0 - Manufacturer SIBA

Rated current In (A)	3
Rated Voltage Un AC (V)	250
Rated break.capacity I1 AC (A)	35
Voltage of total I2t test	250
Weight (g)	3
Format	Cylindrical
Dimension	6,3x32mm

Price List €0.81/pc

Quantity

lock Datasheet

Fuse 6,3x32 F 500V UL ceramic 0,5A 7006563.0,5

Reference 189020.0,5.0 - Manufacturer SIBA

Class	F
Rated current In (A)	0,5
Rated Voltage Un AC (V)	500
Rated break.capacity I1 AC (A)	50000
Voltage of total I2t test	500
Weight (g)	3
Format	Cylindrical
Dimension	6,3x32mm
Pre-arcing I2t value (A2s)	0,19
Homologations	UL
Power loss (W)	1,1
Voltage drop (mV)	800

Price List €0.84/pc

Quantity

lock Datasheet

Fuse 6,3x34mm F 450V glass 7A 7005960.7

Reference 189000.7.0 - Manufacturer SIBA

Class	F
Rated current In (A)	7
Rated Voltage Un AC (V)	250
Rated break.capacity I1 AC (A)	70
Voltage of total I2t test	250
Weight (g)	3
Format	Cylindrical
Dimension	6,3x32mm
Pre-arcing I2t value (A2s)	170
Homologations	IEC
Power loss (W)	1,8
Voltage drop (mV)	170

Price List €0.99/pc

Quantity

lock Datasheet

Fuse VT 12kV 39,6x220 1A

Reference 3037211.1.0 - Manufacturer SIBA

Rated current In (A)	1
Rated Voltage Un AC (V)	12000
Rated break.capacity I1 AC (A)	63000
Voltage of total I2t test	12000
Weight (g)	680
Format	BS
Dimension	40x220mm
Pre-arcing I2t value (A2s)	0,6
Total I2t value (A2s)	1,9
Homologations	IEC
Power loss (W)	5,3
Min breaking current (A)	8

Price List €69.39/pc

Quantity

lock Datasheet

Fuse 15,5kV 63,5x359 1/2 UNC 10A

Reference 3035421.10.0 - Manufacturer SIBA

Rated current In (A)	10
Rated Voltage Un AC (V)	15500
Rated break.capacity I1 AC (A)	63000
Voltage of total I2t test	15500
Weight (g)	2700
Format	Cylindrical
Dimension	63,5x359mm
Pre-arcing I2t value (A2s)	75
Total I2t value (A2s)	500
Homologations	IEC
Power loss (W)	38

Product available on request Ask for more information

Fuse 7,2kV 85x442 back-up with striker no temp-limiting 160A

Reference 3011014.160.0 - Manufacturer SIBA

Rated current In (A)	160
Rated Voltage Un AC (V)	7200
Rated break.capacity I1 AC (A)	50000
Voltage of total I2t test	6264
Weight (g)	5670
Format	Cylindrical
Dimension	85x442mm
Homologations	IEC

Price List €646.85/pc

Quantity

lock Datasheet

Fuse SQB1 110mm aR 1250V top switch adapter 200A

Reference 2071432.200.0 - Manufacturer SIBA

Class	aR
Rated current In (A)	200
Rated Voltage Un AC (V)	1250
Rated break.capacity I1 AC (A)	100000
Voltage of total I2t test	1000
Weight (g)	580
Format	Screw fixing
Dimension	SQB1-110mm
Pre-arcing I2t value (A2s)	4600
Total I2t value (A2s)	25000
Power loss (W)	49

Price List €257.92/pc

Quantity

lock Datasheet

Fuse SQB3 110mm aR 450V lateral switch adapter 1800A

Reference 2063532.1800.0 - Manufacturer SIBA

Class	aR
Rated current In (A)	1800
Rated Voltage Un AC (V)	450
Rated break.capacity I1 AC (A)	200000
Voltage of total I2t test	660
Weight (g)	920
Format	Screw fixing
Dimension	SQB3-80mm
Pre-arcing I2t value (A2s)	903000
Total I2t value (A2s)	4300000
Homologations	IEC
Power loss (W)	200

Price List €129.26/pc

Quantity

lock Datasheet

Fuse SQB2 US-Long aR 690V lateral switch adapter 350A

Reference 2062832.350.0 - Manufacturer SIBA

Class	aR
Rated current In (A)	350
Rated Voltage Un AC (V)	690
Rated break.capacity I1 AC (A)	200000
Voltage of total I2t test	660
Weight (g)	640
Format	Screw fixing
Dimension	SQB2 US-Long
Pre-arcing I2t value (A2s)	11800
Total I2t value (A2s)	68000
Homologations	IEC
Power loss (W)	61

Product available on request Ask for more information

Fuse SQB2 US-Long aR 690V lateral switch adapter 1000A

Reference 2062832.1000.0 - Manufacturer SIBA

Class	aR
Rated current In (A)	1000
Rated Voltage Un AC (V)	690
Rated break.capacity I1 AC (A)	200000
Voltage of total I2t test	660
Weight (g)	640
Format	Screw fixing
Dimension	SQB2 US-Long
Pre-arcing I2t value (A2s)	230000
Total I2t value (A2s)	1260000
Power loss (W)	115

Price List €299.44/pc

Quantity

lock Datasheet

Fuse SQB2 80mm aR 690V top switch adapter 700A

Reference 2062132.700.0 - Manufacturer SIBA

Class	aR
Rated current In (A)	700
Rated Voltage Un AC (V)	690
Rated break.capacity I1 AC (A)	200000
Voltage of total I2t test	660
Weight (g)	550
Format	Screw fixing
Dimension	SQB2-80mm
Pre-arcing I2t value (A2s)	74000
Total I2t value (A2s)	410000
Power loss (W)	99

Price List €277.23/pc

Quantity

lock Datasheet

Fuse NH3M aM 1000V 450A

Reference 2039708.450.0 - Manufacturer SIBA

Class	aM
Rated current In (A)	450
Rated Voltage Un AC (V)	1000
Rated break.capacity I1 AC (A)	25000
Voltage of total I2t test	760
Weight (g)	1030
Format	NH knife contact
Dimension	NH3M
Pre-arcing I2t value (A2s)	672000
Total I2t value (A2s)	2688000
Power loss (W)	44

Price List €280.66/pc

Quantity

lock Datasheet

Fuse NH2M aM 1000V 35A

Reference 2039608.35.0 - Manufacturer SIBA

Class	aM
Rated current In (A)	35
Rated Voltage Un AC (V)	1000
Rated break.capacity I1 AC (A)	25000
Voltage of total I2t test	760
Weight (g)	770
Format	NH knife contact
Dimension	NH2M
Pre-arcing I2t value (A2s)	3700
Total I2t value (A2s)	14800
Power loss (W)	2,4

Price List €195.07/pc

Quantity

lock Datasheet

Fuse NH2M aM 1000V 160A

Reference 2039608.160.0 - Manufacturer SIBA

Class	aM
Rated current In (A)	160
Rated Voltage Un AC (V)	1000
Rated break.capacity I1 AC (A)	25000
Voltage of total I2t test	760
Weight (g)	760
Format	NH knife contact
Dimension	NH2M
Pre-arcing I2t value (A2s)	75000
Total I2t value (A2s)	300000
Power loss (W)	14

Price List €195.10/pc

Quantity

lock Datasheet

Fuse NH00 long gB 1000V 100A

Reference 2038903.100.0 - Manufacturer SIBA

Class	gB
Rated current In (A)	100
Rated Voltage Un AC (V)	1000
Rated break.capacity I1 AC (A)	25000
Voltage of total I2t test	760
Weight (g)	280
Format	NH knife contact
Dimension	NH00
Pre-arcing I2t value (A2s)	3300
Total I2t value (A2s)	9900
Power loss (W)	18,3

Price List €138.65/pc

Quantity

lock Datasheet

Fuse NH00 gRL 800V 50A

Reference 2030934.50.0 - Manufacturer SIBA

Rated current In (A)	50
Rated Voltage Un AC (V)	800
Rated break.capacity I1 AC (A)	120000
Voltage of total I2t test	800
Weight (g)	214
Format	NH knife contact
Dimension	NH00
Pre-arcing I2t value (A2s)	2600
Total I2t value (A2s)	12800
Homologations	IEC
Power loss (W)	12

Price List €149.16/pc

Quantity

Fuse SQB2 110mm gRL/gS 690VAC/500VDC with indicator 400A

Reference 2027234.400.0 - Manufacturer SIBA

Rated current In (A)	400
Rated Voltage Un AC (V)	690
Rated break.capacity I1 AC (A)	200000
Voltage of total I2t test	690
Weight (g)	600
Format	Screw fixing
Dimension	SQB2-110mm
Pre-arcing I2t value (A2s)	85000
Total I2t value (A2s)	442000
Homologations	IEC
Power loss (W)	48
Rated Voltage Un DC (V)	500
Rated break.capacity I1 DC (A)	32000
Time costant L/R (ms)	15

Price List €155.90/pc

Quantity

lock Datasheet

Fuse SQB2 110mm gRL/gS 690VAC/500VDC with indicator 350A

Reference 2027234.350.0 - Manufacturer SIBA

Rated current In (A)	350
Rated Voltage Un AC (V)	690
Rated break.capacity I1 AC (A)	200000
Voltage of total I2t test	690
Weight (g)	600
Format	Screw fixing
Dimension	SQB2-110mm
Pre-arcing I2t value (A2s)	58000
Total I2t value (A2s)	310000
Homologations	IEC
Power loss (W)	43
Rated Voltage Un DC (V)	500
Rated break.capacity I1 DC (A)	32000
Time costant L/R (ms)	15

Price List €136.85/pc

Quantity

lock Datasheet

Fuse SQB1 110mm gRL/gS 690VAC/500VDC with indicator 200A

Reference 2026934.200.0 - Manufacturer SIBA

Rated current In (A)	200
Rated Voltage Un AC (V)	690
Rated break.capacity I1 AC (A)	200000
Voltage of total I2t test	690
Weight (g)	600
Format	Screw fixing
Dimension	SQB1-110mm
Pre-arcing I2t value (A2s)	15000
Total I2t value (A2s)	190000
Homologations	IEC
Power loss (W)	27
Rated Voltage Un DC (V)	500
Rated break.capacity I1 DC (A)	32000
Time costant L/R (ms)	12

Price List €92.90/pc

Quantity

lock Datasheet

Fuse 7,2kV 76x359 back-up TA3 125A

Reference 3024936.125.0 - Manufacturer SIBA

Rated current In (A)	125
Rated Voltage Un AC (V)	7200
Rated break.capacity I1 AC (A)	40000
Voltage of total I2t test	7200
Weight (g)	3880
Format	BS
Dimension	76x359mm
Pre-arcing I2t value (A2s)	81000
Total I2t value (A2s)	241000
Homologations	IEC

Product available on request Ask for more information

Fuse SQB1 screw M8 aR 1100V top indicator 630A

Reference 2076032.630.0 - Manufacturer SIBA

Class	aR
Rated current In (A)	630
Rated Voltage Un AC (V)	1100
Rated break.capacity I1 AC (A)	100000
Voltage of total I2t test	1000
Weight (g)	510
Format	Screw fixing
Dimension	SQB1 screw M8
Pre-arcing I2t value (A2s)	126000
Total I2t value (A2s)	670000
Power loss (W)	99

Price List €1,534.55/pc

Quantity

lock Datasheet

Fuse SQB3 gRL/gS 690V M12 lateral switch adapter 450A

Reference 2025434.450.0 - Manufacturer SIBA

Rated current In (A)	450
Rated Voltage Un AC (V)	690
Rated break.capacity I1 AC (A)	200000
Voltage of total I2t test	690
Weight (g)	500
Format	Screw fixing
Dimension	SQB3 screw M12
Pre-arcing I2t value (A2s)	107000
Total I2t value (A2s)	560000
Homologations	IEC
Power loss (W)	48

Price List €152.50/pc

Quantity

lock Datasheet

Fuse 40,5kV 67x537 back-up with striker 40A 80N

Reference 3034113.40.0 - Manufacturer SIBA

Rated current In (A)	40
Rated Voltage Un AC (V)	40500
Rated break.capacity I1 AC (A)	40000
Voltage of total I2t test	35235
Weight (g)	4450
Format	Cylindrical
Dimension	537x67mm
Pre-arcing I2t value (A2s)	2500
Total I2t value (A2s)	19800
Homologations	IEC
Power loss (W)	202
Resistance (ohm)	0,073
Min breaking current (A)	140

Price List €168.21/pc

Quantity

lock Datasheet

Fuse 24kV 63,5x360 M8 oiltight 40A

Reference 3031211.40.0 - Manufacturer SIBA

Rated current In (A)	40
Rated Voltage Un AC (V)	24000
Rated break.capacity I1 AC (A)	63000
Voltage of total I2t test	24000
Weight (g)	2520
Format	Cylindrical
Dimension	63,5x360mm
Pre-arcing I2t value (A2s)	2200
Total I2t value (A2s)	22000
Homologations	IEC
Power loss (W)	94

Price List €179.65/pc

Quantity

lock Datasheet

"Fuse 17,5kV 63,5x360 general purpose M8-M8 w/o striker 10A

Reference 3031091.10.0 - Manufacturer SIBA

Rated current In (A)	10
Rated Voltage Un AC (V)	12000
Rated break.capacity I1 AC (A)	63000
Voltage of total I2t test	12000
Weight (g)	2600
Format	Cylindrical
Dimension	63,5x360mm
Pre-arcing I2t value (A2s)	250
Total I2t value (A2s)	2800
Homologations	IEC
Power loss (W)	11

Product available on request Ask for more information

Fuse 213x27 3000V DC 4A

Reference 3030801.4.0 - Manufacturer SIBA

Rated current In (A)	4
Weight (g)	480
Format	Cylindrical
Dimension	27x213mm
Pre-arcing I2t value (A2s)	7,5
Power loss (W)	3,4
Rated Voltage Un DC (V)	3000
Rated break.capacity I1 DC (A)	50000
Resistance (ohm)	145
Time costant L/R (ms)	10
Min breaking current (A)	15

Product available on request Ask for more information

Fuse 17,5kV 85x367back-up striker no temp.lim200ARC125

Reference 3017814.200.0 - Manufacturer SIBA

Rated current In (A)	200
Rated Voltage Un AC (V)	17500
Rated break.capacity I1 AC (A)	63000
Voltage of total I2t test	15225
Weight (g)	4800
Format	Cylindrical
Dimension	85x367mm
Pre-arcing I2t value (A2s)	146000
Total I2t value (A2s)	1166000
Homologations	IEC
Power loss (W)	118
Resistance (ohm)	0,0051
Min breaking current (A)	800

Price List €246.98/pc

Quantity

lock Datasheet

Fuse 12kV 63,5x254 F01 oiltight 16A

Reference 3014436.16.0 - Manufacturer SIBA

Rated current In (A)	16
Rated Voltage Un AC (V)	12000
Rated break.capacity I1 AC (A)	40000
Voltage of total I2t test	12000
Weight (g)	1810
Format	Cylindrical
Dimension	63,5x254mm
Pre-arcing I2t value (A2s)	190
Total I2t value (A2s)	1800
Homologations	IEC

Price List €210.94/pc

Quantity

lock Datasheet

Fuse 12kV 76x359 back-up FA2 100A

Reference 3014736.100.0 - Manufacturer SIBA

Rated current In (A)	100
Rated Voltage Un AC (V)	12000
Rated break.capacity I1 AC (A)	40000
Voltage of total I2t test	12000
Weight (g)	2500
Format	BS
Dimension	76x359mm
Pre-arcing I2t value (A2s)	52900
Total I2t value (A2s)	158000
Homologations	IEC

Price List €512.81/pc

Quantity

lock Datasheet

Fuse 17,5kV 53x367 back-up with striker 2,5A 80N

Reference 3017613.2,5.0 - Manufacturer SIBA

Rated current In (A)	2,5
Rated Voltage Un AC (V)	17500
Rated break.capacity I1 AC (A)	63000
Voltage of total I2t test	15225
Weight (g)	1980
Format	Cylindrical
Dimension	53x367mm
Pre-arcing I2t value (A2s)	7,2
Total I2t value (A2s)	24
Homologations	IEC
Power loss (W)	12
Resistance (ohm)	1,4
Min breaking current (A)	20

Product available on request Ask for more information

Fuse 38,5kV TV 53x537 with striker 10A 80N

Reference 3033713.10.0 - Manufacturer SIBA

Rated current In (A)	10
Rated Voltage Un AC (V)	38500
Rated break.capacity I1 AC (A)	40000
Voltage of total I2t test	33495
Weight (g)	2740
Format	Cylindrical
Dimension	53x537mm
Pre-arcing I2t value (A2s)	68
Total I2t value (A2s)	1300
Homologations	IEC
Power loss (W)	82
Resistance (ohm)	0,609
Min breaking current (A)	34

Price List €693.10/pc

Quantity

lock Datasheet

Fuse 17,5kV 53x192 back-up with striker 6,3A 80N

Reference 3017913.6,3.0 - Manufacturer SIBA

Rated current In (A)	6,3
Rated Voltage Un AC (V)	17500
Rated break.capacity I1 AC (A)	63000
Voltage of total I2t test	15225
Weight (g)	1200
Format	Cylindrical
Dimension	53x192mm
Pre-arcing I2t value (A2s)	27
Total I2t value (A2s)	520
Homologations	IEC
Power loss (W)	22
Resistance (ohm)	0,402
Min breaking current (A)	22

Price List €123.07/pc

Quantity

lock Datasheet

Fuse 17,5kV 67x442 back-up with striker 16A 80N

Reference 3023113.16.0 - Manufacturer SIBA

Rated current In (A)	16
Rated Voltage Un AC (V)	17500
Rated break.capacity I1 AC (A)	63000
Voltage of total I2t test	15225
Weight (g)	2280
Format	Cylindrical
Dimension	53x442mm
Pre-arcing I2t value (A2s)	140
Total I2t value (A2s)	2400
Homologations	IEC
Power loss (W)	43
Resistance (ohm)	0,123
Min breaking current (A)	56

Price List €635.31/pc

Quantity

lock Datasheet

3503 products

01
• • •
20
•
21
•
22
• • •
98

List of products by manufacturer SIBA

INFORMATIONS

ACCOUNT

CONTACT US

NEWSLETTER
